Software configuration
To install the ESXi to the M.2 SSD, see
page 315.
15.7

Dual microSD 64GB Enterprise

15.7.1

Position of the Dual microSD 64GB Enterprise

Management
LAN
Shared LAN 1
LAN 1
LAN 2
Figure 253: Position on the system board
15.7.2

Installing the Dual microSD 64GB Enterprise

Upgrade and Repair Unit
(URU)
Tools: tool-less
Preliminary steps
▶ If applicable,
"Removing the front cover with lock" on page
▶
"Shutting down the server" on page
▶
"Disconnecting the power cord" on page
▶
"Getting access to the component" on page
▶
"Removing the air duct" on page
RX1330 M5
Slot 1
iRMC
S6
INDICATE
CSS
65.
Upgrade and Maintenance Manual
System board and components
"Software configuration" on
DIMM 2B
DIMM 1B
USB 5
SATA
SATA
0-3
ODD
ROC
Micro
SD
Hardware: 5 minutes
Software: 15 minutes
46.
47.
49.
FAN2
SYS
Battery
FAN1
SMBSYS
SYS
45.
319
