Publication No. 5B9615
OCT95
Supersedes 4B4858
6/94
User's Manual
for the
Kodak Ektascan 2180 Laser Printer
and the
Kodak X-Omat 180 LP or 180 LPS
Processor
H126_0703AA
HEALTH SCIENCES DIVISION
© Eastman Kodak Company

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ektascan 2180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kodak Ektascan 2180

  • Page 1 Publication No. 5B9615 OCT95 Supersedes 4B4858 6/94 User’s Manual for the Kodak Ektascan 2180 Laser Printer and the Kodak X-Omat 180 LP or 180 LPS Processor H126_0703AA HEALTH SCIENCES DIVISION © Eastman Kodak Company...
  • Page 2: Table Of Contents

    No patent license is granted by this information. Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable Table of Contents Description...
  • Page 3 Section 15: Preventive Maintenance 15-1 Overview 15-2 Weekly 15-3 Monthly 15-8 Section 16: Using a 21-Step Gray Scale for Processor Quality Assurance 16-1 Overview 16-2 Printing the 21-Step Gray Scale 16-2 Setting Up the Kodak Process Control Densitometer 16-3 5B9615 –3...
  • Page 4 Daily Processor Quality Assurance 16-9 Evaluating the Control Chart 16-10 Crossover Procedure 16-10 Final Comments 16-11 Section 17: Kodak X-Omat 180 LP or 180 LPS Sorter Kit 17-1 Introduction 17-2 General Information 17-2 Using the Control Panel 17-4 Clearing Film Jams...
  • Page 5: Section 1: Safety Information For The Kodak Ektascan 2180 Laser Printer

    Read and understand all instructions before using. The Kodak Ektascan 2180 Laser Printer is a Class I device. This means that for protection of the user against electrical shock, this device relies on a proper ground connection as outlined in the Site Specifications for the Kodak Ektascan 2180 Laser Printer.
  • Page 6 User’s Manual Note Noise Emission is less than 70 dBA. DANGER Laser radiation when open and interlocks defeated Avoid direct exposure to beam H126_2719AC Warning DANGER, AVOID LASER BEAM. THIS EQUIPMENT USES A VISIBLE RED LASER. LASER RADIATION CAN BE PRESENT WHEN THE MACHINE IS OPERATED WITH THE PANELS OFF AND THE INTERLOCKS DEFEATED.
  • Page 7 DO NOT use an extension cord to power the Laser Printer. Connect this equipment to a grounded outlet. Refer to the Site Specifications for the Kodak Ektascan 2180 Laser Printer and the Kodak X-Omat 180 LP or 180 LPS Processor for additional details.
  • Page 8 User’s Manual KODAK EKTASCAN 2180 Laser Printer SERVICE SERIAL 3230 3230 3230 3230 CODE NUMBER MANUFACTURED 100V 50/60 Hz 115V 60 Hz 120V 60 Hz 220/230/240 50 Hz LISTED 115B THIS PRODUCT COMPLIES WITH 21 CFR CHAPTER 1, SUBCHAPTER J.
  • Page 9 Safety Information for the Kodak Ektascan 2180 Laser Printer DANGER Laser radiation when open and interlocks defeated Avoid direct exposure to beam KODAK EKTASCAN 2180 Laser Printer SERVICE SERIAL 3230 3230 3230 3230 CODE NUMBER MANUFACTURED 100V 50/60 Hz 115V...
  • Page 10 • the Kodak Ektascan 2180 Laser Printer is used in accordance with the instructions for use. Note Please refer to the Kodak Ektascan 2180 Laser Printer and Kodak X-Omat 180 LP or 180 LPS Processor site specifications for installation and site preparation information. 1–6...
  • Page 11: Section 2: Printer Overview

    Printer Overview Section 2: Printer Overview Table of Contents Description Page About This Manual General Product Overview Printer Overview Display Screen Overview Keypad Overview Control Terminal 5B9615 2–1...
  • Page 12: About This Manual 3

    Before using the system, read each section carefully. Sections 2 - 8 of this manual are devoted to the operation of the Kodak Ektascan 2180 Laser Printer. Section 9 is a Quick Reference Guide to aid when using the Keypad and to show the flow of the Operator Interface Screens.
  • Page 13 • Section 9 - Quick Reference Guide provides information when using the Keypad and a flow chart of the Operator Interface Screens. • Sections 10-15 - Kodak X-Omat 180 LP or 180 LPS Processor provides Processor information. • Section 16 - Using a 21-Step Gray Scale for Processor Quality Assurance explains procedures related to processor quality assurance.
  • Page 14: General Product Overview

    The Kodak Ektascan 2180 Laser Printer prints high-quality, hard copy films of medical images using Kodak Ektascan HN or HNC laser imaging film. It is part of a diagnostic imaging system, and accepts medical images from multiple imaging devices. The Kodak Ektascan 2180 Laser Printer is designed to be integrated with the Kodak X-Omat 180 LP or 180 LPS Processor.
  • Page 15 Printer Overview Ultrasound Keypad Control Terminal Footswitch (optional) data cable autofilm link data cable autofilm link Keypad Footswitch H126_9061HA System Configuration Example The above illustration shows a typical system configuration. The Laser Printer can receive video and digital images from 6 to 8 imaging devices. Storage of images and other input-specific parameters can be controlled either by the Keypad or by autofilming commands from the imaging device.
  • Page 16 If a Processor is attached, the film is sent to be processed. Otherwise, you would select Receive Magazine for the film to be sent to a Receive Magazine and processed later. Imaging Device Kodak Ektascan 2180 Laser Printer Keypad Kodak X-Omat 180 LP Processor H126_9062HA 2–6...
  • Page 17: Printer Overview

    Printer Overview Printer Overview display screen printer control door panel function keys (6) latch film door processor slot cover densitometer main (built in) power switch H126_0702GCB H126_0702GA 5B9615 2–7...
  • Page 18: Display Screen Overview

    User’s Manual Display Screen Overview The following information briefly describes the information that is shown on the Display Screen on the Laser Printer. The general screen format is: CONTROL PRINTER Ready Supply 35 x 43B Supply 8 x 10C Receive mag Processor Start Printing Manage Study Reprinting...
  • Page 19 Printer Overview Data Section The following information is provided on the Data Section part of the Display Screen: • Screen title, shown in reverse video (which is at the top of the Display in the highlight bar). • Printer state - “Printing,” “Not printing,” “Ready,” “Testing,” or “Offline.” “Printing”...
  • Page 20 User’s Manual Command Section The following information is provided on the Command Section part of the Display Screen: • Up to six commands, consisting of a key label and descriptive text. You may perform any of the commands that appear on the screen by pressing the appropriate function key, such as [F1], [F2], or [F3].
  • Page 21 After print jobs are recovered, the prompt returns to the initial prompt as displayed. PRINTER STARTUP Offline KODAK EKTASCAN 2180 Laser Printer 1995 Eastman Kodak Company Initializing printer; please wait. H126_9021AC When all startup diagnostics are successfully executed, the Printer displays the Control Printer Screen.
  • Page 22 User’s Manual Control Printer Screen The following screen will be displayed most of the time during normal operation. Display Screens will be discussed in more detail in “Using the Control Panel” of Section 3. size and type of film approximate film level in Supply in Supply Magazine(s) Magazines...
  • Page 23: Keypad Overview

    Printer Overview Keypad Overview The following information explains the basic functions of the Keypad that can be used with the Laser Printer. The Keypad is a device that allows the user to enter commands which control the storing of images and the subsequent printing of those images. Each Keypad is independent and may be used to select parameters that are specific to that imaging device.
  • Page 24 User’s Manual Each item is explained briefly below. More complete explanations of specific key functions are located where the function is fully explained. Note If a particular feature or key is not available at the time it is pressed, the “Invalid Key” tone sounds.
  • Page 25 Printer Overview Footswitch Description The Footswitch connects directly to the back of the Keypad. Pressing the Footswitch stores an image just like the [Store] bar on the Keypad stores an image (left to right, top to bottom). 5B9615 2–15...
  • Page 26: Control Terminal

    User’s Manual Control Terminal The Control Terminal can be used to substitute or supplement existing autofilming or Keypad features for any device that sends commands to the Laser Printer. The Control Terminal and its features will be discussed in detail in Section 5 “Control Terminal.”...
  • Page 27: Section 3: Basic Operations

    Basic Operations Section 3: Basic Operations Table of Contents Description Page Start-Up and Shutdown Start-Up Shutdown Selecting Film Loading and Unloading Film Access Magazines Screen Changing Film Size Loading Roomlight Film in the Supply Magazine Unloading Film from the Receive Magazine Loading Film in the Darkroom Loading Film into a Partially-Empty Magazine Using the Control Panel...
  • Page 28: Start-Up And Shutdown

    User’s Manual Start-Up and Shutdown Start-Up [1] If a Processor is attached to the Laser Printer, see the procedure in Section 14 of Part II of this User’s Manual to start-up the 180 LP or 180 LPS Processor. [2] Turn on the main power switch for the Printer. display Processor main power switch...
  • Page 29 Receive Magazine, before the Laser Printer is turned off. [3] If a Kodak Ektascan Network Interface is installed in the Laser Printer, refer to the shutdown procedure for the Network Interface located in the User’s Guide for the Kodak Ektascan Network Interface for Laser Printer Interconnect.
  • Page 30: Selecting Film

    User’s Manual Selecting Film Overview The [Select Film] key on the Keypad allows you to select or change the film size or type that is used by the imaging device. The Control Terminal or Auxiliary Keypad may be used to select film for autofilming imaging devices. There are two film types (blue base and clear base), and four film sizes for the 2180 Laser Printer: •...
  • Page 31: Loading And Unloading Film

    Basic Operations Loading and Unloading Film Overview To load or unload film in the Laser Printer, select [F3] Access Magazines from the Control Printer Screen. CONTROL PRINTER Ready Supply 35 x 43B Supply 8 x 10C Receive mag Processor Start Printing Manage Study Reprinting Access Magazines Other Functions...
  • Page 32 User’s Manual Access Magazines Screen ACCESS MAGAZINES Not Printing Supply 35 x 43C Supply 8 x 10B Receive mag Access magazines, push in maga- zine drawers, and close door. H126_9024AC When this screen appears, the Printer will: • check to see if work is in progress. If so, the Printer displays a message, “Work in progress;...
  • Page 33 Basic Operations display screen Supply Magazine 1 control panel drawer function keys (6) 35 x 43 Clear Supply Magazine 2 8 x 10 Blue empty drawer magazine indicator light Receive Magazine H126_0712DA 5B9615 3–7...
  • Page 34 User’s Manual Changing Film Size To change the size of film used, you must [1] Load the new film into the Supply Magazine. [2] Insert the Magazine into the Printer. READY TO STORE IMAGE QUEUE:01 H126_2714BC [3] Select the new film size at a Keypad. If you are using the autofilming option, you can select the new film size at the Control Terminal or Auxiliary Keypad.
  • Page 35 Basic Operations Loading Roomlight Film in the Supply Magazine Film is stored in one of two Supply Magazines before it is used for printing images. Each Supply Magazine will accept only one film size at a time. The Supply Magazines Drawers are marked S1 and S2 to differentiate them from the Receive Magazine Drawer, which is labeled with an R.
  • Page 36 User’s Manual [3] Remove the old white cardboard and discard it. [4] Remove and discard the empty film pouch. [5] Make sure you have the proper film for the Magazine. [6] Place the new film package into the Magazine, checking that the side labeled “UP” is facing up as illustrated below and that the package is fully seated in the Magazine.
  • Page 37 Basic Operations [7] Lift flap 1 and place it over the teeth of the Spindle at the back of the Magazine. These teeth will engage to pull the film package off of the film. [8] Remove tape and fold out flap 2 as numbered on the film packaging and in the illustration below.
  • Page 38 User’s Manual [9] Close the Magazine Lid by lifting the Release Button on the left-hand side of the Supply Magazine, lowering the Lid, and pressing on the Magazine Lid until it latches on both sides. Important Do not put weight on the Supply Magazine. This will result in damage to the Drawer. Supply Magazine release button H126_0007ACA...
  • Page 39 Basic Operations [10] Remove flap 3 at the notch as indicated on the film packaging and in the illustration below. About 1 in. of the film package will hang out of the front of the Supply Magazine. The package will be wrapped up by the Spindle in the Supply Magazine. Supply Magazine H126_0010ACA H126_0010AA...
  • Page 40 User’s Manual [11] If you removed the Supply Magazine from the Supply Magazine Drawer, return it to the appropriate Supply Magazine Drawer in the Laser Printer. [12] Push the Supply Magazine Drawer all the way in until it latches and close the Film Door of the Printer.
  • Page 41 These features include the calibration or the transport of the film through the Printer to the docked Kodak X-Omat 180 LP or 180 LPS Processor. If none of the options is selected within a preset time delay, the Printer will automatically start printing.
  • Page 42 User’s Manual Unloading Film from the Receive Magazine The following is a summary of steps for unloading film from the Receive Magazine. Note Do not wear shoe types or clothing materials that might cause static, such as rubber sole shoes or nylon materials. [1] Select [F3] Access Magazines from the Control Printer Screen.
  • Page 43 Basic Operations Caution Do not open the Receive Magazine until you are in total darkness. When the Receive Magazine is removed, the software will change the “count” of the films in the Receive Magazine to zero. Important If the film is not removed from the Receive Magazine after removing the Magazine from the Printer, a film jam may occur when the Magazine becomes full.
  • Page 44 User’s Manual [5] Unlatch the two Side Latches to open the Magazine Lid. Note When the Receive Magazine is new, the Side Latches may be stiff and difficult to open. Receive Magazine H126_0012ACA H126_0012AA [6] Remove the film slowly, handling the films by the edges only. Flip the film over so that it is emulsion side up.
  • Page 45 These features include calibration or the transport of the film through the Printer to the docked Kodak X-Omat 180 LP or 180 LPS Processor. If none of the options is selected within a preset time delay, the Printer will automatically start printing.
  • Page 46 Be sure to load darkroom film in total darkness. No darkroom lights or safe lights can be used. If changing the size of the film, the correct size Carrier Board must be used also. If necessary, order the correct Carrier Board from Eastman Kodak Company, Service Parts Management. 35 x 43 cm Carrier Board Part No.
  • Page 47 Basic Operations [6] Open the film package, and with the notch in the front right-hand corner (or the rear left-hand corner), put the stack of film inside the Plastic Carrier Board as illustrated in the side view below. plastic carrier board film H126_3700ACA H126_3700AC...
  • Page 48 User’s Manual [7] Put the combined film and Plastic Carrier Board into the Supply Magazine as illustrated below. Supply Magazine film notch film plastic carrier board H126_0009ACA H126_0009AA [8] Close the Magazine Lid by lifting the Release Button on the left-hand side of the Supply Magazine, lowering the Lid, and pressing on the Magazine Lid until it latches on both sides.
  • Page 49: Using The Control Panel

    Basic Operations Using the Control Panel The Control Panel on the front of the Printer contains a Display Screen, and six Control Panel function keys. The Control Panel function keys are labeled [F1] through [F6], and they correspond to options which appear in the Command Section of the Display Screen. Control Printer Screen The Control Printer Screen displays after the Printer completes its startup procedure.
  • Page 50 User’s Manual CONTROL PRINTER Ready Supply 35 x 43B Supply 8 x 10C Receive mag Processor Start Printing Manage Study Reprinting Access Magazines Other Functions Select the desired function. H126_9029AC This function toggles between two alternatives: • “Start Printing” • “Stop Printing” When the “Start Printing”...
  • Page 51 Basic Operations Manage Study Reprinting The Manage Study Reprinting Screen is discussed in Section 7, “Study Reprinting.” It is accessed when you select [F2] on the Control Printer Screen. MANAGE STUDY REPRINTING 42 Studies Printing SOURCE: STUDIES Manage Selected Source Manage All Sources Return Select Source and Manage or...
  • Page 52 User’s Manual Select [F1] or [F2] to see the sources that are not displayed and to select a source. If you select [F3] or [F4] to print studies from one or all sources, the Manage Studies Screen appears. MANAGE STUDIES 5 Studies Printing 00012345689...
  • Page 53 Basic Operations Access Magazines Screen The Access Magazines function was discussed earlier, in the “Loading and Unloading Film” Section. It is accessed through the Control Printer Screen. Select [F3] to access this display. This screen stops the printing of films and opens the Film Door so that you can fill the Supply Magazines or remove the Receive Magazine.
  • Page 54 User’s Manual Other Functions Screen These screens allow you to perform other tasks. OTHER FUNCTIONS Ready 15-Oct-95 09:26 Calibrate Printer Access Film Path Transport Films Control Processor Show More Functions Return Select the desired function. H126_9032AC Calibrate Printer The [F1] function displays the Calibrate Printer Screen, which will be discussed in detail in Section 6, “Calibrating the 2180 Laser Printer.”...
  • Page 55 Basic Operations Transport Films The [F3] function displays the Transport Films Screen. The purpose of this function is to transport films from either Supply Magazine into the Receive Magazine or the docked Processor. This may be useful to clear fogged films from a Supply Magazine. These functions take place without exposing the film.
  • Page 56 User’s Manual Control Processor The [F4] function displays the Control Processor Screen if a Processor is installed with your Printer. The Control Processor Screen will be discussed in detail in the Processor section which is in Part II of this User’s Manual. Show More Functions The [F5] function displays additional options, as shown in the screen illustration on page 3–31.
  • Page 57 Basic Operations Return If you press [F6], you will be returned to the Control Printer Screen (the screen which you used to get to the Other Functions Screen). OTHER FUNCTIONS Ready 15-Oct-95 09:26 Manage Print Queue Show Printer Info Read Reference Strip Print Test Films Show More Functions Return...
  • Page 58 User’s Manual Manage Print Queue Press [F1] to display the Print Queue Screen. This screen will show all of the jobs in the print queue and allow you to delete jobs. PRINT QUEUE 9job/42flm Printing SOURCE PRIO STATUS CTRM1 Norm In prog STAT In prog...
  • Page 59 Basic Operations Print Queue Screen You can check the status of a job or delete a job that is in the Printer’s queue by looking at the Print Queue Screen. scroll bar PRINT QUEUE 9job/42flm Printing SOURCE PRIO STATUS CTRM1 Norm In prog STAT...
  • Page 60 User’s Manual • Job Status, which may be one of the following: – “In prog.” The job is in progress. Films in the job are moving through the Printer and Processor. Note that more than one job may have this status. –...
  • Page 61 Basic Operations Deleting Jobs Before a job can be deleted, it must be selected by pressing [F1] or [F2] at the Print Queue Screen, as described in the previous section. PRINT QUEUE 9job/42flm Printing SOURCE PRIO STATUS CTRM1 Norm In prog STAT In prog Norm...
  • Page 62 User’s Manual If you want to delete the job that is currently selected, press [F3]. The Printer displays the Delete Job Confirm Screen. If you want to delete all jobs selected, press [F4]. The Printer displays the Delete Job Confirm Screen. DELETE JOB CONFIRM 9job/42flms Printing...
  • Page 63 Basic Operations Show Printer Info Press [F2] to display the Show Printer Info Screen. This screen shows the telephone number which you can call for service, the serial number, the “K” number, film counts, and the number of films that were printed this year and last year and this month and last month.
  • Page 64 User’s Manual Press [F3] to display the Show Actuations by Source Screen. This screen provides the number of films that were printed from a directly connected imaging device during the specified time period. The Printer displays actuations by source in alphabetical order. This screen is not updated in real time.
  • Page 65 Basic Operations Print Test Films The [F4] function displays the Print Test Films Screen. This screen enables you to print test films to verify Printer and Processor operation. PRINT TEST FILMS Ready From: Supply 2 35 x 35C To: Receive mag Site 2 Calibration Flat Field Cal Results...
  • Page 66 User’s Manual Return If you press [F6], you will be returned to the previous screen (the screen which you used to get to the Other Functions Screen). Show More Functions The [F5] function displays the additional options in the Other Functions Screen. OTHER FUNCTIONS Ready 15-Oct-95...
  • Page 67 Basic Operations Set Time and Date Select [F1] Set Time and Date from the Other Functions Screen to display the Set Time and Date function. The [F1] function displays the Set Time and Date Screen. SET TIME AND DATE Ready 1-Oct-95 15 : 36 Increase...
  • Page 68 User’s Manual Select Destination Screen To select the destination for your exposed films, press the [F2] Control Panel function key while at the Other Functions Screen. The current destination is shown as selected on the screen. A Printer can be calibrated to support up to five remote Processor sites. If the Receive Magazine is selected, you must select a Processor site so that the correct system calibration can be used.
  • Page 69 Basic Operations Press [F1] to select the docked Processor or Receive Magazine function. By pressing [F1], you highlight either the box to the left of “Docked Processor” or the box to the left of the “Receive Magazine”. When “Docked Processor” is selected, the Site information in the screen and the [F2] and [F3] commands are not shown.
  • Page 70 User’s Manual 3–44 5B9615...
  • Page 71: Section 4: Keypad Functions

    Keypad Functions Section 4: Keypad Functions Table of Contents Description Page Using the Keypad Storing Images and Printing Pages Storing Images Setting Formats Special Format F1 Special Format F2 Special Format F3 - Slides Reverse Setting Number of Copies Printing Pages Autoprint Printing STAT Printing Deleting Images or Pages...
  • Page 72: Using The Keypad

    User’s Manual Using the Keypad Take a few minutes to review the Keypad on the Kodak Ektascan 2180 Laser Printer. READY TO STORE IMAGE QUEUE:01 H126_2713BC Message Display The display is divided into four areas. Area Function Top line, left side System status, for example, “Ready to Store Image”...
  • Page 73 Keypad Functions Numeric Keypad The left side of the Keypad functions both as Position Store Keys and as a numeric keypad. The numeric keypad is backlit only when the user is in the Program Mode. When the Keypad is used as a position store indicator, green indicates that the position is available for storage.
  • Page 74 This feature is available for Printers interconnected through the network. For information regarding the operation of interconnected Laser Printers, please refer to the User’s Guide for the Kodak Ektascan Network Interface for Laser Printer Interconnect. On networked systems, if a remote Printer is the selected Printer, the name of the Printer will replace Queue and Film Supply level information on the display of the Keypad.
  • Page 75: Storing Images And Printing Pages

    Keypad Functions Storing Images and Printing Pages Position Store Keys This section describes storing images and printing pages using a Keypad. If autofilming is used or these functions are controlled by the imaging device, check the appropriate imaging device manual for the correct procedures. Most formats activate the Position Store keys on the Keypad.
  • Page 76: Storing Images

    The procedures for changing options are listed below. The options are changed through the Keypad. The Kodak Ektascan 2180 Laser Printer retains the most recently-used format for the next page. Sixteen standard formats are available. They are formats 1, 2, 4, 6, 8, 9, 12, 15, 16, 20, 24, 30, 35, and Kodak formats F1, F2, and F3.
  • Page 77: Special Format F1

    Keypad Functions Special Format F1 Special Format F1 allows the printing of one large image and six smaller images. Locate group “A” in the figure below. These four keys represent one image store position. Any of the keys in this group may be selected to store (or delete) the image for this position.
  • Page 78: Special Format F2

    User’s Manual Special Format F2 Special Format F2 allows the printing of two large images and nine smaller images. Locate group “A” and “B” in the figure below. These eight keys represent two image store positions. Any of the keys within a group may be selected to store (or delete) the image for these positions.
  • Page 79: Special Format F3 - Slides

    Keypad Functions Special Format F3 - Slides The F3 Special Format option provides 35 mm landscape slides in a 12-up format (4 rows of 3 columns). Important Printed slides may not include all of the original image data. Do not use slides for primary diagnosis.
  • Page 80: Autoprint Printing

    User’s Manual Printing Pages To print a partial or complete page of images, press [Print] on the Keypad. Note You can continue storing or “printing” images even when the Printer is out of film or in an error condition. Autoprint Printing When the Autoprint function is enabled, the Printer will automatically send the Print request when all image positions have been stored on the selected format.
  • Page 81: Deleting Images Or Pages

    Keypad Functions Deleting Images or Pages Deleting Images If you are using a format for which the Position Store keys are active, press [Delete Image] once, and then press the specific Position Store key of the image to be erased. If the format selected does not illuminate the position store keys, you can delete images by pressing [Delete Image] twice.
  • Page 82: Program Options

    User’s Manual Program Options Overview Important Entering this mode could result in unintentionally changing image parameters and system set-up. The [Program] key on the Keypad allows access to the functions which do not have dedicated keys on the Keypad. Included in the functions of this key are the following items: •...
  • Page 83: Tone Scaling

    Keypad Functions Tone Scaling Tone scaling is a technique of making the printed images match the images on the input monitor. Caution Tone scale adjustments should only be done by trained personnel. Important Before doing a tone scale adjustment, verify that the monitor for the imaging device has been properly adjusted.
  • Page 84: Entering And Leaving The Program Function

    User’s Manual Entering and Leaving the Program Function To enter the Program Function, press [Program]. READY TO STORE IMAGE QUEUE:01 H126_2717BC The Program Menu will be displayed, and the numeric keypad will be active at this time. F1 WINDOW OPTIONS F2 PRINT OPTIONS F3 REPRINT OPTIONS F4 CONFIGURATION...
  • Page 85: Window Options

    Keypad Functions Window Options The Window Options Menu is the F1 selection of the Program Menu. It allows the user to change the window width, level, curve shape, or to print a curve series. F1 WINDOW WIDTH F2 WINDOW LEVEL F3 CURVE SHAPE F4 CURVE SERIES Important...
  • Page 86: Window Level

    User’s Manual Window Level To change the window level, press: [Program] [F1] [F2] The system will ask you to enter a window level value. Note The valid window level value range is between 0 and 4095. • The default value is 128. •...
  • Page 87: Curve Shape

    Keypad Functions Curve Shape To change the curve shape, press: [Program] [F1] [F3] The system will ask you to enter a curve shape value. Note The valid curve shape value range is between 0 and 6. The default value is 3. In some cases, the curve shape may be changed if images have already been stored on a page.
  • Page 88: Curve Series

    User’s Manual Curve Series The allows the user to select one image, print 6 curve shapes on one sheet of film, and then determine which image represents the desired optimal image appearance. Then, the number of the selected curve shape would be entered into the system by using the “Curve Shape”...
  • Page 89 Keypad Functions Curve Shapes 0 through 5 on 35 x 43 cm, 35 x 35 cm, and 11 x 14 in. film Figure 4–1 H027_0054AA 5B9615 4–19...
  • Page 90: Print Options

    User’s Manual Print Options Overview Before you can enter the Print Options Menu, there can be no images stored on the current page. To enter the Print Options Menu, press: [Program] [F2] The system will display the following menu. F1 INTERPOLATION F2 BORDER OPTION F3 TRIM OPTION F4 CONTRAST OPTION...
  • Page 91 Keypad Functions Border Option The Border Option allows the user to select black or clear borders for the non-image area. See also the Trim Option. The factory default for the Border Option is black. To change the border type, press: [Program] [F2] [F2]...
  • Page 92: Contrast Option

    User’s Manual Contrast Option To enter the Contrast Option Menu, press: [Program] [F2] [F4] The system will display the following menu: F1 CONTRAST F2 IMAGE DMIN F3 IMAGE DMAX F4 BORDER DMAX Image Dmin, Image Dmax, and Border Dmax The Printer can set the Image Dmin and Image Dmax for all of the images on a page. The Image Dmax must be less than or equal to the Border Dmax.
  • Page 93: Contrast

    Keypad Functions Contrast To change the contrast setting, press [Program] [F2] [F4] [F1] The system will prompt you to enter the contrast value. CONTRAST ENTRY CONTRAST: Note The valid range of contrast values is -5 to +5. The + means higher contrast and the - means lower contrast.
  • Page 94: Configuration

    User’s Manual Configuration To enter the Configuration Options Menu, there can be no images stored on the current page. The Configuration Options Menu allows you to access and change the following: • Autoprint • Audio Option • Rotation Option • Study Option To enter the Configuration Options Menu, press: [Program] [F4]...
  • Page 95: Audio Option

    Keypad Functions Audio Option The Audio menu selection allows you to specify a preference for audible feedback from the keypad. The options include: • no audible feedback • the “Store” tone sounds when you begin a Store command • the “Store” tone sounds when a Store command is completed •...
  • Page 96: Rotation Option

    User’s Manual Rotation Option This option allows you to have all images of a format rotate 90° clockwise. A rotation type (ON or OFF) is saved for each format. The default setting for each format is OFF. Note • The time required to store an image will increase when the rotation option is ON. •...
  • Page 97 Keypad Functions Rotation OFF Rotation ON common text 5B9615 4–27...
  • Page 98: Auxiliary Keypad

    Display Mode only. In others, the user may switch from Display Mode to Active Keypad Mode. Note Consult your Kodak representative for the modes available with your imaging device. Display Mode When the auxiliary keypad is attached in addition to the autofilming link, and the Laser Printer and imaging device are powered on, the following screen could appear on the keypad display.
  • Page 99 Keypad Functions Active Keypad Mode By pressing [F2] to make the Keypad active, the following screen displays. READY TO STORE IMAGE QUEUE:00 F2 TO SWITCH CONTROL The keypad features are: • Store availability depends on the imaging device • Print availability depends on the imaging device •...
  • Page 100 User’s Manual 4–30 5B9615...
  • Page 101: Section 5: Control Terminal

    Control Terminal Section 5: Control Terminal Table of Contents Description Page Overview The Main Menu Reaching the Main Menu Procedure Operational Mode Change Format Number of Copies Print Priority Rotation Interpolation Type Select Film Polarity Store Position Print a Page Delete Defined Delete a Position Delete a Page...
  • Page 102: Overview

    User’s Manual Overview The Control Terminal can be used to supplement autofilming or Keypad features for any device that sends commands to the Laser Printer. These features include Dmin and Dmax settings, contrast adjustment, and common text. Note Occasionally, an autofilming device will override a desired function that has been set up with the Control Terminal.
  • Page 103: The Main Menu

    Control Terminal The Main Menu Overview The Control Terminal Main Menu allows access to four groups of options: • Operational Mode Enter Format Enter Number of Copies Set Print Priority Set Rotation Enter Interpolation Type Select Film (size and base) Set Polarity Set Page Functions Return...
  • Page 104 User’s Manual • Change Destination Used for redirecting inputs (sources) to alternative Kodak Ektascan Laser Printers on a network. For details of this operation, refer to the User’s Guide for the Kodak Ektascan Network Interface for Laser Printer Interconnect. Caution Never press [Set Up] at the top right of the Control Terminal keyboard.
  • Page 105: Reaching The Main Menu

    Control Terminal Reaching the Main Menu Follow these steps to reach the Main Menu: [1] Verify that the Control Terminal is turned on. The ON/OFF switch is on the right side of the Terminal, with the Brightness and Contrast adjustments. [2] If the Display Screen is blank, press any key to display the Main Menu.
  • Page 106 User’s Manual [3] Specify that the Terminal is a WYSE terminal or a different type. TERMINAL TYPE MENU Kodak Control Terminal (WYSE) Kodak Service Engineering Terminal Enter Menu Item:1 [4] Specify that the Terminal is to be used for Laser Printer operations rather than service operations.
  • Page 107: Procedure

    Control Terminal Procedure To reach the Main Menu from the initial Terminal Type Menu, enter: 1. [1] and press [Enter]. 2. [1] and press [Enter]. 3. [n] (the menu number of the imaging device) and press [Enter]. The Main Menu and the name of the imaging device affected will be displayed. The name of the imaging device affected will be printed on the screen when each of the Main Menu suboptions are displayed.
  • Page 108: Operational Mode

    User’s Manual Operational Mode The following functions are available through the Operational Mode Menu. The values for most of these functions will be displayed on the screen in an area that is labeled “Current Settings.” • F1 Change Format • F2 Number of Copies •...
  • Page 109: Change Format

    Control Terminal Change Format All valid formats will be displayed when this function is selected. To enter an [F1] through [F3] format, type the letter “F” and the number. For example, press “F” and “1”. The [F1], [F2], and [F3] function keys above the normal keyboard area are not available whenever a prompt is active, so the two items must be typed.
  • Page 110: Store Position

    User’s Manual Store Position The default image store positions are from left to right and from top to bottom. The “STORE” command default will be in the next available position, but images can be stored in any available position. The page diagram will be updated continuous to reflect the positions that have a stored image.
  • Page 111: Image Setup

    Control Terminal Image Setup Overview The following functions are available through the Image Setup Menu: • F1 Window Width • F2 Window Level • F3 Border • F4 Trim • F5 Contrast • F6 Image Dmin • F7 Image Dmax •...
  • Page 112: Common Text

    User’s Manual Common Text Main Menu item number 4, “Common Text Setup,” allows the specification of text that will be printed across the bottom of all films for that imaging device. It consists of 1 line of up to 80 characters, centered on the bottom of the film. The text can contain: •...
  • Page 113: Update Text

    Control Terminal Update Text If [F1] is selected, you can retype each line of text and then press [Enter]. In the process, change whatever items are necessary. Once [Enter] is pressed for a line, the system moves to the next line. Important The store date and time macros (%STORDAT%,%STM%, and%STORE_TIME%) print the dates and times that the Printer saved the images.
  • Page 114: Change Destination

    User’s Manual Change Destination Refer to the User’s Guide for the Kodak Ektascan Network Interface. Troubleshooting the Control Terminal Blank Display Screen If a terminal is not used for several minutes, the screen will become blank to protect the screen from “burning in” the characters. When the screen is blank, use the following sequence to refresh the screen: 1.
  • Page 115: Locked Screen

    Control Terminal Locked Screen If the user inadvertently presses [Ctrl and the letter “S,” the display terminal will appear to “lock” and not respond. This is a command that stops the screen from scrolling to allow a user to see a single screen of information. If this happens, press [Ctrl] and the letter “Q”...
  • Page 116 User’s Manual 5–16 5B9615...
  • Page 117: Section 6: Calibrating The 2180 Laser Printer

    Calibrating the 2180 Laser Printer Section 6: Calibrating the 2180 Laser Printer Table of Contents Description Page Overview General Information When to Calibrate Calibrating the 2180 Laser Printer Using a Stored Calibration Table Performing the Calibration Calibrate Printer Screen Calibration Data Entry Screen Checking Calibration Calibration Results Film 5B9615...
  • Page 118: Overview

    User’s Manual Overview General Information Calibration is a method of ensuring consistent image appearance, despite differences in film emulsions and variations in Processor chemistry. Images can be stored and printed at any time during calibration. If calibration takes place while the Laser Printer is printing, the new calibration takes effect only when all copies of the current page have finished printing.
  • Page 119 Calibrating the 2180 Laser Printer USE FOR CALIBRATION General CT1 12:03:06 15-May-92 Rochester, NY calibration test film NOT FOR CALIBRATION General CT1 12:03:06 15-May-92 Rochester, NY calibration results film H126_2721CC 5B9615 6–3...
  • Page 120 User’s Manual When to Calibrate The Kodak Ektascan 2180 Laser Printer is designed to produce consistent, high quality images on film. To maintain optimum image quality, the Laser Printer should be re-calibrated when changing: • film emulsion • the chemistry, Processor temperature, or changing Processors To determine whether the emulsion number has changed, read the label on the side of the box of film.
  • Page 121: Calibrating The 2180 Laser Printer

    Calibrating the 2180 Laser Printer Calibrating the 2180 Laser Printer Using a Stored Calibration Table Caution Successful entry of new calibration data for a calibration table results in the loss of existing data for that table. Performing the Calibration [1] Check that the Printer, and the Processor, if one is attached, is warmed up. [2] Access the Other Functions Screen.
  • Page 122 User’s Manual Calibrate Printer Screen CALIBRATE PRINTER Printing Film type: 35 x 43B To: Receive mag Site 3 Last done: 14-Oct-95 20:37 Change Film Type Change Destination Print Calibration Film Read Calibration Film Enter Density Data Return Select Film Type and Dest; Print Film;...
  • Page 123 Calibrating the 2180 Laser Printer [3] Process the film and check that the information on the screen matches the destination printed on the film and the film type. If the information does not match, use [F1] and [F2] to select the correct values. The Calibration Test Film will look like the following illustration.
  • Page 124 User’s Manual [5] Press [F4] to read the Calibration Test Film. The Printer will: • Clear all commands and change the prompt to “Please wait.” • Change the prompt to “Slide calibration film through the densitometer.” densitometer calibration test film H126_0022ACB H126_0022AA You must slide the calibration film through the Densitometer within about 15 seconds.
  • Page 125 Calibrating the 2180 Laser Printer Calibration Data Entry Screen You may use another Densitometer instead of the built-in Densitometer that is on the front of the 2180 Laser Printer to measure the density values of the Calibration Test Film. If so, you should follow these steps to enter the density data into the Printer at the Control Panel.
  • Page 126 User’s Manual Checking Calibration You may check the calibration by printing the Calibration Results Film from the Print Test Films Screen. Calibration Results Film You may verify that the calibration was successful by checking the density of steps 1 - 9. They should be in equal increments. NOT FOR CALIBRATION General CT1 12:03:06 15-May-92 Rochester, NY...
  • Page 127: Section 7: Study Reprinting

    Study Reprinting Section 7: Study Reprinting Table of Contents Description Page In This Section General Information Study Reprinting From the Main Control Panel Manage Study Reprinting Reprint Study Protected or Unprotected Studies Keypad Overview Storing Studies at the Keypad Reprint Options Study Options Sorting Options Selecting and Reprinting Images...
  • Page 128: In This Section

    Main Control Panel,” page 7–4. • Keypad This is an option that may be purchased separately. Please contact your Kodak Sales Representative for further details. See “Study Reprinting From the Keypad,” page 7–10. For detailed information on study reprinting, see the “KEYPAD Study Reprinting”...
  • Page 129 Study Reprinting To select studies for reprinting from the: • Control Panel First select the source and then the particular study by date and time. • If a single source has been selected, only the studies from that source will be available.
  • Page 130: Study Reprinting From The Main Control Panel

    User’s Manual Study Reprinting From the Main Control Panel Manage Study Reprinting You can access a patient study for reprinting from the Main Control Panel. Select [F2] to access Manage Study Reprinting. CONTROL PRINTER Ready Supply 35 x 43B Supply 8 x 10C Receive mag Processor...
  • Page 131 Study Reprinting MANAGE STUDY REPRINTING 42 Studies Printing SOURCE: STUDIES Manage Selected Source Manage All Sources Return Select Source and Manage or Manage All Sources, H126_9110AC For up to 5 sources, the Printer Screen Displays: • Source - a 5 character name for the imaging device. The Printer Display “~~~~~” sorts if a source name is not defined for that source.
  • Page 132 User’s Manual The display is updated as studies are added or deleted. If there are no closed studies, the scroll bar and all commands except “Return” are cleared. MANAGE STUDIES 5 Studies Printing 00012345689 PROT 10-Jan-95 10:32 00012345678 UNPROT 10-Jan-95 8:02 Reprint Study Unprotect Study...
  • Page 133 Study Reprinting Reprint Study Select [F3] Reprint Study from the Manage Studies screen. Reprinting a study will send a job to the print queue. When “Reprint Study” is selected, the Printer displays the study selected for reprinting. Upon entering this screen, the copy count defaults to 1, and the print priority to Norm. Copy count can be from 1 to 255.
  • Page 134 User’s Manual Protected or Unprotected Studies Studies can be protected or unprotected. Protected studies will never be deleted automatically. Unprotected studies will be deleted when necessary to make space for new studies to be stored. MANAGE STUDIES 5 Studies Printing 00012345689 PROT 10-Jan-95...
  • Page 135 Study Reprinting If a protected study is selected and the [F4] key is selected, or if the [F5] key is selected from the Manage Studies screen, the Unprotected Study Confirm screen is accessed to confirm your selection. UNPROTECT STUDY CONFIRM 5 Studies Printing 00012345689...
  • Page 136: Keypad

    User’s Manual Keypad Overview You can display sorted information, and reprint a study at the Keypad. See the illustration below to review the Keypad. READY TO STORE IMAGE QUEUE:01 H126_2713BC Options available at installation include: • Study#, Page # • dd mm yyyy, mm dd yyyy, yyyy mm dd •...
  • Page 137 Study Reprinting which may be a patient’s Social Security number or any unique number. The study number must be numerical and not exceed 11 characters. The form of the study number is determined by the hospital and configured by the service provider when the system is installed.
  • Page 138 User’s Manual Reprint Options The Reprint Options Menu is the F3 selection of the Program Menu. This menu allows the user to reprint images that are stored as pages or studies. F1 STUDY OPTIONS F2 SORTING OPTIONS F3 REPRINT OPTIONS F4 UNAVAILABLE Study Options Study Options allows you to set up all sources or a single source for searching for...
  • Page 139 Study Reprinting Sorting Options Sorting Options allows you to set up defaults that define how the studies will be organized and displayed for reprinting. Default sort options include: • Study# — A unique number, up to 11 digits in length, which identifies a page or a study.
  • Page 140 User’s Manual Selecting and Reprinting Images When you search for a study using “Select”, the data will display in the order that you have indicated on the “Select” screen. The “Select” feature allows you to define the order of the display for this search only. The default sorting options set up in the “Sorting Options”...
  • Page 141 Study Reprinting Note If you enter a date that is invalid, the message “Invalid Date; Please Re-enter” displays. The “Study# Entry” screen displays. [6] After you type the date, press [E]. The “Time Selection” screen displays. [7] Enter [F1] for AM or [F2] for PM. The “Time Entry” screen displays. [8] Type the time of the study you want to reprint, and press [E].
  • Page 142 User’s Manual [10] From either of the screens shown above, press [F1]. The following screen displays. PRESS F1 TO REPRINT LAST STUDY F2 REPRINT OPTIONS, OTHER KEYS TO EXIT [11] Press [F2] “Reprint Option” to reprint a previous study for reprinting. The following screen displays.
  • Page 143: Section 8: Troubleshooting And Error Messages

    Section 8: Troubleshooting and Error Messages Table of Contents Description Page Troubleshooting Film Transport Film Transport with a Kodak X-Omat 180 LP or 180 LPS Processor Film Transport with Receive Magazine Film Jams Error Messages General Information Show Error Log Screen...
  • Page 144: Troubleshooting

    User’s Manual Troubleshooting Overview This section will provide suggestions for what to do if problems arise. After an overview of the path that the film takes through the 2180 Laser Printer, this section will give you guidelines for clearing film jams. In order to clear film jams, you must open the Film Door of the Printer.
  • Page 145: Film Transport

    Troubleshooting and Error Messages Film Transport Overview The Transport Films function can be selected from the Other Functions Screen to move film through the Printer and Processor without printing on the film. This may be used for processing a pre-exposed sensitometric film, to clear out fogged films from the Supply Magazine, or to move preprinted films to the Processor.
  • Page 146 User’s Manual Film Transport with a Kodak X-Omat 180 LP or 180 LPS Processor The Picker Assembly picks up a piece of film from one of the two Supply Magazines, and the Elevator lifts the Picker and the film up to the Registration Assembly. The film is squared on the Registration Table and pushed to the left.
  • Page 147 Troubleshooting and Error Messages Film Transport with Receive Magazine This view shows the film path without a docked 180 LP or 180 LPS Processor. The exposed film goes to an internal Receive Magazine. H126_0707GA 5B9615 8–5...
  • Page 148 User’s Manual Film Jams If a film jam occurs, the Display Screen of the Control Panel will display a message to tell you where to look. Inside the Film Door is a label which suggests where to look for film jams. registration assembly chute assembly picker assembly...
  • Page 149 Troubleshooting and Error Messages Film jams may occur in the following places: • the Picker Assembly • the Registration Assembly • the Chute Assembly The illustrations on the following pages identify each of these areas. picker assembly H126_0724GCA H126_0724GA 5B9615 8–7...
  • Page 150 User’s Manual Check the Picker Assembly for film jams. [1] Press down to lower the Film Pocket. [2] Carefully raise the Picker. [3] Check the Supply Magazine. Any exposed film must be destroyed. [4] Check the Receive Magazine. If film is partly in the Receive Magazine, close the Printer door and press “Start Printing”...
  • Page 151 Troubleshooting and Error Messages registration assembly Supply Magazines H126_0725CCA H126_0725CA 5B9615 8–9...
  • Page 152 User’s Manual [7] Open the Chute Door to check the Chute and Diverter Assemblies for film jams. If the film is stuck in the rollers, pull it out. chute assembly chute door diverter assembly H126_0726GCA H126_0726GA Caution If film has gone partly into the Processor, open the lid of the Processor and pull the film out through the Processor and not back through the Printer.
  • Page 153: Error Messages

    Troubleshooting and Error Messages Error Messages General Information Error Messages for the 2180 Laser Printer and the 180 LP or 180 LPS Processor display on the Display Screen that is located on the Laser Printer. Show Error Log Screen Press [F1] from Show Printer Info Screen to display the Show Error Log Screen SHOW PRINTER INFO Printing Service:...
  • Page 154 User’s Manual SHOW ERROR LOG Ready 15-Oct-95 07:32:58 E132 Receive magazine full Access Magazines to empty the receive mag and Start Printing to resume. Show Previous Message Show Next Message Return Select the desired function. H126_9042AC The Printer displays the error log of the message number and the latest message in reverse chronological order.
  • Page 155 Troubleshooting and Error Messages Error Recovery The screen displays when the Printer detects an error. The screen that is currently displayed is suspended. You will be able to view the error message(s). To exit, you have 2 choices: • Select “Return”. The suspended screen resumes at the point it was suspended.
  • Page 156 User’s Manual Error Recovery Screen ERROR RECOVERY 1 more Not printing 21-Aug-95 07:32:58 E285 Film Jam in Printer Access Film Path and clear film supply path. Remove supply mag- azine and fan film in darkroom. Show Next Message Skip to Last Message Exit to Control Printer Return Select the desired function.
  • Page 157: Preventive Maintenance

    Preventive Maintenance Cleaning and Sterilization The Kodak Ektascan 2180 Laser Printer is not to be cleaned by immersion nor sterilized by autoclaving. Do not wash in a manner allowing fluid to flow freely over the external surfaces. To properly sterilize or clean: •...
  • Page 158 User’s Manual Maintaining the Densitometer The Reference Strip is used to calibrate the Densitometer on the front of the 2180 Laser Printer. The Densitometer is calibrated at installation time, but the Reference Strip can be used periodically to check that the Densitometer is still properly calibrated. A Reference Strip is delivered with each Printer.
  • Page 159 Troubleshooting and Error Messages Press [F3] at the Other Functions Screen to Read the Reference Strip. OTHER FUNCTIONS Ready 15-Oct-95 09:26 Manage Print Queue Show Printer Info Read Reference Strip Print Test Films Show More Functions Return Select the desired function. H126_9045AC When the [F3] function key is pressed, the Printer changes the prompt to “Please wait,”...
  • Page 160 User’s Manual densitometer reference strip H126_0023ACA H126_0023AA You must slide the Reference Strip through the Densitometer within about 15 seconds. Use an even, sweeping motion when sliding through the Densitometer. When you slide the Reference Strip through the Densitometer, the Printer displays the message, “Densitometer calibration successful.”...
  • Page 161: How To Contact Service Personnel

    Return Select the desired function. H126_9046AC [1] Call the Kodak System Response Center for assistance. The Show Printer Info Screen displays the correct number. [2] Be prepared to leave a message and the K number for your system. A Service Representative will contact you to get more information about the nature of your system problems and take necessary actions to get your Printer working again.
  • Page 162 User’s Manual 8–20 5B9615...
  • Page 163 Quick Reference Guides Section 9: Quick Reference Guides Flowchart for Operator Interface Screens KEYPAD Study Reprinting Features Flowchart 5B9615 9–1...
  • Page 164 User’s Manual 9–2 5B9615...
  • Page 165: Section 10: Safety Information For The 180 Lp Or 180 Lps Processor

    Safety Information for the 180 LP or 180 LPS Processor Section 10: Safety Information for the 180 LP or 180 LPS Processor Read and understand all instructions before using. Warning This equipment is not intended to be located in the patient’s vicinity. Caution This device is intended for use only by professional, trained personnel.
  • Page 166 Warning DO NOT use an extension cord to power the processor. Connect this equipment to a grounded outlet. Refer to the Site Specifications for the Kodak Ektascan 2180 Laser Printer and the Kodak X-Omat 180 LP Processor for additional details.
  • Page 167: Section 11: Processor Overview

    Processor Overview Section 11: Processor Overview Table of Contents Description Page Introduction General Information Control Processor Screen Process Information for the 180 LP or 180 LPS Processor Processor Configuration and Setpoints Using the Access Code Processor Setup Access Screen 5B9615 11–1...
  • Page 168: Introduction

    Receive Magazine to be processed in a remote Processor. The Kodak X-Omat 180 LPS Processor has a 9 Bin Film Sorter installed at the factory. To improve productivity, each Sorter Bin usually receives films from a particular imaging device connected to the Laser Printer.
  • Page 169: Control Processor Screen

    Control Processor Screen The user selects, changes, and monitors processing variables for the Processor through the Control Processor Screen at the Display Screen for the Kodak Ektascan 2180 Laser Printer. Select [F4] at the Other Functions Screen to see the Control Processor Screen.
  • Page 170 User’s Manual error description field Processor status field CONTROL PROCESSOR Processor Ready Processor Error: Exxx Dev: temp=100.0F Set=100.0F Fix: temp=100.0F Set=100.0F Dry: temp=119.5F Set=120.0F Increase Dry Set Decrease Dry Set Setup Processor Override Error Return Select the desired function. prompt lines commands H126_9048GCA H126_9048GC...
  • Page 171 Processor Overview Processor Error Messages are listed and described in Section 18 on page 18–15. If the Processor Status line does not show that the Processor is off-line, then the Developer, Fixer, and Dryer actual temperatures and temperature setpoints are displayed.
  • Page 172: Process Information For The 180 Lp Or 180 Lps Processor

    Replenishment and Kodak X-Omat Fixer Replenishment, or equivalents, may be used. Contact your Kodak Representative to discuss the best option for your needs. Throughput is the number of 35 x 43 cm sheets of film that can be processed in one hour.
  • Page 173: Processor Configuration And Setpoints

    Processor Overview Processor Configuration and Setpoints Setup information consists of the film processor configuration and process setpoints. Setup information that was preset at the factory is listed below. Setup information is stored in battery backed-up RAM (Random Access Memory). Therefore, you do not need to program new values every time that you turn on the Processor.
  • Page 174: Using The Access Code

    User’s Manual Using the Access Code Only the Service Representative and the Key Operator should use the access code. The access code 4213 is necessary to change setup information that is preset at the factory (like default settings). The access code is not necessary to change the Dryer temperature.
  • Page 175: Processor Setup Access Screen

    Processor Overview Processor Setup Access Screen PROCESSOR SETUP ACCESS Processor Ready XXXX Cancel Request Enter access code or cancel request. H126_9050AC The Control Panel Function keys [F1] through [F4] represent the numbers 1 through 4, respectively, and must be pressed in the order of the access code. For each number entered, an X is displayed in the Data Section of the screen.
  • Page 176 User’s Manual Press [F6] to cancel the request and return to the previous screen. PROCESSOR SETUP Processor Ready Cycle is Rapid Replenishment Mode is Auto Change Replen Mode Setup Process Dev Replen Calibration Fix Replen Calibration Return Select the desired function. H126_9051AC 11–10 5B9615...
  • Page 177: Section 12: Mixing The Chemistry

    Mixing Chemistry Section 12: Mixing Chemistry Mixing the Chemistry Warning Wear protective eyewear when mixing the chemistry. Important When mixing chemistry, follow all instructions and precautions that are provided with the chemicals. Mix only a 2-week supply of developer and fixer replenishment. Following all directions provided with the solutions, mix at least 19 liters (5 gallons) of solution.
  • Page 178 User’s Manual 12–2 5B9615...
  • Page 179: Section 13: Setting Up The Processor

    Setting Up the Processor Section 13: Setting Up the Processor Table of Contents Description Page Processor Configuration Automatic Replenishment Mode Flooded Replenishment Mode Tank Fill Mode Disable Replenishment Selecting a Replenishment Mode Procedure Automatic Replenishment Mode Flooded Replenishment Mode Calibrating the Replenishment System Changing Setpoints Standby Mode Display Units...
  • Page 180: Processor Configuration

    User’s Manual Processor Configuration Automatic Replenishment Mode Select this mode when you want the Processor to automatically adjust the replenishment volumes for developer and fixer according to the film usage for the Processor. See “Replenishment Mode” in this section. Flooded Replenishment Mode Select this mode when the film usage for the Processor is only 1 or 2 sheets of film ⁄...
  • Page 181: Selecting A Replenishment Mode

    Setting Up the Processor Selecting a Replenishment Mode Procedure Changes to the replenishment volume will be stored until new changes are made. Replenishment mode is Automatic or Flooded. [1] To select a replenishment mode, press [F4] at the Other Functions Screen to see the Control Processor Screen.
  • Page 182 User’s Manual [2] Press [F3] at the Control Processor Screen to display the Processor Setup Access Screen. PROCESSOR SETUP ACCESS Processor Ready XXXX Cancel Request Enter access code or cancel request. H126_9050AC 13–4 5B9615...
  • Page 183 Setting Up the Processor [3] Enter the four-digit Access Code. PROCESSOR SETUP Processor Ready Cycle is Rapid Replenishment Mode is Auto Change Replen Mode Setup Process Dev Replen Calibration Fix Replen Calibration Return Select the desired function. H126_9051AC 5B9615 13–5...
  • Page 184 User’s Manual [4] Press [F2] to change the replenishment mode. PROCESSOR REPLENISHMENT MODE Processor Ready Replenishment Mode is Flooded Select Auto Fill Tanks Disable Replenishment Return Select the desired function. H126_9052AC [5] If the Replenishment Mode is Flooded, and you want to change it to Auto, press [F1] to select Auto Replenishment Mode.
  • Page 185 Setting Up the Processor Automatic Replenishment Mode This is the standard replenishment mode of the Processor. In this mode, replenishment will occur under 2 conditions: • The replenishment cycle is activated each time approximately 1500 cm (238 in. of film has been processed. This is equivalent to one 35 x 43 cm (14 x 17 in.) sheet of film.
  • Page 186 User’s Manual Flooded Replenishment Mode In the Flooded Replenishment Mode, the preset values for developer and fixer replenishment volumes are: • 65 mL every 5 minutes. • 65 mL for each 1500 cm (238 in. ) of film. If you wish, you may change the setup information by using the function keys on the display panel.
  • Page 187 Setting Up the Processor Press [F2] to select the Flooded Replenishment Mode when the film usage for the ⁄ processor is only 1 or 2 sheets of film during a hour period. Replenishment will be added automatically: • every 5 minutes, achieving a minimum replenishment of 780 mL/hr during the processor operation.
  • Page 188: Calibrating The Replenishment System

    User’s Manual Calibrating the Replenishment System Procedure Important Calibrate the replenisher pumps every 3 months. Calibration of the replenishment system will determine the actual rate of solution flow through the Replenishment Pumps for a given period of time. Measure the volume of solution that is delivered by the system, then use the Display Panel to enter the measurement into the microprocessor.
  • Page 189 Setting Up the Processor [4] Press [F4] to calibrate the replenishment of the developer, or press [F5] to calibrate the replenishment of the fixer. PROCESSOR REPLENISHMENT CAL Processor Not Ready Processor Error: E130 Dev replen cal switch enabled Dev Cal Volume = 62ml Increase Decrease Return...
  • Page 190 User’s Manual developer replenishment hose fixer replenishment hose replenishment calibration switch filter mandrels graduated cylinder H127_0072CCB H127_0072CA 13–12 5B9615...
  • Page 191 Setting Up the Processor Warning Wear protective eyewear when following this procedure. Replenishment solutions are pumped quickly and may splash. [5] Follow the directions at the bottom of the screen. When this screen is displayed, the Replenishment Calibration Switch is enabled for the procedure that is described below.
  • Page 192: Changing Setpoints

    User’s Manual Changing Setpoints This procedure explains how to change processor variables whose setpoints were preset at the factory. In most cases, factory setpoints will provide optimum film processing. [1] Press [F4] at the Other Functions Screen to see the Control Processor Screen. CONTROL PROCESSOR Processor Ready Processor Error: E134...
  • Page 193 Setting Up the Processor [2] Press [F3] at the Control Processor Screen to display the Processor Setup Access Screen. [3] Enter the four-digit Access Code. PROCESSOR SETUP Processor Ready Processor Error: E134 Cycle is Rapid Replenishment Mode is Auto Change Replen Mode Setup Process Dev Replen Calibration Fix Replen Calibration...
  • Page 194 User’s Manual [4] Press [F3] at the Processor Setup Screen to display the Processor Setpoints Screen. PROCESSOR SETPOINTS Processor Ready Processor Error: E134 Cycle is Rapid Replenishment mode is Auto Dev Temp Setpoint = 95.0F Increase Setpoint Decrease Setpoint Default Setpoint Next Setpoint Return Select the desired action.
  • Page 195 Setting Up the Processor Press [F4] to change the current processor parameter that is displayed to the next parameter. This parameter can be modified by function keys [F1] through [F3]. The processor setpoints display in the following order: • developer temperature setpoint •...
  • Page 196: Standby Mode

    User’s Manual Standby Mode If the 180 LP or 180 LPS Processor doesn’t receive film for approximately 60 seconds after the last film has exited, the Processor will enter standby mode. When the Processor goes into standby mode, the following events occur: •...
  • Page 197: Section 14: Operating Instructions

    Operating Instructions Section 14: Operating Instructions Table of Contents Description Page Start-Up Adjusting Dryer Temperature Shutdown 5B9615 14–1...
  • Page 198: Start-Up

    User’s Manual Start-Up Procedure [1] Turn on the water supply to the Processor. [2] Check that the Processor Cover is closed. Note The Replenisher Pumps start automatically when the Processor is turned on. [3] Turn on the power for the Processor by moving the main wall circuit breaker to the ON position.
  • Page 199 Operating Instructions Processor main power switch H126_0703ACB H126_0703AA Note If an image is sent to the Printer before the chemistry in the Processor has reached the correct temperature, the image will remain in the printer queue until the Processor becomes ready. 5B9615 14–3...
  • Page 200: Adjusting Dryer Temperature

    User’s Manual Adjusting Dryer Temperature Procedure CONTROL PROCESSOR Processor Ready Dev: temp=100.0F Set=100.0F Fix: temp=100.0F Set=100.0F temp=119.5F Set=120.0F Dry: Increase Dry Set Decrease Dry Set Setup Processor Return Select the desired function. H126_9059AC Press [F1] to increase the dryer setpoint in increments of 1° Fahrenheit (or 1° Celsius). Press [F2] to decrease the dryer setpoint in increments of 1°...
  • Page 201: Shutdown

    Operating Instructions Shutdown Procedure [1] Wait for all films to be printed. You can check the Print Queue Screen or Control Printer Screen on the Printer to make sure that images are not being printed, or in the printer queue. [2] Turn off the Processor by moving the Main Power Switch to the “0”...
  • Page 202 User’s Manual 14–6 5B9615...
  • Page 203: Section 15: Preventive Maintenance

    Preventive Maintenance Section 15: Preventive Maintenance Table of Contents Description Page Overview Weekly Monthly 5B9615 15–1...
  • Page 204: Overview

    User’s Manual Overview Reliable operation of the Processor requires that all parts are cleaned and adjusted correctly on a regular basis. The following procedures should be followed to keep your system in good working order. 15–2 5B9615...
  • Page 205: Weekly

    Preventive Maintenance Weekly Procedure The following procedure should be performed every week. Warning DANGER. HIGH VOLTAGE. This equipment is operated with hazardous voltage which can shock, burn, or cause death. Do not try to open the Processor or remove the Panels of the Processor except for the Top Cover.
  • Page 206 User’s Manual Warning Wear rubber gloves, safety glasses, and protective clothing when doing any maintenance on the 180 LP or 180 LPS Processor. [4] Lift the Top Cover of the Processor. Caution Handle all Racks carefully to prevent changing their alignment or causing damage. Do not clean the Racks, Crossover Assembly or Squeegee Rollers with abrasive materials.
  • Page 207 Preventive Maintenance detector crossover assembly "D" washer developer "F" rack washer developer fixer crossover wash rack fixer rack dryer rack fixer/wash crossover H127_0147GCA H127_0147GA 5B9615 15–5...
  • Page 208 User’s Manual "DF" crossover washer "FW" H127_0148GCA crossover washer H127_0148GA [10] Install the Wash Rack, Crossover Assemblies, and Wet Section Cover in the correct positions in the Processor, and check that each Assembly seats firmly. Looking closely at the following illustrations and the front ends of the Racks, you will notice that there are letters on the Washers.
  • Page 209 Preventive Maintenance [12] After all Racks have been cleaned and returned to their proper positions in the Processor, move the main wall circuit breaker for the Processor to the ON position. [13] Turn on the Processor by moving the Main Power Switch to the “|” position. Note The Replenisher Pumps start automatically when the Processor is turned on.
  • Page 210: Monthly

    User’s Manual Monthly Procedure In addition to the preventive maintenance procedure that should be followed every week, the following procedure should be performed every month. Follow the shutdown procedure and turn off all electrical power to the Processor before performing preventive maintenance. [1] Turn off the Processor by moving the Main Power Switch to the “0”...
  • Page 211 Preventive Maintenance [8] Clean the Detector Crossover Assembly with a soft fiber brush and warm water. Allow the Detector Crossover Assembly to air dry before processing film. [9] Check that all Rollers on all Racks rotate freely. [10] Check to be sure that the Racks and Crossover Assemblies are square by doing the following procedure.
  • Page 212 User’s Manual Removal of the Developer Filter Figure 15–1 replenisher hose mandrel developer filter H127_0135GCA H127_0135GA [15] Change the Developer Filter each month. Follow these steps to change the Developer Filter. (a) Check that all electrical power to the Processor is OFF. (b) Lift the Top Cover of the Processor.
  • Page 213 Preventive Maintenance level sensor housing mandrel assembly H127_0061CCA H127_0061CA (e) Press the clip on the Level Sensor Housing and remove the Mandrel Assembly by pulling straight up. (f) Remove the Wing Nut from the Mandrel Assembly and the Developer Filter from the Mandrel Assembly.
  • Page 214 User’s Manual (g) Reverse the procedure to install the new Developer Filter. Note Contact your Service Representative for the 3 Month Preventive Maintenance Procedures. 15–12 5B9615...
  • Page 215: Section 16: Using A 21-Step Gray Scale For Processor Quality Assurance

    Description Page Overview Printing the 21-Step Gray Scale Setting Up the Kodak Process Control Densitometer Entering Density Data into the Kodak Process Control Densitometer Items Needed for Processor Quality Assurance Establishing the Baseline Determining the Speed Index Determining the Base+Fog Value...
  • Page 216: Overview

    Kodak Process Control Densitometer. The 21-step gray scale can also be used for manual quality assurance checks of the Processor. In most cases, the Processor will be a Kodak X-Omat 180 LP or 180 LPS docked to the 2180 Laser Printer. Printing the 21-Step Gray Scale Important The 21-step gray scale is used only for processor quality assurance.
  • Page 217: Setting Up The Kodak Process Control Densitometer

    Rochester, NY H126_0032AA Setting Up the Kodak Process Control Densitometer For complete instructions on setting up the Kodak Process Control Densitometer, refer to the Operation Manual for the Kodak Process Control Densitometer, Publication Part Number 635933, available from X-Rite (616) 534-7663.
  • Page 218: Entering Density Data Into The Kodak Process Control Densitometer

    If the Densitometer is connected to an appropriate Printer, the data can be sent to the Printer. Refer to Section 3.3 of the Operation Manual for the Kodak Process Control Densitometer, Publication Part Number 635933, for further information on sending data.
  • Page 219 Using a 21-Step Gray Scale for Processor Quality Assurance Kodak Process Control Densitometer test pattern film stop U S E F O R C A L I B R A T I O N H126_0031CCA H126_0031CA 5B9615 16–5...
  • Page 220: Items Needed For Processor Quality Assurance

    The following items are needed for processor quality assurance: • Kodak Process Control Densitometer, or alternative densitometer • Thermometer (not mercury) • Control charts for recording process control data or Kodak Process Control Densitometer with an appropriate printer • Fresh box of Kodak Ektascan HN Laser Film The laser film that is routinely used in the Printer can be used, but the emulsion number must be tracked.
  • Page 221: Establishing The Baseline

    • The Processor is filled with correctly mixed fresh chemicals. • The correct developer temperature and replenishment rates have been set. [2] Set aside a fresh box of Kodak Ektascan HN Laser Film. Designate it as the Quality Control (“QC”) film and record the emulsion number.
  • Page 222: Determining The Speed Index

    [3] Record the average CUDP value on the control chart. Note For users of the Kodak Process Control Densitometer, it is recommended that the preset value of “Dmax” be changed to the CUDP value to more accurately describe the variable being monitored.
  • Page 223: Developer Temperature

    Using a 21-Step Gray Scale for Processor Quality Assurance Developer Temperature [1] Record the developer temperature recommended by the film manufacturer for your: • type of film • developer (chemicals) • Processor • length of developer immersion time [2] Record this value on the control chart. Establishing Operating Limits [1] The operating limits for the following processor variables are ±0.15: •...
  • Page 224: Evaluating The Control Chart

    • developer starter added Crossover Procedure [1] Perform a crossover procedure when the new Kodak Ektascan HN Laser Film used has an emulsion number different from that of the previously used “QC” film. [2] On the same day, at the same time, expose the 21-step gray scale and process 5 films from the existing box of “QC”...
  • Page 225: Final Comments

    Using a 21-Step Gray Scale for Processor Quality Assurance Final Comments [1] It is recommended that a maintenance log be kept for the Processor and 2180 Laser Printer to record all service on the units. This log can be used to correlate system service with system performance.
  • Page 226 User’s Manual 16–12 5B9615...
  • Page 227: Section 17: Kodak X-Omat 180 Lp Or 180 Lps Sorter Kit

    Kodak X-Omat 180 LP or 180 LPS Sorter Kit Section 17: Kodak X-Omat 180 LP or 180 LPS Sorter Kit Table of Contents Description Page Introduction General Information Using the Control Panel Clearing Film Jams Sorter Error Messages Displayed on the Display Screen...
  • Page 228: Introduction

    Introduction General Information The Kodak X-Omat 180 LP or 180 LPS Sorter Kit is installed onto an existing Kodak X-Omat 180 LP or 180 LPS Processor. The Kodak X-Omat 180 LPS Processor is a Processor that has the Sorter installed at the factory. The Sorter has 9 Bins with a capacity to hold 50 films each and accepts all film sizes, including mixed film sizes.
  • Page 229 Kodak X-Omat 180 LP or 180 LPS Sorter Kit The operator can sort by Bin or by Study. Sort by Bin allows the operator to assign a separate Bin for each imaging device. Sort by Study allows the operator to assign a separate Bin for each Study.
  • Page 230: Using The Control Panel

    User’s Manual Using the Control Panel To assign Processor Sorter Bins: [1] Select [F4] Other Functions at the Control Printer screen. [2] Select [F5] to Show More Functions. [3] Select [F5] again to Show More Functions. This will access the Other Functions screen.
  • Page 231 Kodak X-Omat 180 LP or 180 LPS Sorter Kit Assign each Bin to the imaging device that you select and write the name of the imaging device on the paper insert on the front of the Bin. H127_2000GA Select [F3] from the Other Functions screen to access the Assign Processor Sorter Bins screen.
  • Page 232 User’s Manual There is no limit to the number of Bins assigned for each source. If a Bin is full and no other Bin is assigned, empty the Bin so that a film jam will not occur. Bin capacity is 50 films.
  • Page 233 Kodak X-Omat 180 LP or 180 LPS Sorter Kit The Assign Bin Confirm screen will appear if a Bin has already been assigned to a source. You have the option to make the Bin assignment or not. ASSIGN BIN CONFIRM...
  • Page 234: Clearing Film Jams

    User’s Manual Clearing Film Jams Important Do not place the Bin Assembly on top of the Laser Printer. To clear a film jam: • Remove any films in the Bin and then lift the Bin Assembly from the Processor. • If a film is protruding from the Sorter mechanism, pull up on the film to remove it. •...
  • Page 235 Kodak X-Omat 180 LP or 180 LPS Sorter Kit The following illustration shows the top of the 180 LPS Processor with the Bins removed. H127_2001GA 5B9615 17–9...
  • Page 236 User’s Manual The following illustration shows the bottom of the Sorter mechanism with the Access Door open. H127_2002GA 17–10 5B9615...
  • Page 237 Kodak X-Omat 180 LP or 180 LPS Sorter Kit The following illustration shows the Processor Cover opened to allow films to transport to the Tray. access door tray H127_2003GCA H127_2003GA If the film cannot be cleared, call your Service Representative. The Processor can still operate with the Processor Cover open, allowing films to go into the Tray and bypassing the Sorter.
  • Page 238: Sorter Error Messages Displayed On The Display Screen Of The Laser Printer

    User’s Manual Sorter Error Messages Displayed on the Display Screen of the Laser Printer E080 Sorter Bin Ay Not Sensed Replace/reseat processor sorter bin assembly or open processor cover to use film bypass tray. E081 Film Bypass Tray Not Sensed Replace/reseat processor film bypass tray or close processor cover and install bin assembly.
  • Page 239: Section 18: Appendix

    Appendix Section 18: Appendix Table of Contents Description Page Appendix A - Setting Up Supply Magazines Appendix B - Folding the Reusable Plastic Carrier Board 10 Appendix C - Warranty Statement for the Processor Appendix D - Processor Menu Flowchart Appendix E - Processor Error Messages 5B9615 18–1...
  • Page 240: Appendix A - Setting Up Supply Magazines

    User’s Manual Appendix A - Setting Up Supply Magazines Overview There are two film types (blue base and clear base), and four film sizes (8 x 10 inch, 11 x 14 inch, 35 x 35 cm, and 35 x 43 cm) for the 2180 Laser Printer. A different Supply Magazine setup is required for each film size and type.
  • Page 241 Appendix Changing Film Guides To change the Supply Magazine Film Guides for different film sizes, you will need a Torx T10 driver. • For 11 x 14 inch film, insert Guides in locations, A, A, and C of the Supply Magazine.
  • Page 242 User’s Manual For 11 x 14 inch film, the Supply Magazine Film Guides should be set up in locations A, A, and C as illustrated below. 11 x 14 inch film H126_6330ACA H126_6330AA 18–4 5B9615...
  • Page 243 Appendix Changing the Rear Film Stop Assemblies In the Lid of the Supply Magazine, there is a pair of Rear Film Stop Assemblies that keeps the film in place within the Magazine. This pair of Assemblies must be located in the appropriate location for the size of film that is used.
  • Page 244 User’s Manual For the 11 x 14 inch film that we used in the previous example, the Rear Film Stop Assemblies should be set up in the middle locations as illustrated below. rear film stop assemblies comb assembly spindle 11 x 14 in. film H126_6347CCA H126_6347CA 18–6...
  • Page 245 Appendix Changing the Encoding Screws To change the Supply Magazine Encoding Screws, you will need a 2.5 mm Hex head wrench. On the bottom of the Supply Magazine, there are Encoding Screws which are sensed by Switches to communicate information about the film type to the Printer. With the Magazine upside down and the Handle to the left, locate Encoding Screws X1, X2 and X3 as illustrated below.
  • Page 246 User’s Manual After the Supply Magazine has been set up for the appropriate film type, you should apply an identifying label to the center of the front of the Supply Magazine as shown in the illustration below. Adhesive labels are supplied with each Supply Magazine. 35 x 43 Clear 11 x 14 Blue H126_0727AA...
  • Page 247 Appendix Ordering Information for KODAK EKTASCAN Laser Imaging Film The Kodak Ektascan 2180 Laser Printer uses Kodak Ektascan HN or HNC film. Designed exclusively for helium neon and visible light solid state laser imaging, it is available in the following configurations.
  • Page 248: Appendix B - Folding The Reusable Plastic Carrier Board

    [1] Fold the Carrier Board at the fold lines so that the smooth side is on the inside. carrier board smooth H126_6350ACB side H126_6350AA [2] Load film into the Carrier Board with emulsion-side up. [3] Place the Carrier Board and film into the Kodak Ektascan 2180 Laser Printer Supply Magazine. 18–10 5B9615...
  • Page 249 Appendix Important The slots in the Carrier Board will be on the bottom of the Supply Magazine and placed toward the opening. slot H126_6349GCB supply magazine H126_6349GA 5B9615 18–11...
  • Page 250: Appendix C - Warranty Statement For The Processor

    How to Obtain Service Should the equipment require service, refer to the sales contract for details on whom to call for service, or contact the dealer (for Kodak X-Omat 180 LP or 180 LPS Processors) who sold the equipment to you.
  • Page 251 Kodak. Such damages for which Kodak will not be responsible include, but are not limited to,...
  • Page 252: Appendix D - Processor Menu Flowchart

    User’s Manual Appendix D - Processor Menu Flowchart CONTROL PRINTER F4 OTHER FUNCTIONS OTHER FUNCTIONS F4 CONTROL PROCESSOR CONTROL PROCESSOR F3 SETUP PROCESSOR PROCESSOR SETUP ACCESS ACCESS CODE PROCESSOR SETUP F4 DEV REPLEN CALIBRATION F3 SETUP PROCESS F5 FIX REPLEN PROCESSOR CALIBRATION SETPOINTS...
  • Page 253: Appendix E - Processor Error Messages

    Appendix Appendix E - Processor Error Messages E001 PROCESSOR FATAL ERROR Call processor service. Select Receive Magazine. Films in processor will not be reprinted E002 DRYER OVER TEMPERATURE Call processor service. Select Receive Magazine. Films in processor will not be reprinted. E005 PROCESSOR AIR FLOW LOSS Call processor service.
  • Page 254 User’s Manual E039 PROC UNABLE TO HEAT FIXER Call processor service. Select Receive Magazine. Films in processor will not be reprinted. E040 PROC DRYER INOPERATIVE Call processor service. Select Receive Magazine. E042 PROC COMMUNICATIONS ERROR Call processor service. Select Receive Magazine. Films in processor will not be reprinted.
  • Page 255 Appendix E097 SORTING ERROR AT BIN 7 Film may arrive at wrong bin or may be jammed in sorter. Remove film. SORTING ERROR AT BIN 8 E098 Film may arrive at wrong bin or may be jammed in sorter. Remove film. E099 SORTING ERROR AT BIN 9 Film may arrive at wrong bin or may be jammed in sorter.
  • Page 256 User’s Manual E112 MIS-SORTED FILM AT BIN 2 Verify correct films in this bin. If error repeats, remove bin assembly and use bypass tray. MIS-SORTED FILM AT BIN 3 E113 Verify correct films in this bin. If error repeats, remove bin assembly and use bypass tray. E114 MIS-SORTED FILM AT BIN 4 Verify correct films in this bin.
  • Page 257 Appendix W134 PROC DRYER UNDER SET TEMP Films in Proc not reprinted. Printing to resume when temp ok. May override in Control Proc. W139 PROC EXIT SENSOR ERROR Check connector on dryer rack. Call processor service. Select Receive Magazine. E211 Processor Error Fix the processor error or Select Receive Magazine.
  • Page 258 User’s Manual 18–20 5B9615...
  • Page 259: Section 19: Glossary

    Glossary Section 19: Glossary Access Code: A 4-digit password which must be entered by a Service Representative or a key operator to set up the Processor or to change Processor default settings. Audio: The Audio menu selection that allows you to specify a preference for audible feedback from the Keypad.
  • Page 260 User’s Manual Border Dmax: The Laser Printer specifies the maximum density of the page for each page. This is called the Border Dmax because black borders are printed at this density. The maximum density for an image on the page is typically the Border Dmax. Calibrating: A process that compensates for changes in film emulsions, processor chemistry, or the printing...
  • Page 261 Entrance Detector Rollers of the Processor and the trailing edge to exit the Dryer Rack of the Processor. Ektascan: A trademark of the Eastman Kodak Company. Field: An area on the screen where you enter data or data is displayed.
  • Page 262 User’s Manual Image Density Restriction: The Printer may specify a minimum and maximum density for the images on a page. The maximum image density may be lower than the black border density, and the minimum image density may be higher than the clear border density.
  • Page 263 Glossary Pixel: Picture element. The smallest printable area in an image. The number of bits per pixel determines how many gray levels are possible in the image. For instance, 2 bits/pixel equals to 4 gray levels, and 8 bits/pixel equals to 256 gray levels. Process Time: The time that it takes the leading edge of a sheet of film to travel from the Entrance Detector Rollers...
  • Page 264 Toggle: Change between 2 settings. For example, a switch toggles from OFF to ON Tone scaling: A technique of making the printed images match the images on the input monitor. X-Omat: A trademark of the Eastman Kodak Company. 19–6 5B9615...
  • Page 265: Section 20: Index

    Index Section 20: Index About This Manual 2-2 Access Code 11-8 Access Film Path 3-28 Access Magazines Screen 3-6, 3-27 Active Keypad Mode 4-29 Adjusting Dryer Temperature 14-4 Appendix 18-1 Appendix A - Setting Up Supply Magazines 18-2 Appendix B - Folding the Reusable Plastic Carrier Board 18-10 Appendix C - Warranty Statement for the Processor 18-12 Appendix D - Processor Menu Flowchart 18-14 Appendix E - Processor Error Messages 18-15...
  • Page 266 User’s Manual Calibration Results Film 6-10 Checking Calibration 6-10 Overview 6-2 Performing the Calibration 6-5 Using a Stored Calibration Table 6-5 When to Calibrate 6-4 Calibrating the Replenishment system 13-10 Calibration Data Entry Screen 6-9 Calibration Results Film 6-10 Carrier Board, Folding 18-10 Changing: Destination 5-14 Format 5-9...
  • Page 267 Index Set Time and Date 3-41 Show More Functions 3-30, 3-40, 3-43 Show Printer Info 3-37 Transport Films 3-29 Control Printer Screen 2-12, 3-23 Control Processor Screen 3-30, 11-3 Control Terminal 2-16, 5-1 Change Destination 5-14 Image Setup 5-11 Main Menu 5-3 Overview 5-2 Troubleshooting 5-14 Crossover Procedure 16-10...
  • Page 268 Loading and Unloading 3-5 Select 3-4, 5-9 Size 3-8 Transport 8-3, 3-29 Transport with a Kodak X-Omat 180 LP or 180 LPS Processor 8-4 Transport with Receive Magazine 8-5 Final Comments 16-11 Flooded Replenishment Mode 13-2, 13-8 Footswitch 2-15, 4-4...
  • Page 269 Index Entering Density Data into the Kodak Process Control Densitometer 16-4 Establishing Operating Limits 16-9 Establishing the Baseline 16-7 Evaluating the Control Chart 16-10 Final Comments 16-11 Items Needed for Processor Quality Assurance 16-6 Printing the 21-Step Gray Scale 16-2...
  • Page 270 User’s Manual Sorter Error Messages Displayed on the Display Screen of the Laser Printer 7-12 Using the Control Panel 3-24, 17-4 Loading and Unloading Film 3-5 Access Magazines Screen 3-6 Changing Film Size 3-8 Loading Film in the Darkroom 3-20 Loading Film into a Partially-Empty Magazine 3-22 Loading Roomlight Film in the Supply Magazine 3-9 Unloading Film from the Receive Magazine 3-16...
  • Page 271 Index Operating Instructions, Processor 14-1 Adjusting Dryer Temperature 14-4 Limits 16-9 Shutdown 14-5 Start-up 14-2 Operational Mode 5-3, 5-8 Operations, Basic, for Laser Printer 3-1 Other Functions Screen 3-28 Page, Delete 4-11, 5-10 Page Function and Parameter Function 5-10 Performing Calibration 6-5 Polarity 5-9 Position, Delete 5-10 Position Store Keys 4-5...
  • Page 272 User’s Manual Automatic Replenishment Mode 13-2 Disable Replenishment 13-2 Flooded Replenishment Mode 13-2 Tank Fill Mode 13-2 Processor Configuration and Setpoints 11-7 Processor Overview 11-1 Control Processor Screen 11-3 Error Messages 18-15 Menu Flowchart 18-14 Process Information 11-6 Processor Configuration and Setpoints 11-7 Processor Setup Access Screen 11-9 Using the Access Code 11-8 Processor, Setting Up 13-1...
  • Page 273 Reprinting a Study Using Date 7-14 Reprinting a Study Using Study # 7-15 Selecting Film 3-4 Service Personnel - How to Contact 18-9 Set Time and Date 3-41 Setpoints - Changing 13-14 Setting Formats 4-6 Setting Up the Kodak Process Control Densitometer 16-3 5B9615 20–9...
  • Page 274 User’s Manual Setting Up the Processor 13-1 Calibrating the Replenishment System 13-10 Changing Setpoints 13-14 Display Units 13-18 Processor Configuration 11-7, 13-2 Selecting a Replenishment Mode 13-3 Standby Mode 13-18 Show Error Log Screen 8-11 Show More Functions 3-30, 3-40, 3-43 Show Printer Info 3-37 Shutdown, Printer 3-3 Shutdown, Processor 14-5...
  • Page 275 Error Codes 5-15 Error Messages 8-1, 8-11 Film Jams 8-6, 17-8 Film Transport 8-3 Film Transport with a Kodak X-Omat 180 LP or 180LPS Processor 8-4 Film Transport with Receive Magazine 8-5 Garbled Screen 5-14 How to Contact Service Personnel 8-19...
  • Page 276 User’s Manual Using a 21-Step Gray Scale for Processor Quality Assurance 16-1 Using a Stored Calibration Table 6-5 Using the Access Code 11-8 Using the Control Panel 3-23, 17-4 Using the Keypad 4-2 Footswitch 4-4 Keypad, Right Side 4-3 Message Display 4-2 Numeric Keypad 4-3 Warranty Statement, Processor 18-12 When to Calibrate the Laser Printer 6-4...
  • Page 277: Section 21: Publication History

    Publication History Section 21: Publication History Print Date Pub. No. ECO No. Affected Pages File Name OCT 1995 5B9615, 5B9616, 5B9607 2632-286 All om3230_1.book This book file includes: om3230_1.front, om3230_1.doc through om3230_21.doc. 5B9615 21–1...
  • Page 278 Kodak, Ektascan, and X-Omat are trademarks. HEALTH SCIENCES DIVISION om3230_21.doc EASTMAN KODAK COMPANY ROCHESTER, N.Y. 14650 Printed In USA...

This manual is also suitable for:

X-omat 180 lpX-omat 180 lps

Table of Contents
