Page 15: Preface
(VCStack) feature. For instructions on how to install the switch as a stand- alone device, refer to the SBx908 GEN2 Installation Guide for Stand-alone Switches. This preface contains the following sections:  “Document Conventions” on page 16  “Contacting Allied Telesis” on page 17...
Page 16: Document Conventions
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury.
Page 17: Contacting Allied Telesis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: ...
Page 18 Preface...
Page 19 Chapter 1 Overview The chapter contains the following sections:  “Overview” on page 20  “SBx908 GEN2 Chassis” on page 22  “XEM2 Ethernet Line Cards” on page 23  “XEM2-8XSTm Line Card” on page 26  “XEM2-12XT Line Card” on page 29 ...
Page 20: Chapter 1: Overview
XEM2-1CQ Card features one port for a 100Gbps QSFP28 transceiver. Ethernet line cards are ordered separately. Refer to the product data sheet on the Allied Telesis web site for a list of approved transceivers. Management Here are the management software and interfaces: Software and ...
Page 21: Management Methods
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  Web browser interface available remotely over the network. The AlliedWare Plus management software comes pre-installed on the chassis. Management You can manage the switch as follows: Methods  Command line interface accessed locally through the Console port or remotely using Telnet or Secure Shell.
Page 22: Sbx908 Gen2 Chassis
Chapter 1: Overview SBx908 GEN2 Chassis The front panel of the SBx908 GEN2 Chassis is shown in Figure 1. Management Panel Power Supply Slot (PSU A) Power Supply Slot (PSU B) Eight Slots for XEM2 Ethernet Line Cards with Blank Cover Figure 1.
Page 23: Xem2 Ethernet Line Cards
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking XEM2 Ethernet Line Cards The XEM2 Ethernet line cards are shown in Figure 3 and briefly described in Table 1. XEM2-12XTm XEM2-8XSTm XEM2-12XT XEM2-12XS XEM2-1CQ XEM2-4QS Figure 3. XEM2 Ethernet Line Cards...
Page 24: Table 1: Xem2 Series Line Cards
Chapter 1: Overview Table 1. XEM2 Series Line Cards Line Card Description XEM2-8XSTm Four twisted pair ports (1-4) with RJ-45 connectors that support the following speeds: - 100Mbps - 1/2.5/5/10Gbps Four ports (5-8) that support the following types of transceivers and cables: - 1Gbps SFP - 10Gbps SFP+ - 10Gbps one meter SP10TW1, three...
Page 25 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 1. XEM2 Series Line Cards (Continued) Line Card Description XEM2-1CQ One port for the 100Gbps QSFP28 transceiver. Please review the following:  The XEM2-8XSTm Card requires AlliedWare Plus v5.4.9-2 or later. ...
Page 26: Xem2-8Xstm Line Card
Chapter 1: Overview XEM2-8XSTm Line Card The XEM2-8XSTm Line Card is shown in Figure 4. Figure 4. XEM2-8XSTm Line Card Twisted Pair The XEM2-8XSTm Card has four twisted pair ports and four SFP ports. The specifications for the twisted pair ports are listed in Table 2. Ports Table 2.
Page 27: Twisted Pair Port Leds
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 2. Twisted Pair Ports on the XEM2-8XSTm Line Card (Continued) Specification Description Cabling Minimum cable requirements are: - 100Mbps - Standard TIA/EIA 568-B- compliant Category 3 unshielded cabling. - 1/2.5/5Gbps - Standard TIA/EIA 568-A- compliant Category 5 or TIA/EIA 568-B- compliant Enhanced Category 5 (Cat 5e) unshielded cabling.
Page 28: Transceiver Ports
SFP and SFP+ transceivers are purchased separately. For a list of supported transceivers, refer to the SBx908 GEN2 Series data sheet on the Allied Telesis web site. Transceiver Port The ports have link and activity LEDs. The states of the LEDs are described in Table 4.
Page 29: Xem2-12Xt Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking XEM2-12XT Line Card The XEM2-12XT Line Card is shown in Figure 5. Figure 5. XEM2-12XT Line Card Twisted Pair The XEM2-12XT Card has 12 twisted pair ports with standard 8-pin RJ-45 ports. The specifications of the ports are listed in Table 5. Ports Table 5.
Page 30: Leds
Chapter 1: Overview Table 5. Twisted Pair Ports on the XEM2-12XT Line Card (Continued) Specification Description Cabling Minimum cable requirements are: - 100Mbps - Standard TIA/EIA 568-B- compliant Category 3 unshielded cabling. - 1Gbps - Standard TIA/EIA 568-A- compliant Category 5 or TIA/EIA 568-B- compliant Enhanced Category 5 (Cat 5e) unshielded cabling.
Page 31: Xem2-12Xtm Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking XEM2-12XTm Line Card The XEM2-12XTm Line Card is shown in Figure 6. Figure 6. XEM2-12XTm Line Card Twisted Pair The XEM2-12XTm Card has 12 twisted pair ports with standard 8-pin RJ- 45 ports. The specifications of the ports are listed in Table 7. Ports Table 7.
Page 32: Leds
Chapter 1: Overview Table 7. Twisted Pair Ports on the XEM2-12XTm Line Card (Continued) Specification Description Cabling Minimum cable requirements are: - 100Mbps - Standard TIA/EIA 568-B- compliant Category 3 unshielded cabling. - 1/2.5/5Gbps - Standard TIA/EIA 568-A- compliant Category 5 or TIA/EIA 568-B- compliant Enhanced Category 5 (Cat 5e) unshielded cabling.
Page 33: Xem2-12Xs Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking XEM2-12XS Line Card The XEM2-12XS Line Card is shown in Figure 7. Figure 7. XEM2-12XS Line Card Transceiver Ports The XEM2-12XS Card has twelve transceiver ports that support the following types of 1Gbps SFP transceivers, 10Gbps SFP+ transceivers and 10Gbps direct connect cables ...
Page 34: Leds
SFP or SFP+ transceivers must be purchased separately. For a list of supported transceivers, refer to the SBx908 GEN2 Series data sheet on the Allied Telesis web site. LEDs The ports have link and activity LEDs. The states of the LEDs are described in Table 9 on page 34.
Page 35: Xem2-4Qs Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking XEM2-4QS Line Card The XEM2-4QS Line Card is shown in Figure 8. Figure 8. XEM2-4QS Line Card Transceiver Ports The XEM2-4QS Line Card has four ports that support the following types of 40Gbps QSFP+ transceiver: ...
Page 36 Chapter 1: Overview Table 10. Link and Activity LEDs on the XEM2-4QS Line Card (Continued) State Description Possible causes of this state are listed here: - The slot is empty. - The transceiver has not established a link to a network device. - The LEDs are turned off.
Page 37: Xem2-1Cq Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking XEM2-1CQ Line Card The XEM2-1CQ Line Card is shown in Figure 9. Figure 9. XEM2-1CQ Line Card Transceiver Port The XEM2-1CQ Line Card has one transceiver port that supports the following 100Gbps transceivers: ...
Page 38 Chapter 1: Overview Table 11. Link and Activity LED on the XEM2-1CQ Line Card (Continued) State Description Flashing Green The transceiver is transmitting or receiving data. Possible causes of this state are listed here: - The port is empty. - The transceiver has not established a link to a network device.
Page 39: Management Panel
The management panel is not field-replaceable. USB Port You can use the USB port with a flash drive to perform the following management functions:  Provide a centralized network backup location for Allied Telesis Management Framework.  Store backup copies of configuration files. ...
Page 40: Net Mgmt Ethernet Management Port
100 ohm impedance and a frequency of 100 MHz. For instructions on how to configure the NET MGMT port, refer to the Software Reference for SwitchBlade x908 Gen2 Switch. The Network Management (NET MGMT) port has one Status LED, described in Table 12.
Page 41: Console (Rs-232) Port
“Starting a Local Management Session” on page 157 or the Software Reference for SwitchBlade x908 Gen2 Switch. Switch ID LED The Switch ID LED, shown in Figure 11, displays the ID number of the switch.
Page 42: Eco-Friendly Button
Chapter 1: Overview  A cooling fan has failed.  The internal temperature of the switch has exceeded the normal operating range and the switch may shut down. Note You can use the SHOW SYSTEM ENVIRONMENT command in the command line interface to identify the source of the problem. eco-friendly You use the eco-friendly button on the management panel to turn the LEDs on or off.
Page 43: Power Supplies
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Power Supplies The power supply units for the chassis are the SBxPWRSYS2 AC and SBxPWRSYS1-80 DC Power Supplies. Refer to Figure 12. SBxPWRSYS2 AC Power Supply SBxPWRSYS1-80 DC Power Supply Figure 12. SBxPWRSYS2 and SBxPWRSYS1-80 Power Supplies Here are the power supply guidelines: ...
Page 44 The power supplies are installed in the PSU A and PSU B slots in the front panel of the chassis. If you are installing only one power supply, Allied Telesis recommends installing it in PSU A slot because that slot does not come with a blank slot cover.
Page 45: Fan08 Units
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking FAN08 Units The cooling unit for the chassis is the FAN08 Fan module. Refer to Figure 13. Figure 13. FAN08 Module The chassis comes with two pre-installed fan modules in FAN A and FAN B slots on the rear panel.
Page 46: Specifying Ports In The Command Line Interface
Chapter 1: Overview Specifying Ports in the Command Line Interface The individual ports on the switches in a stack are specified in the command line interface with the PORT parameter. The format of the parameter is shown in Figure 14. n.n.n port Stack ID Number...
Page 47 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking For instructions on the command line interface and the PORT parameter, refer to the Software Reference for SBx908 GEN2 Switch, AlliedWare Plus Operating System.
Page 48: Software And Hardware Releases
Chapter 1: Overview Software and Hardware Releases Software releases of the AlliedWare Plus operating software for the SBx908 GEN2 Switch are listed in Table 14. Table 14. Software and Hardware Releases Software Version Hardware v5.4.7A-1 SBx908 GEN2 Chassis XEM2-12XT Line Card XEM2-12XS Line Card XEM2-4QS Line Card FAN08 Fan Module...
Page 49: Chapter 2: Virtual Chassis Stacking
Chapter 2 Virtual Chassis Stacking The sections in this chapter are listed here:  “Overview” on page 50  “Stacking Guidelines” on page 51  “Stack Trunk” on page 52  “Master and Member Switches” on page 68  “Switch ID Numbers” on page 69 ...
Page 50: Overview
Chapter 2: Virtual Chassis Stacking Overview The Virtual Chassis Stacking (VCStack) feature lets you build a virtual stack of up to four SBx908 GEN2 Series switches. The feature allows the switches to function as a single networking unit, with the following benefits: ...
Page 51: Stacking Guidelines
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Stacking Guidelines Here are general stacking guidelines:  A stack can have two, three, or four switches.  Stacking requires v5.4.8-0.2 or later of the AlliedWare Plus management software. Instructions later in this guide explain how to view the version number of the operating software on the switches.
Page 52: Stack Trunk
 If you are using fiber optic transceivers for the trunk, the transceivers must be from Allied Telesis. Transceivers from other network equipment providers might not operate properly as part of a trunk link. For a list of supported transceivers, refer to the Allied Telesis web site.
Page 53: Figure 15: Example Trunks For Stacks Of Two, Three, Or Four Switches
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Stack with Two Chassis Stack with Three Chassis Stack with Four Chassis Figure 15. Example Trunks for Stacks of Two, Three, or Four Switches  The trunk configuration is referred to as a ring because the last switch in the stack is connected to the first switch, creating a loop.
Page 54: Figure 16: Stack Of Three Switches With A Linear Trunk
Chapter 2: Virtual Chassis Stacking  You can omit the link from the last to first switches to create a linear trunk. An example of a stack with three switches in a linear trunk is shown in Figure 16. This trunk topology is not recommended.
Page 55: Figure 17: Example Of A Trunk With Multiple Links Between Switches
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  You can increase the bandwidth and resiliency of trunks by increasing the number of physical links between switches. The example in Figure 17 uses ports on XEM2-12XS Line Cards to build a stack of three switches, with a trunk of three links from switch-to-switch.
Page 56: Figure 18: Example Of A Stack Trunk Of Ports On Multiple Line Cards
Chapter 2: Virtual Chassis Stacking  You can further improve the resiliency of trunks by distributing the ports onto multiple cards in the switches. This makes it possible for trunks to continue functioning, though at reduced bandwidths, even if line cards with trunk ports fail. The example in Figure 18 is a stack of three switches with a trunk of two links from switch-to- switch, on different line cards.
Page 57: Table 15: Maximum Number Of Trunk Ports Per Switch
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  Table 15 lists the maximum number of trunk ports that a switch can support at one time. The number varies by line card. For example, a switch can have a maximum of eight trunk ports when a trunk is build with ports on XEM2-12XS Line Cards.
Page 58: Figure 19: Unsupported Trunk With Too Many Stacking Ports
Chapter 2: Virtual Chassis Stacking Chassis 1 Chassis 2 Figure 19. Unsupported Trunk with Too Many Stacking Ports  You can use any line card in the chassis for the trunk. Furthermore, as stated earlier, the ports of the trunk can be from different cards in a chassis, so long as all the cards are the same model.
Page 59: Figure 20: Stack With Three Chassis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  With stacks of three or four switches, the number of physical links in the trunk has to be the same on all switches. The example in Figure 20 is a stack of three chassis with a valid trunk of two links between chassis 1 and 2, chassis 2 and 3, and chassis 3 and 1.
Page 60: Figure 21: Unsupported Trunk Because Switches Have Different Numbers Of Trunk Links
Chapter 2: Virtual Chassis Stacking  Figure 21 is an example of an unsupported trunk because the units do not have the same number of trunk links. There are two links between chassis 1 and 2 and chassis 2 and 3, but only one link between chassis 1 and 3.
Page 61: Figure 22: Unsupported Trunk With Different Ethernet Line Card Models
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  A trunk cannot have ports from different line card models. The trunk for the three switches in Figure 22 is unsupported because it has ports from XEM2-4QS and XEM2-12XT Line Cards. Chassis 1 Chassis 2 Chassis 3...
Page 62: Figure 23: Example Of A Stack Trunk Of Ports On Xem2-8Xstm Line Cards
Chapter 2: Virtual Chassis Stacking  The XEM2-8XSTm Line Card has four twisted pair ports and four SFP+ ports. When building a trunk with the ports on this line card, you can use either the twisted pair or SFP+ ports, but not both. Figure 23 is an example of a trunk of SFP+ ports on XEM2-8XSTm Line Cards for a stack of three switches.
Page 63: Figure 24: Unsupported Trunk With Both Direct Connect And Fiber Optic Cables On Xem2-12Xt Line Cards
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  The XEM2-12XS Line Card supports 10Gbps SP10TW direct connect twinax cables in addition to fiber optic transceivers. You can use direct connect cables for trunk links when switches are physically close together, such as in the same equipment rack or adjacent racks.
Page 64: Figure 25: Unsupported Trunk With Both Direct Connect And Fiber Optic Cables On Xem2-4Qs Line Cards
Chapter 2: Virtual Chassis Stacking  The XEM2-4QS Line Card also supports QSFPICU and QSFP3CU direct connect cables. As with the XEM2-12XT Line Card, you can build stack trunks using XEM2-4QS Line Cards with either direct connect cables or fiber optic transceivers, but not both. Figure 25 is an example of an unsupported trunk on XEM2-4QS Line Cards because it uses both direct connect and fiber optic cables.
Page 65: Figure 26: Example Of A Stack Trunk With Xem2-1Cq Line Cards
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  You can use XEM2-1CQ Line Cards for a stack trunk. But since the card has only one 100Gbps transceiver port, each switch has to have two cards for the trunk. Figure 26 is an example of a stack trunk of four switches with the line card.
Page 66: Figure 27: Unsupported Trunk Because A Chassis Is Connected To Three Other Chassis
Chapter 2: Virtual Chassis Stacking  In stacks of four chassis, no switch can have trunk links to more than two other chassis. The trunk example in Figure 27 is unsupported because chassis 1 has trunk links to all three of the other switches.
Page 67: Figure 28: Unsupported Trunk With Intermediary Network Devices
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  Trunk links must be direct connections between ports on the line cards. A trunk cannot have any intermediary network devices, such as media converters, routers, or other Ethernet switches. Figure 28 is an example of an unsupported trunk because it has intermediary network devices, in this case media converters.
Page 68: Master And Member Switches
Chapter 2: Virtual Chassis Stacking Master and Member Switches A stack has a master switch. A stack can have only one master switch at a time. Its main functions are listed here:  Coordinate and monitor stack operations.  Verify that the switches are using the same version of management software.
Page 69: Switch Id Numbers
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Switch ID Numbers Each switch must be assigned an ID number. The range is 1 to 4. The default is 1. The ID numbers are displayed on the ID LEDs on the front panels of the units.
Page 70: Optional Feature Licenses
Additional features and capabilities might be included with the operating system, but they can only be used after they are unlocked with optional feature licenses from Allied Telesis. Contact your authorized reseller or distributor for a list of optional features licenses for this product.
Page 71: Planning The Stack
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Planning the Stack Here are factors to consider when planning a stack:  How many SBx908 GEN2 Chassis will be in the stack? The maximum is four chassis.  Which line cards will have the trunk ports? ...
Page 72: Stacking Worksheet
Chapter 2: Virtual Chassis Stacking Stacking Worksheet The worksheet in Table 16 is here to assist you in configuring and maintaining a stack. Table 16. Stacking Worksheet Firmware Trunk: Version Switch Location Priority Slots, Line Cards, and Ports Number Master Member Member Member...
Page 73 ID LEDs on the front panels and you use the numbers to configure the individual ports. Allied Telesis recommends assigning the ID 1, the default value, to the master switch. You should decide ahead of time, before beginning the configuration procedures, the ID assignments of the switches.
Page 74: Table 18: Example Of A Completed Stacking Worksheet
Cards, and Ports have not yet chosen them, you should do so before beginning the configuration procedures. Allied Telesis recommends using the same ports as trunk ports on all the switches of the stack. Although this is not mandatory, it can make managing and troubleshooting the stack easier.
Page 75: Chapter 3: Beginning The Installation
Chapter 3 Beginning the Installation The chapter contains the following sections:  “Hardware Installation Overview” on page 76  “Reviewing Safety Precautions” on page 77  “Choosing a Site for the Chassis” on page 82  “Unpacking the Chassis” on page 83 ...
Page 76: Hardware Installation Overview
Chapter 3: Beginning the Installation Hardware Installation Overview Table 19 lists the general steps to installing the switch hardware. Table 19. Hardware Installation Procedures Step Description Procedure Review safety precautions. “Reviewing Safety Precautions” on page 77 Choose locations for the “Choosing a Site for the Chassis”...
Page 77: Reviewing Safety Precautions
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedure. Note Safety statements that have the  symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/library.
Page 78 Chapter 3: Beginning the Installation Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord.  E3 Warning Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet.
Page 79  E25 Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28 Note Use dedicated power circuits or power conditioners to supply reliable electrical power to the device.
Page 80 Chapter 3: Beginning the Installation Note If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than the room ambient temperature. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).
Page 81 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Warning The temperature of an operational SFP or SFP+ transceiver may exceed 70° C (158° F). Exercise caution when removing or handling transceivers with unprotected hands.  E43 Warning The grounding lug on the rear panel of the chassis is for supplemental grounding.
Page 82: Choosing A Site For The Chassis
Chapter 3: Beginning the Installation Choosing a Site for the Chassis Observe these site requirements.  The SBx908 Gen2 Chassis should be installed in a standard 19- inch equipment rack. It should not be installed on a table, desk, or wall.
Page 83: Unpacking The Chassis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Unpacking the Chassis Figure 30 shows the contents of the shipping box. Figure 30. SBx908 Gen2 Switch Shipping Box The items in the box are listed here:  A - Protective bag ...
Page 84: Figure 31: Lifting The Switch From The Shipping Box
Chapter 3: Beginning the Installation Warning The switch is heavy. Ask for assistance lifting the device out of the shipping box. You might injure yourself or damage the device if you lift it without assistance. Figure 31. Lifting the Switch from the Shipping Box 2.
Page 85: Figure 33: Pre-Installed Items On The Front And Side Panels
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 3. Visually inspect the front panel of the switch for the pre-installed components shown in Figure 33. 1. Two equipment rack 3. One blank panel in power 2. Seven line card slot brackets supply slot B covers...
Page 86: Figure 34: Pre-Installed Items On The Rear Panel
Figure 34. Pre-installed Items on the Rear Panel Note You should retain the original packaging material in the event you need to return the unit to Allied Telesis. Note The product does not come with power supplies. Power supplies must be ordered separately.
Page 87: Figure 35: Accessory Kit
RJ-45 (8P8C) and DB-9 (D- sub 9-pin) connectors. Two power cord retaining clips Figure 35. Accessory Kit If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. 6. After unpacking the switch, do one of the following: ...
Page 88: Unpacking Sbxpwrsys2 Ac Power Supplies
The tie wrap included with the power supply is not used with the SBx908 Gen2 chassis. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. After unpacking the chassis and power supplies, go to Chapter 4,...
Page 89: Unpacking Sbxpwrsys1-80 Dc Power Supplies
Figure 37. Items in the Shipping Box for the SBxPWRSYS1-80 DC Power Supply If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. After unpacking the chassis and power supplies, go to Chapter 4,...
Page 90 Chapter 3: Beginning the Installation...
Page 91: Chapter 4: Installing The Chassis
Chapter 4 Installing the Chassis The procedures in this chapter explain how to install the chassis in a standard 19-inch equipment rack. The procedures are listed here:  “Tools and Material” on page 92  “Adjusting the Equipment Rack Brackets” on page 93 ...
Page 92: Tools And Material
Chapter 4: Installing the Chassis Tools and Material You need to provide the following tools and material to install the chassis:  #2 Phillips-head screwdriver  Eight screws for a standard 19-inch equipment rack  10 AWG stranded grounding wire ...
Page 93: Adjusting The Equipment Rack Brackets
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Adjusting the Equipment Rack Brackets The chassis comes with two pre-installed equipment rack brackets. The default positions of the brackets align the front of the chassis with the front of the equipment rack. You can re-position the brackets on the sides of the chassis to have the device extend in front of the rack.
Page 94: Figure 39: Chassis Orientations In The Equipment Rack
Chapter 4: Installing the Chassis Figure 39. Chassis Orientations in the Equipment Rack...
Page 95: Figure 40: Chassis Orientations In The Equipment Rack
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 40. Chassis Orientations in the Equipment Rack To change the positions of the brackets, use a #2 Phillips-head screwdriver to remove them from their default positions and secure them to the new locations. An example is shown in Figure 41 on page 96.
Page 96: Figure 41: Example Of Adjusting The Equipment Rack Brackets
Chapter 4: Installing the Chassis Figure 41. Example of Adjusting the Equipment Rack Brackets...
Page 97: Installing The Chassis In An Equipment Rack
“Choosing a Site for the Chassis” on page 82 before installing the chassis. Caution The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28 To install the chassis, perform the following procedure: 1.
Page 98: Installing The Chassis Grounding Wire
Chapter 4: Installing the Chassis Installing the Chassis Grounding Wire This procedure explains how to connect a grounding wire to the chassis. The chassis requires a permanent connection to a good earth ground for the line cards and power supplies. The procedure requires the following items: ...
Page 99: Figure 44: Removing The Grounding Lug From The Chassis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 44. Removing the Grounding Lug from the Chassis 3. Insert one end of the grounding wire into the grounding lug, as shown in Figure 45, and use a crimping tool to secure the wire to the grounding lug.
Page 100: Figure 46: Installing The Grounding Lug And Wire
Chapter 4: Installing the Chassis Figure 46. Installing the Grounding Lug and Wire 5. Connect the other end of the grounding wire to the building protective earth. 6. Go to “Installing SBxPWRSYS2 AC Power Supplies” on page 101 or “Installing SBxPWRSYS1-80 DC Power Supplies” on page 105.
Page 101: Installing Sbxpwrsys2 Ac Power Supplies
PSU A and PSU B If you are installing only one power supply, you may install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel. 2. If there is already a power supply in PSU A, lift the handle on the blank power supply panel in PSU B and slide the panel from the slot.
Page 102: Figure 47: Removing The Blank Power Supply Panel From Power Supply Slot B
Chapter 4: Installing the Chassis Figure 47. Removing the Blank Power Supply Panel from Power Supply Slot B 3. Lift the handle on the SBxPWRSYS2 AC Power Supply. Refer to Figure 48. Figure 48. Lifting the Locking Handle on the SBxPWRSYS2 Power Supply 4.
Page 103: Figure 49: Sliding The Sbxpwrsys2 Ac Power Supply Into The Chassis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 49. Sliding the SBxPWRSYS2 AC Power Supply into the Chassis 5. Gently press on the faceplate of the power supply to seat the unit on the connector on the backplane of the chassis, and lower the locking handle to secure the unit in the chassis.
Page 104 Chapter 4: Installing the Chassis 6. Visually inspect the power supply to be sure that its faceplate is flush against the front panel of the chassis and the locking handle is fully down. 7. If necessary, repeat this procedure to install a second power supply. 8.
Page 105: Installing Sbxpwrsys1-80 Dc Power Supplies
PSU A and PSU B If you are installing only one power supply, you may install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel. 2. If there is already a power supply in PSU A, lift the handle on the blank power supply panel in PSU B and slide the panel from the slot.
Page 106: Figure 51: On/Off Switch On The Sbxpwrsys1-80 Dc Power Supply
Chapter 4: Installing the Chassis On/Off Switch Figure 51. On/Off Switch on the SBxPWRSYS1-80 DC Power Supply 4. With a #2 Phillips-head screwdriver, loosen the handle locking screw on the power supply, as shown in Figure 52. Figure 52. Loosening the Handle locking Screw on the SBxPWRSYS1-80 DC Power Supply 5.
Page 107: Figure 53: Lifting The Locking Handle On The Sbxpwrsys1-80 Dc Power Supply
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 53. Lifting the Locking Handle on the SBxPWRSYS1-80 DC Power Supply 6. Carefully align the power supply in the slot and slide it into the slot until it makes contact with the connector inside the chassis. Refer to Figure 54.
Page 108: Figure 55: Lowering The Locking Handle On The Sbxpwrsys1-80 Dc Power Supply
Chapter 4: Installing the Chassis Figure 55. Lowering the Locking Handle on the SBxPWRSYS1-80 DC Power Supply 8. Visually inspect the power supply to be sure that its faceplate is flush against the front panel of the chassis and the locking handle is fully down.
Page 109: Installing Ethernet Line Cards
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing Ethernet Line Cards This section contains the procedure for installing Ethernet line cards in the chassis. The illustrations show the XEM2-12XT Line Card. The procedure is the same for all line card models. Caution The device can be damaged by static electricity.
Page 110: Figure 57: Removing The Ethernet Line Card From The Anti-Static Bag
Chapter 4: Installing the Chassis 3. Carefully remove the new Ethernet line card from its shipping container and anti-static bag. Refer to Figure 57. Figure 57. Removing the Ethernet Line Card from the Anti-static Bag 4. Position the line card with the notch on the faceplate in the upper left corner, as shown in Figure 58 on page 111, and carefully slide it into the slot.
Page 111: Figure 58: Sliding The Ethernet Line Card Into The Slot
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Notch Bottom Flange Figure 58. Sliding the Ethernet Line Card into the Slot Caution Do not force the card into the slot. If you feel resistance, remove it and try again. 5. When you feel the line card make contact with the connector on the backplane of the chassis.
Page 112: Figure 59: Seating An Ethernet Line Card In The Chassis
Chapter 4: Installing the Chassis Figure 59. Seating an Ethernet Line Card in the Chassis 6. Visually inspect the line card to verify that its faceplate is flush against the front panel of the chassis. 7. Tighten the two captive screws on the card to secure it in the chassis. Refer to Figure 60.
Page 113: Installing Blank Line Card Slot Covers
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing Blank Line Card Slot Covers After installing the Ethernet line cards, inspect slots 1 to 8 for empty slots. Empty slots need to be covered with the blank slot covers that come with the chassis.
Page 114: Figure 62: Tightening The Captive Screws On A Blank Slot Cover
Chapter 4: Installing the Chassis Figure 62. Tightening the Captive Screws on a Blank Slot Cover 3. Repeat this procedure to install additional blank slot covers. 4. Go to “Installing the Blank Power Supply Slot Cover” on page 115...
Page 115: Installing The Blank Power Supply Slot Cover
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing the Blank Power Supply Slot Cover If you installed only one power supply in the chassis, check that the empty power supply slot is covered with the blank power supply slot cover included with the chassis.
Page 116: Figure 64: Aligning The Blank Power Supply Cover In The Slot
Chapter 4: Installing the Chassis Figure 64. Aligning the Blank Power Supply Cover in the Slot 3. Lower the locking handle on the blank power supply slot cover to secure the cover in the chassis. Refer to Figure 65. Figure 65. Lowering the Locking Handle on the Blank Power Supply Slot Cover 4.
Page 117: Installing The Power Cord Retaining Clips
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing the Power Cord Retaining Clips The chassis comes with two power cord retaining clips in the accessory kit. They are used to prevent the power cords for the SBxPWRSYS2 AC power supply from being accidentally disconnected from the unit. To install a power cord retaining clip, press in the sides and insert the ends into the holes above and below the AC connector.
Page 118: Verifying The Installation
Chapter 4: Installing the Chassis Verifying the Installation Please perform the following procedure after installing a chassis: 1. Verify that the chassis has at least one power supply in slot PSU A or 2. If the chassis has only one power supply, verify that the empty power supply slot on the front panel is covered with a blank panel.
Page 119: Chapter 5: Wiring The Sbxpwrsys1-80 Dc Power Supply
Chapter 5 Wiring the SBxPWRSYS1-80 DC Power Supply This chapter contains the following procedures:  “Introduction” on page 120  “Choosing a Method for Attaching the Grounding Wire” on page 122  “Connecting the Grounding Wire with the Grounding Terminal” on page 123 ...
Page 120: Introduction
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Introduction The procedures in this chapter explain how to attach the ground and power wires to the SBxPWRSYS1-80 DC Power Supplies. If you have not installed the power supplies, refer to “Installing SBxPWRSYS1-80 DC Power Supplies”...
Page 121: Figure 67: Components On The Sbxpwrsys1-80 Dc Power Supply
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking The components on the power supply are identified in Figure 67. Positive (+) Negative (-) On/Off Terminal Terminal Switch Plastic Locking Cover Handle Screw Locking Ground Post Handle with Nut and Washer Figure 67.
Page 122: Choosing A Method For Attaching The Grounding Wire
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Choosing a Method for Attaching the Grounding Wire You may attach the grounding wire to the power supply using the supplied terminal, shown in Figure 68, or bare wire. Figure 68. Grounding Wire Terminal The two methods are described in the following sections: ...
Page 123: Connecting The Grounding Wire With The Grounding Terminal
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Connecting the Grounding Wire with the Grounding Terminal To attach a grounding wire with the grounding terminal provided with the power supply, perform the following procedure: 1. Prepare an adequate length of stranded 10 AWG grounding wire by stripping it as shown in Figure 69.
Page 124: Figure 71: On/Off Switch On The Sbxpwrsys1-80 Dc Power Supply
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply On/Off Switch Figure 71. On/Off Switch on the SBxPWRSYS1-80 DC Power Supply 4. Use an 8 mm wrench to remove the grounding post nut and washer, shown in Figure 72 on page 125, from the power supply.
Page 125: Figure 72: Removing The Nut And Washer From The Grounding Post
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Grounding post Figure 72. Removing the Nut and Washer from the Grounding Post 5. Attach the grounding lug and wire to the grounding post. Refer to Figure 73 on page 126. Review the following before installing the grounding wire: ...
Page 126: Figure 73: Attaching The Grounding Lug And Wire To The Grounding Post
Figure 73. Attaching the Grounding Lug and Wire to the Grounding Post 6. Secure the grounding wire with the nut and washer removed in step 4, with an 8 mm wrench. Refer to Figure 74 on page 127. Allied Telesis recommends tightening the nut and washer to 26 inch- lbs.
Page 127: Figure 74: Securing The Grounding Wire
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 74. Securing the Grounding Wire 7. Connect the other end of the grounding wire to the building protective earth. Warning When installing this equipment, always ensure that the power supply ground connection is installed first and disconnected last.  E11 Note This system works with a positive grounded or negative grounded DC system.
Page 128: Connecting The Grounding Wire With Bare Wire
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Connecting the Grounding Wire with Bare Wire To attach the grounding wire to the power supply with bare wire, perform the following procedure: 1. Prepare an adequate length of solid or stranded 10 AWG grounding wire by stripping it as shown in Figure 75.
Page 129: Figure 76: Attaching The Bare Grounding Wire To The Grounding Post
Figure 76. Attaching the Bare Grounding Wire to the Grounding Post 5. Secure the wire with the nut and washer removed in step 2, and an 8 mm wrench, as shown in Figure 77 on page 130. Allied Telesis recommends tightening the nut and washer to 26 inch- lbs.
Page 130: Figure 77: Securing The Bare Grounding Wire To The Grounding Post
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Figure 77. Securing the Bare Grounding Wire to the Grounding Post 6. After connecting the grounding wire, go to “Introduction to Attaching the Power Wires” on page 131.
Page 131: Introduction To Attaching The Power Wires
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Introduction to Attaching the Power Wires The SBxPWRSYS1-80 DC Power Supply comes with the two sets of power wire terminals, shown in Figure 78. You may use either set to connect the positive (+) and negative (-) wires to the terminal block on the power supply.
Page 132: Connecting The Dc Power Wires With The Straight Terminals
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Connecting the DC Power Wires with the Straight Terminals To use the straight terminals to connect the DC power wires to the positive and negative terminals on the power supply, perform the following procedure: 1.
Page 133: Figure 81: Opening The Plastic Cover
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 3. Verify that the On/Off switch on SBxPWRSYS1-80 Power Supply is in the Off position. Refer to Figure 71 on page 124. 4. Use a #1 Phillips-head screwdriver to loosen the two screws on the plastic cover over the positive and negative terminals on the power supply and slide the cover to the right, as shown in Figure 81 on page 133.
Page 134: Figure 82: Removing The Terminal Screws
You may attach the terminals with the wires either above or below the terminal block. Figure 83 on page 135 shows the positive wire above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 135: Figure 83: Connecting The Positive (+) Power Wire With A Straight Terminal
You may attach the terminals with the wires either above or below the terminal block. Figure 84 on page 136 shows the wires above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 136: Figure 84: Connecting The Negative (-) Power Wire With A Straight Terminal
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Figure 84. Connecting the Negative (-) Power Wire with a Straight Terminal Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block.
Page 137: Figure 85: Closing The Plastic Cover Over The Terminal Connectors
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 85. Closing the Plastic Cover over the Terminal Connectors 9. With a #2 Phillips-head screwdriver, tighten the handle locking screw to secure the power supply to the chassis. See Figure 86 on page 138.
Page 138: Figure 86: Tightening The Handle Locking Screw
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Handle locking screw Figure 86. Tightening the Handle Locking Screw 10. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off. 11.
Page 139: Connecting The Dc Power Wires With The Right Angle Terminals
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Connecting the DC Power Wires with the Right Angle Terminals To use the right angle terminals to connect the DC power wires to the positive and negative terminals on the SBxPWRSYS1-80 DC Power Supply, perform the following procedure: 1.
Page 140: Figure 88: Removing The Plastic Cover
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Figure 88. Removing the Plastic Cover 5. Use a #3 Phillips-head screwdriver to remove the two screws from the positive and negative terminals, as shown in Figure 89 on page 141.
Page 141: Figure 89: Removing The Terminal Screws
The positive terminal is on the left. Refer to Figure 90 on page 142. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 142: Figure 90: Connecting The Positive (+) Power Wire With A Right Angle Terminal
5. The negative terminal is on the right. Refer to Figure 91 on page 143. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 143: Figure 91: Connecting The Negative (-) Power Wire With A Right Angle Terminal
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 91. Connecting the Negative (-) Power Wire with a Right Angle Terminal Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block.
Page 144: Figure 92: Tightening The Handle Locking Screw
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Handle locking screw Figure 92. Tightening the Handle Locking Screw 9. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off. 10.
Page 145: Connecting Bare Dc Power Wires
You may attach the wire to the terminal so that it extends either above or below the terminal block. Figure 94 on page 146 shows the wire above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 146: Figure 94: Connecting The Positive Wire With Bare Wire
Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply Figure 94. Connecting the Positive Wire With Bare Wire 5. Wrap the negative lead wire clockwise around the remaining terminal screw and secure the screw and wire to the negative terminal connection on the terminal block with a #3 Phillips-head screwdriver, as shown in Figure 95 on page 147.
Page 147: Figure 95: Connecting The Negative Lead Wire With Bare Wire
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 95. Connecting the Negative Lead Wire with Bare Wire Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Warning Check to see if there are any exposed copper strands coming from the installed wires.
Page 148 Chapter 5: Wiring the SBxPWRSYS1-80 DC Power Supply 7. With a #2 Phillips-head screwdriver, tighten the handle locking screw to secure the power supply to the chassis. See Figure 92 on page 144. 8. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off.
Page 149: Chapter 6: Configuring Switches For Stacking
Chapter 6 Configuring Switches for Stacking This chapter contains the following procedures:  “Introduction” on page 150  “Command Summary” on page 151  “Powering On SBxPWRSYS2 AC Power Supplies” on page 154  “Starting a Local Management Session” on page 157 ...
Page 150: Introduction
Chapter 6: Configuring Switches for Stacking Introduction This chapter contains instructions on how to configure switches for stacking with VCStack. Please review the following information before performing the instructions:  The procedures should be performed in the order presented here. ...
Page 151: Command Summary
MAC address, the higher the priority. A switch can have only one priority number. Allied Telesis recommends making a switch’s priority and ID numbers the same. This is not required, but it can make managing and troubleshooting a stack easier.
Page 152: Stack Renumber
This example changes the switch’s ID from the default ID 1 to 2: awplus(config)# stack 1 renumber 2 SWITCH To ensure that the first power-on of the stack is successful, Allied Telesis recommends configuring the units such that the units know about each PROVISION other prior to forming the stack.
Page 153 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking awplus(config)# switch 2 provision sbx908gen2 This example adds a provisioned switch to the current switch and assigns it the ID 1. You use this command to add the master switch as a provisioned switch on a member switch: awplus(config)# switch 1 provision sbx908gen2...
Page 154: Powering On Sbxpwrsys2 Ac Power Supplies
Chapter 6: Configuring Switches for Stacking Powering On SBxPWRSYS2 AC Power Supplies The procedure in this section explains how to power on SBxPWRSYS2 AC Power Supplies. If you have not installed the power supplies, refer to “Installing SBxPWRSYS2 AC Power Supplies” on page 101 for instructions.
Page 155: Figure 96: Connecting The Ac Power Cord
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 96. Connecting the AC Power Cord 2. Move the retaining clip over the power cord to secure the cord to the chassis. Refer to Figure 97. Figure 97. Securing the Power Cord with the Retaining Clip 3.
Page 156: Figure 98: Connecting The Power Cord To An Ac Power Source
Chapter 6: Configuring Switches for Stacking Figure 98. Connecting the Power Cord to an AC Power Source Note The illustration shows the North American power cord. Your power cord may be different. Note The power cords included with SBxPWRSYS2 Power Supplies for 100-125 VAC installations have 20 Amp, 125 V NEMA 5-20P plugs.
Page 157: Starting A Local Management Session
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Starting a Local Management Session To start a local management session on the switch, perform the following procedure. If the switch is powered off, start with step 1. If the switch is already powered on, start with step 3: Note The initial management session has to be a local session because...
Page 158: Figure 99: Connecting The Management Cable To The Console Rs-232 Port
Chapter 6: Configuring Switches for Stacking Figure 99. Connecting the Management Cable to the Console RS-232 Port 4. Connect the other end of the cable to an RS-232 port on a terminal or personal computer with a terminal emulation program. 5.
Page 159: Figure 100: User Exec Mode Prompt
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Note User names and passwords are case sensitive. The local management session starts when the User Exec mode prompt, shown in Figure 100. is displayed. awplus> Figure 100. User Exec Mode Prompt Note The User Exec mode is the first level in the command mode interface.
Page 160: Configuring The Master Switch
Chapter 6: Configuring Switches for Stacking Configuring the Master Switch This section contains the following procedures for configuring the master switch of the stack:  “General Steps for the Master Switch,” next  “Configuring the Master Switch” on page 161 ...
Page 161: Configuring The Master Switch
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 7. Designate the ports of the stack trunk on the provisioned member switches, with the STACKPORT command in the port Interface mode. 8. Save your changes with the WRITE command in the Privilege Exec mode.
Page 162 Chapter 6: Configuring Switches for Stacking Table 20. Configuring the Master Switch (Continued) Step Description and Command Move to the Global Configuration mode with the CONFIGURE TERMINAL command. awplus# configure terminal Enter configuration commands, one per line. End with CNTL/Z. Activate VCStack on the switch with the STACK ENABLE command.
Page 163 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 20. Configuring the Master Switch (Continued) Step Description and Command Enter the port Interface modes of the ports that will be the stack trunk on the provisioned member switches. If you filled out the worksheet on Table 16 on page 72, refer there for the stacking ports.
Page 164: Verifying The Master Switch
Chapter 6: Configuring Switches for Stacking Verifying the Perform the steps in Table 21 to confirm the configuration of the master switch. Master Switch Table 21. Verifying the Master Switch Step Description and Command Start a new local management session on the master switch. Move to the Privileged Exec mode with the ENABLE command.
Page 165: What To Do Next
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 21. Verifying the Master Switch (Continued) Step Description and Command Enter the SHOW RUNNING-CONFIG command to display the running configuration of the master switch: awplus# show running-config Use the display to confirm that you designated the correct trunk ports for the master and member switches.
Page 166: Configuring Member Switches
Chapter 6: Configuring Switches for Stacking Configuring Member Switches Here are the procedures for configuring the member switches of the stack.  “General Steps for Member Switches” on page 166  “Configuring a Member Switch - Part I” on page 167 ...
Page 167: Configuring A Member Switch - Part I
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 2. Assign the member switch a priority number equal to its ID number, with the STACK PRIORITY command in the Global Configuration mode. 3. Designate the ports of the stack trunk for the member switch, with the STACKPORT command in the port Interface mode.
Page 168 Chapter 6: Configuring Switches for Stacking Table 22. Configuring a Member Switch - Part I (Continued) Step Description and Command Enter the ENABLE command to move from the User Exec mode to the Privileged Exec mode. awplus> enable Verify that the hardware components are operating correctly by entering the SHOW SYSTEM ENVIRONMENT command.
Page 169: Configuring A Member Switch - Part Ii
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 22. Configuring a Member Switch - Part I (Continued) Step Description and Command Enter the WRITE command to save your changes. If this is the first management session, the switch adds the configuration file DEFAULT.CFG to flash memory to store your configuration changes.
Page 170 Chapter 6: Configuring Switches for Stacking Table 23. Configuring the Member Switch - Part II Step Description and Command Start a new local management session on the member switch. Refer to “Starting a Local Management Session” on page 157. Enter the ENABLE command to move from the User Exec mode to the Privileged Exec mode.
Page 171: Verifying A Member Switch
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 23. Configuring the Member Switch - Part II (Continued) Step Description and Command Return to the Privileged Exec mode. awplus(config)# exit Save your changes with the WRITE command. awplus# write Building configuration ... [OK] Restart the switch.
Page 172: What To Do Next
Chapter 6: Configuring Switches for Stacking Table 24. Verifying the Configuration of a Member Switch (Continued) Step Description and Command Enter the SHOW STACK DETAIL command. awplus# show stack detail In the display, examine the entry that has the same ID number as the member switch you are currently configuring.
Page 173 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 3. If you have not already configured the master switch, perform “Configuring the Master Switch” on page 160. 4. After configuring all the switches, confirm that they are all powered off. 5. Do all the switches have the same version of the AlliedWare Plus operating software? If you filled out Table 16 on page 72, refer there for the version numbers.
Page 174: Powering On The Stack
Chapter 6: Configuring Switches for Stacking Powering on the Stack After configuring the master and member switches of the stack with the previous procedures in this chapter, you are ready to cable the ports of the stack trunk and power on the stack for the first time. (If you want to monitor the power-on sequence, connect a terminal or PC with a terminal emulator program to the Console port on any switch).
Page 175: Verifying The Stack
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Verifying the Stack To verify the stack, perform the following procedure: 1. Start a local management session on any switch in the stack. Refer to “Starting a Local Management Session” on page 157. 2.
Page 176 Chapter 6: Configuring Switches for Stacking...
Page 177: Chapter 7: Cabling Xem2 Line Card Ports
Chapter 7 Cabling XEM2 Line Card Ports This chapter contains the following procedures:  “Cabling Twisted Pair Ports” on page 178  “Guidelines to Handling Fiber Optic or Twisted Pair Transceivers” on page 179  “Installing and Cabling Fiber Optic Transceivers” on page 180 ...
Page 178: Cabling Twisted Pair Ports
Chapter 7: Cabling XEM2 Line Card Ports Cabling Twisted Pair Ports Here are the guidelines to cabling twisted pair ports on the XEM2-8XSTm, XEM2-12XT and XEM2-12XTm Line Cards:  Minimum cable requirements are: – 100Mbps - Standard TIA/EIA 568-B-compliant Category 3 unshielded cabling. –...
Page 179: Guidelines To Handling Fiber Optic Or Twisted Pair Transceivers
 For a list of supported transceivers, refer to the product data sheet on the Allied Telesis web site.  The operational specifications and fiber optic cable requirements are provided in the documents included with the transceivers.
Page 180: Installing And Cabling Fiber Optic Transceivers
Chapter 7: Cabling XEM2 Line Card Ports Installing and Cabling Fiber Optic Transceivers Table 25 lists the types of fiber optic transceivers that are supported by the XEM2 line cards. Refer to the product datasheet for a list of approved transceivers.
Page 181: Figure 103: Installing An Sfp Transceiver In The Xem2-12Xs Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 103. Installing an SFP Transceiver in the XEM2-12XS Line Card  XEM2-4QS Line Card - Figure 104 shows an QSFPLR4 transceiver being installed in an XEM2-4QS Line Card. Figure 104. Installing a Fiber Optic Transceiver in the XEM2-4QS Line Card ...
Page 182: Figure 105: Installing An 100Gbps Qsfp28 Transceiver In The Xem2-1Cq Line Card
Chapter 7: Cabling XEM2 Line Card Ports Figure 105. Installing an 100Gbps QSFP28 Transceiver in the XEM2-1CQ Line Card Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step. Otherwise, repeat steps 1 to 4 to install additional transceivers.
Page 183: Installing Direct Connect Cables
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing Direct Connect Cables The XEM2-8XSTm, XEM2-12XS, and XEM2-4QS line cards support direct connect cables, which offer an economical way to add 10Gbps or 40Gbps connections over short distances. Refer to Table 26. Table 26.
Page 184: Figure 106: Installing Sp10Tw Cables In The Xem2-12Xs Line Card
Chapter 7: Cabling XEM2 Line Card Ports Release Tab Figure 106. Installing SP10TW Cables in the XEM2-12XS Line Card  XEM2-4QS Line Card - Orient the connector on the QSFPCU Cable with the release tab on the left side and slide it into the port until it clicks into place.
Page 185 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 6. Repeat this procedure to install additional direct connect cables. Note To remove the connector and cable from the port, gently push on the connector, pull on the release tab, and slide the connector from the port.
Page 186 Chapter 7: Cabling XEM2 Line Card Ports...
Page 187: Chapter 8: Replacing Modules
Chapter 8 Replacing Modules This chapter contains the following procedures:  “Replacing SBxPWRSYS2 AC Power Supplies” on page 188  “Replacing SBxPWRSYS1-80 DC Power Supplies” on page 191  “Replacing XEM2 Line Cards” on page 202  “Replacing FAN08 Modules” on page 209...
Page 188: Replacing Sbxpwrsys2 Ac Power Supplies
PSU B. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing power supplies. For instructions, refer to the Software Reference for SwitchBlade x908 Gen2 Switches.
Page 189: Figure 109: Disconnecting The Ac Power Cord From The Chassis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 2. Move the retaining clip from the appropriate power cord on the rear panel of the chassis, and disconnect the cord. Refer to Figure 109. Figure 109. Disconnecting the AC Power Cord from the Chassis 3.
Page 190: Figure 111: Removing The Sbxpwrsys2 Ac Power Supply
Chapter 8: Replacing Modules Warning The power supply is heavy. Use both hands to hold the module as you remove it from the chassis. Figure 111. Removing the SBxPWRSYS2 AC Power Supply 5. Do one of the following:  To install a new power supply, refer to “Installing SBxPWRSYS2 AC Power Supplies”...
Page 191: Replacing Sbxpwrsys1-80 Dc Power Supplies
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Replacing SBxPWRSYS1-80 DC Power Supplies To replace an SBxPWRSYS1-80 DC Power Supply, perform the following procedure: 1. Turn off the circuit breaker to the SBxPWRSYS1-80 DC Power Supply. 2. Turn off the On/Off switch on the front panel of the power supply. Refer to Figure 51 on page 106.
Page 192: Figure 113: Opening The Plastic Window Over The Terminal Block
Chapter 8: Replacing Modules Note If the power wires are connected to the terminal block with the right angle terminals, go to step 5. 4. Use a #1 screwdriver to loosen the two screws that secure the plastic cover over the terminal block and slide the cover to the right. You may need to slightly lift the locking handle to access the bottom screw.
Page 193: Figure 114: Removing The Negative Lead Wire
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 114. Removing the Negative Lead Wire 6. Use a #3 screwdriver to remove the positive (+) lead wire from the terminal block. Refer to Figure 115 on page 194.
Page 194: Figure 115: Removing The Positive Lead Wire From The Terminal Block
Chapter 8: Replacing Modules Figure 115. Removing the Positive Lead Wire from the Terminal Block 7. Reinstall the two screws on the negative (-) and positive (+) terminals. Refer to Figure 116 on page 195.
Page 195: Figure 116: Reinstalling The Screws On The Positive And Negative Terminals
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 116. Reinstalling the Screws on the Positive and Negative Terminals 8. Slide the plastic cover to the left and lightly tighten the two screws to secure it in place. Refer to Figure 117 on page 196. Caution Do not over tighten the screws or you might crack or break the plastic cover.
Page 196: Figure 117: Closing The Plastic Cover
Chapter 8: Replacing Modules Figure 117. Closing the Plastic Cover 9. Use an 8 mm wrench to remove the grounding wire from the grounding post. Refer to Figure 118 on page 197.
Page 197: Figure 118: Removing The Grounding Wire
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 118. Removing the Grounding Wire 10. Reinstall the nut and washer on the grounding post. Refer to Figure 119 on page 198.
Page 198: Figure 119: Reinstalling The Nut And Washer On The Grounding Post
Chapter 8: Replacing Modules Figure 119. Reinstalling the Nut and Washer on the Grounding Post Note If you did not perform step 3 to loosen the retaining screw on the power supply, perform the step before continuing. 11. Lift the locking handle and slide the power supply from the chassis. Refer to Figure 120 on page 199.
Page 199: Figure 120: Lifting The Locking Handle And Removing The Power Supply
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 120. Lifting the Locking Handle and Removing the Power Supply 12. Do one of the following:  To install a new power supply, refer to “Installing SBxPWRSYS2 AC Power Supplies” on page 101 or “Installing SBxPWRSYS1-80 DC Power Supplies”...
Page 200: Figure 121: Installing The Blank Power Supply Slot Cover
Chapter 8: Replacing Modules Figure 121. Installing the Blank Power Supply Slot Cover 14. Lower the locking handle to secure the slot cover to the slot. Refer to Figure 122 on page 201.
Page 201: Figure 122: Lowering The Locking Handle On The Power Supply Slot Cover
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 122. Lowering the Locking Handle on the Power Supply Slot Cover...
Page 202: Replacing Xem2 Line Cards
Chapter 8: Replacing Modules Replacing XEM2 Line Cards This section contains the procedure for replacing XEM2 Ethernet line cards in the SBx908 Gen2 Switch. Please review the guidelines in Table 27 before performing the procedure: Table 27. Hot-swapping Guidelines for XEM2 Line Cards XEM2 Line Card Description XEM2-8XSTm...
Page 203 Here are additional hot-swapping guidelines:  Allied Telesis recommends saving a backup copy of the switch’s configuration file before removing or replacing XEM2 Line Cards. For instructions, refer to the Software Reference for SwitchBlade x908 GEN2 Switches.
Page 204 Chapter 8: Replacing Modules The next example is from replacing an XEM2-12XT Card with an XEM2-1CQ Card: Console Message: 23:26:02 awplus HSL[996]: Stack member 1 must be rebooted to configure for XEM2-1CQ, disabling XEM. Buffered log: 2018 May 15 23:26:02 local6.crit awplus HSL[996]: Stack member 1 must be rebooted to configure for XEM2-1CQ, disabling XEM.
Page 205: Figure 123: Loosening The Screws On The Ethernet Line Card
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 123. Loosening the Screws on the Ethernet Line Card 5. Carefully pull on the screws on the faceplate to disconnect the line card from the connector on the backplane in the chassis. Refer to Figure 124 on page 206.
Page 206: Figure 124: Disconnecting An Ethernet Line Card From The Chassis
Chapter 8: Replacing Modules Figure 124. Disconnecting an Ethernet Line Card from the Chassis 6. Carefully slide the card from the chassis. Refer to Figure 125 on page 207.
Page 207: Figure 125: Sliding An Ethernet Line Card From The Chassis
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 125. Sliding an Ethernet Line Card from the Chassis 7. If you are not installing the line card in another slot or chassis, return it to its anti-static bag and shipping container. Refer to Figure 126 on page 208.
Page 208: Figure 126: Placing The Ethernet Line Card In Its Anti-Static Bag
Chapter 8: Replacing Modules Figure 126. Placing the Ethernet Line Card in its Anti-static Bag 8. For instructions on how to install the card in another slot in either the same or a different chassis, refer to “Installing Ethernet Line Cards” on page 109.
Page 209: Replacing Fan08 Modules
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Replacing FAN08 Modules This section contains the procedure for replacing FAN08 Modules in the SBx908 Gen2 Switch. The procedures are listed here:  “Removing FAN08 Modules,” next  “Installing FAN08 Modules” on page 210 Removing FAN08 This procedure requires the following tool: Modules...
Page 210: Installing Fan08 Modules
Chapter 8: Replacing Modules Figure 128. Disconnecting the FAN08 Module from the Chassis 3. Continue with the next procedure to install a new FAN08 Module. Installing FAN08 This procedure requires the following tool: Modules  #2 Phillips-head screwdriver (not provided) The illustrations show the installation of the fan module in Fan A slot on the back panel.
Page 211: Figure 129: Aligning The Fan08 Module In The Chassis Slot
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 129. Aligning the FAN08 Module in the Chassis Slot 2. When you feel the module make contact with the connector inside the chassis, gently press on both sides to seat the module on the connector.
Page 212: Figure 131: Tightening The Two Captive Screws On The Fan08 Module
Chapter 8: Replacing Modules 3. Tighten the two screws on the module to secure it in the chassis. Refer to Figure 131. Figure 131. Tightening the Two Captive Screws on the FAN08 Module...
Page 213: Chapter 9: Troubleshooting
This chapter contains suggestions on how to troubleshoot problems with the switch. Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support. Problem 1: All the port LEDs and Switch ID LED are off, and the fans are not operating.
Page 214 Chapter 9: Troubleshooting  Verify that the DC circuit break has power by attaching another device to it.  Verify that the power from the DC circuit break is within the required levels of the power supply. Refer to “Power Specifications”...
Page 215 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking a different cable. If the twisted pair port is able to establish a link, then the problem is with the cable or the other network device.  Verify that the twisted pair cable does not exceed 100 meters (328 feet).
Page 216 If the trunk is using fiber optic transceivers, verify that they are fully inserted into the transceiver slots.  Verify that the transceivers are from Allied Telesis.  Verify that the fiber optic cables are securely connected to the ports on the transceivers.
Page 217 SBx908 GEN2 Installation Guide for Virtual Chassis Stacking STACKPORT command. Problem 9: The switch functions intermittently. Solutions: Check the hardware status through the management software:  Use the SHOW SYSTEM ENVIRONMENT command in the Privileged Exec mode to verify that the input voltage from the power source to the switch is stable and within the approved operating range.
Page 218 Chapter 9: Troubleshooting...
Page 219: Appendix A: Technical Specifications
Appendix A Technical Specifications This appendix contains the following sections:  ”Physical Specifications” on page 220  ”Environmental Specifications” on page 223  ”Power Specifications” on page 224  ”Certifications” on page 226  ”Pin Signals for RJ-45 Twisted Pair Ports” on page 227 ...
Page 220: Physical Specifications
Appendix A: Technical Specifications Physical Specifications Dimensions (H x W x D) Table 28 lists the product dimensions. The chassis dimensions are also shown in Figure 132 and Figure 133 on page 221. Table 28. Product Dimensions SBx908 Gen2 Chassis 13.3 x 44.1 x 47.3 cm (5.22 x 17.34 x 18.64 in.) (H x W x D)
Page 221: Figure 133: Switch Depth And Locations Of Bracket Holes
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 47.3 cm (18.64 in.) 31.88 mm (1.255 in.) 31.88 mm (1.255 in.) Figure 133. Switch Depth and Locations of Bracket Holes...
Page 222: Table 29: Product Weights
Appendix A: Technical Specifications Weights Table 29 lists the weights of the components. Table 29. Product Weights SBx908 Gen2 Chassis 15.81 kg (34.85 lb.) SBxPWRSYS2 AC Power Supply 2.70 kg (6.05 lb.) with power cord System SBxPWRSYS1-80 DC Power 1.9 kg (4.2 lb) Supply System XEM2-8XSTm Line Card 0.70 kg (1.54 lb.)
Page 223: Environmental Specifications
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Environmental Specifications Table 31 lists the environmental specifications of the switches. Table 31. Environmental Specifications Operating Temperature Range 0° C to 50° C (32° F to 122° F) Storage Temperature Range -25° C to 70° C (-13° F to 158° F) Operating Humidity Range 5% to 90% noncondensing Storage Humidity Range...
Page 224: Power Specifications
Appendix A: Technical Specifications Power Specifications This section contains the maximum power consumption values, input voltages, and heat dissipation values. AC Voltage, Frequency Requirements (Volts, Hertz) Table 32 lists the AC voltage and frequency requirements. Table 32. AC Voltage and Frequency Requirements SBxPWRSYS2 AC Power Supply 100 - 120 / 200 - 240 VAC 12/6A 50/60 Hz (per input)
Page 225: Table 35: Typical Power Savings In Eco-Friendly Mode (Watts)
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Typical Power Savings in eco-friendly Mode Table 35 lists the typical power savings in eco-friendly mode. Table 35. Typical Power Savings in eco-friendly Mode (Watts) XEM2-8XSTm Line Card 0.08 W XEM2-12XT Line Card 0.11 W XEM2-12XTm Line Card 0.10 W...
Page 226: Certifications
Appendix A: Technical Specifications Certifications Table 38 lists the product certificates. Table 38. Product Certifications EMI (Emissions) FCC Class A CISPR 22 Class A EN55032 Class A VCCI Class A ICES-003 Class A EMC (Immunity) EN55024 EN61000-3-2 EN61000-3-3 Electrical and Laser Safety UL 60950-1 ( EN60825-1 (TUV) RoHS...
Page 227: Pin Signals For Rj-45 Twisted Pair Ports
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Pin Signals for RJ-45 Twisted Pair Ports Figure 134 illustrates the pin layout of the RJ-45 connectors on the following line cards:  AT-XEM2-8XSTm  AT-XEM2-12XT  AT-XEM2-12XTm Figure 134. Pin Layout (Front View) of Twisted Pair Ports Table 39 lists the pin signals at 100Mbps.
Page 228: Table 40: Pin Signals On Twisted Pair Ports At 1/2.5/5/10Gbps
Appendix A: Technical Specifications Table 40 lists the pin signals at 1/2.5/5/10Gbps. Table 40. Pin Signals on Twisted Pair Ports at 1/2.5/5/10Gbps Pair Signal TX and RX+ TX and RX- TX and RX+ TX and RX+ TX and RX- TX and RX- TX and RX+ TX and RX-...
Page 229: Pin Signals For The Rj-45 Style Serial Console Port
SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Pin Signals for the RJ-45 Style Serial Console Port Table 41 lists the pin signals of the RJ-45 style serial Console port on the management panel. Table 41. RJ-45 Pin Signals for the Console Port on the Management Panel Signal Looped to pin 8.
Page 230: Pin Signals For The Net Mgmt Port
Appendix A: Technical Specifications Pin Signals for the NET MGMT Port Table 42 lists the pin signals for 10 and 100Mbps. Table 42. RJ-45 Pin Signals for 10 or 100Mbps for the NET MGMT Port on the Management Panel MDI Signal MDI-X Signal Not used Not used...

This manual is also suitable for:

Sbx908 gen2

Allied Telesis SwitchBlade x908 GEN2 Installation Manual

Chapter 1: Overview

Chapter 2: Virtual Chassis Stacking

Chapter 3: Beginning the Installation

Chapter 4: Installing the Chassis

Chapter 5: Wiring the Sbxpwrsys1-80 DC Power Supply

Chapter 6: Configuring Switches for Stacking

Chapter 7: Cabling XEM2 Line Card Ports

Chapter 8: Replacing Modules

Chapter 9: Troubleshooting

Appendix A: Technical Specifications

Quick Links

Need help?

Questions and answers

Related Manuals for Allied Telesis SwitchBlade x908 GEN2

Summary of Contents for Allied Telesis SwitchBlade x908 GEN2
