M Disp Motor Fail

Phaser 7500 Printer Service Manual
The Magenta Toner Cartridge empty was detected empty regardless of low usage
of toner from Magenta Toner Cartridge.
Applicable Chain-Link Code
093-315: M Disp Motor Fail
•
Initial Actions
• Power cycle the printer.
• If the problem persists, follow the procedure below.
Troubleshooting Reference
Applicable Parts
Toner Cartridge (M), PL5.1.3
■
MCU PWB, PL18.3.6
■
1. Turn the power Off and On.
2. Examine the toner feed system for clumped toner.
3. Replace the Toner Cartridge (M) (REP 1.1,
4. Perform the Dispenser Motors test in Diagnostics.
5. Check the drive transmission path in the Dispense Assembly. If no problems
are found, replace the MCU PWB (REP 18.12,
Error Messages and Codes
Wiring and Plug/Jack Map References
page 8-9).
page 8-202).
3-283
