7.6

Sentinel Ordering Information

Table 16 below and Table 17 on page 14 show how the Sentinel Flow Measurement System part numbers are
configured from the options specified.
7.6.1

Spoolpiece Ordering Information

The information below shows how the Spoolpiece part number is configured from the options specified.
A B - C
Sentinel - -
LTR CATEGORY
B Nominal Pipe Size
C Uni/Bi-Directional
D Flange Class and
Pipe Bore
E Materials
F Valve
G Transducer Type
H Transducer
Material
I Transducer
Frequency
* Spoolpiece body length equals raised face to raised face.
Sentinel™ User's Manual
- D - E - F
- - -
6
= 6.0" (152.4) ID x 45.0" (1143.0) long*
8
= 8.0" (203.2) ID x 48.0" (1219.2) long*
10
= 10.0" (254.0) ID x 52.0" (1320.8) long*
12
= 12.0" (304.8) ID x 56.0" (1422.4) long*
14
= 14.0" (355.6) ID x 58.0" (1473.2) long*
16
= 16.0" (406.4) ID x 60.0" (1524.0) long*
18
= 18.0" (457.2) ID x 63.0" (1600.2) long*
20
= 20.0" (508.0) ID x 67.0" (1701.8) long*
24
= 24.0" (609.6) ID x 74.0" (1879.6) long*
0
= No Upstream Pipe
1
= One Upstream Pipe
2
= Two Upstream Pipes
30
= 300 Class Sch. 40
60
= 600 Class Sch. 80
1
= Pipe: ASTM A106 GR.B; Flange and Fitting: ASTM A105
2
= Pipe: ASTM A333 GR.6; Flange and Fitting: ASTM A350 LF2
0
= None
1
= Single Valve
1
= T11
1
= Titanium CP GR.2
2
= 316SS
1
= 100 kHz
2
= 200 kHz
- G - H - I
- 1 - -
OPTIONS
Chapter 7. Specifications
