6.4.2

T11 Transducer Installation Components

See Table 2 below and Figure 85 below for the components required to install the new transducer.
Table 2: Components at each Transducer Location
No.* Part Number
1 577-004-00
2 551-1135
3 410-538
4 410-539
5 412-1032-24
6 412-148
7
8
*Component numbers correspond to item numbers in Figure 85 below.
6.4.3

Installing a New Transducer in a Pressurized Pipe

IMPORTANT: The following procedures should be used only in situations where the process line is not shut down.
Sentinel™ User's Manual
Description
Sensor Holder
Sensor Flange
O-Ring, size 210 Viton
O-Ring, size 213 Viton
Screw, Cap Hex 3/8-16 x 1-1/2
Washer, Lock Split 3/8"
O-Ring-Safe Lubricant
Anti-Seize Lubricant
5 6
4 places
8
4 places
7 4
7 3
2 places
Figure 12: T11 Installation Components for a Pressurized Pipe
Chapter 6. Transducer Replacement
Qty.
1
1
2
1
4
4
A/R
A/R
2
T11 Transducer
1
111
