System board and components
15.5.2

Installing the iRMC microSD card

Upgrade and Repair Unit
(URU)
Tools:
tool-less
Preliminary steps
▶ If applicable,
"Removing the front cover with lock" on page
▶
"Shutting down the server" on page
▶
"Disconnecting the power cord" on page
▶
"Getting access to the component" on page
▶
"Removing the air duct" on page
▶ If applicable, remove the riser module 1, see
page 63.
Installing the iRMC microSD card
Figure 245: iRMC microSD card
306
46.
65.
Upgrade and Maintenance Manual
Hardware: 5 minutes
47.
49.
"Removing a riser module" on
45.
RX1330 M5
