Waste Toner Bottle Near Full

Phaser 7500 Printer Service Manual
The Waste Toner Bottle Full Sensor detected Near Full state.
Applicable Chain-Link Code
• 091-400: Waste Toner Bottle Near Full
Initial Actions
• Check the Waste Cartridge life.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts
Waste Toner Bottle Full
■
Sensor, PL8.2.3
Waste Cartridge, PL8.2.19
■
MCU PWB, PL18.3.6
■
Troubleshooting Procedure
Step Actions and Questions
1
Replace the Waste Cartridge as
required (REP 1.3,
Does that fix the problem?
2 Perform the Toner Waste
Cartridge Sensors test in
Diagnostics.
Use a sheet of paper, etc. to block/
clear the light path to the Waste
Toner Bottle Position Sensor.
Does the display change between
High/ Low?
Wiring and Plug/Jack Map References
Yes
Troubleshooting
page 8-12). complete.
Replace the
MCU PWB
(REP 18.12,
page 8-202).
Error Messages and Codes
No
Go to step 2.
Go to "General
Sensor Failure"
on page 3-28
to check the
Waste Toner
Bottle Position
Sensor.
3-247
