3.Installation

This section will guide the user through the installation and general setup of the Robotiq PowerPick20 Vacuum Gripper.
Before installing:
Read and understand the safety instructions related to the PowerPick20 Vacuum Gripper. Please refer to the
l
more information.
Verify the package according to the scope of delivery and the order.
l
Make sure to have the required parts, equipment and tools listed in the scope of delivery.
l
Make sure to meet the recommended environmental conditions.
l
Info
This manual uses the metric system. Unless specified, all dimensions are in millimeters.
Warning
When installing:
Do not operate the PowerPick20 Vacuum Gripper or even turn on the power supply before confirming the device is
l
firmly attached and the work area is clear.
Make sure that the air supply source is secured.
l
Failure to properly secure and install the equipment can result in material damage and bodily injury.
l
If the installation is not performed in compliance with the manufacturer's instructions, the warranty will be void.

3.1 .Scope of Delivery

3.1 .1 .PowerPick20 Vacuum Gripper Kit
1 x PowerPick20 standard kit:
l
1 x PowerPick20 Vacuum Generation Unit
l
1 x I/O cable (M12, 12 pins, 2 m)
l
1 x 2 in pre-perforated grommet
l
1 x PowerPick20 Vacuum Gripper:
l
1 x Manifold assembly
l
1 x Small suction cup bracket assembly with 110 mm suction cups
l
Safety section
PowerPick - Instruction Manual
13
