You can use a connected USB keyboard instead of using the Spell (and other) character
NOTE
editing softkeys.

Recalling Setups, Masks, or Reference Waveforms

1 Press the [Save/Recall] key.
2 In the Save/Recall Menu, press Recall.
3 In the Recall Menu, press Recall:, then, turn the Entry knob to select the type of
You can also recall setups and mask files by loading them using the File Explorer.
See
You can also configure the [Quick Action] key to recall setups, masks, or reference
waveforms. See

To recall setup files

Setup files can be recalled from one of 10 internal (\User Files) locations or from
an external USB storage device.
1 Press [Save/Recall] > Recall > Recall:; then, turn the Entry knob to select Setup
2 Press the softkey in the second position and use the Entry knob to navigate to
3 Press the Press to Recall softkey.
Keysight InfiniiVision 2000 X-Series Oscilloscopes User's Guide
When available, the Increment softkey can be used to enable or disable
automatically incremented file names. Auto increment adds a numeric suffix to
your file name and increments the number with each successive save. It will
truncate characters as necessary when the file name length is at maximum and
more digits are required for the numeric portion of the file name.
file you want to recall:
• Setup (*.scp) — See
• Mask (*.msk) — See
• Reference Waveform data (*.h5) — See
a USB storage device"
"File Explorer" on page 279.
"Configuring the [Quick Action] Key"
(*.scp).
the file to recall. See
"To recall setup files"
"To recall mask files"
"To recall reference waveform files from
on page 266.
"To navigate storage locations"
Save/Recall (Setups, Screens, Data)
on page 265.
on page 266.
on page 291.
on page 264.
18
265
