  • Page 1 Aurora H2O User’s Manual panametrics.com 910-317 B August 2022...
  • Page 3 Aurora H2O Moisture Analyzer for Natural Gas User’s Manual 910-317 B August 2022 panametrics.com Copyright 2017 Baker Hughes company. This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries in one or more countries. All third-party product and company names are trademarks of their respective...
  • Page 4 [no content intended for this page]...

  • Page 5: Table Of Contents

    3.4.6 Reverse ....................10 Aurora H2O User’s Manual...
  • Page 6 4.6.4 Editing Pressure Calibration ................19 Aurora H2O User’s Manual...
  • Page 7 No Flow Measurement Indicated on Aurora H2O Measurement Cell Outlet .......
  • Page 8 Using the MS Windows Telnet Client ................26 Aurora H2O User’s Manual...
  • Page 9 Chapter Product Registration Thank you for purchasing a model Aurora H2O from BH. Please register your product at www.bakerhughesds.com/productregistration for product support such as the latest software/firmware upgrades, product information and special promotions. Services BH provides customers with an experienced staff of customer support personnel ready to respond to technical inquiries, as well as other remote and on-site support needs.
  • Page 10 Make sure that operators and maintenance personnel have all safety equipment applicable to the auxiliary equipment. Examples include safety glasses, protective headgear, safety shoes, etc. Unauthorized Operation Make sure that unauthorized personnel cannot gain access to the operation of the equipment. viii Aurora H2O User’s Manual...
  • Page 11 Chapter Environmental Compliance RoHS The Aurora H2O fully complies with RoHS regulations. Waste Electrical and Electronic Equipment (WEEE) Directive BH Digital Solutions & Control is an active participant in Europe’s Waste Electrical and Electronic Equipment (WEEE) take-back initiative, directive 2012/19/EU.
  • Page 12 Chapter [no content intended for this page] Aurora H2O User’s Manual...

  • Page 13: Chapter 1. Features And Capabilities

    Features and Capabilities Overview BH’s Aurora H2O Moisture Analyzer for Natural Gas makes it possible for natural gas processing and transportation facilities to monitor moisture content in real-time with high precision and reliability. The Aurora H2O analyzer uses tunable diode laser absorption spectroscopy (TDLAS) to measure moisture in natural gas at the speed of light.

  • Page 14: Theory Of Operation

    As the concentration of water increases, the absorption also increases. The Aurora H2O sweeps the diode laser output across a narrow band in the near infrared spectrum and, by measuring the light intensity with a photodetector, is able to provide a direct indication of the partial pressure of water.
  • Page 15 The diode laser emits low energy light, and therefore the system will not ignite the gas. The complete system is rated explosion-proof, and the Aurora H2O provides very fast response time. Once the absorption cell (see Figure 1 below) is purged, the response time is a matter of a few seconds.
  • Page 16 Chapter 1. Features and Capabilities System Components (cont.) Note: Refer to Figure 2 below and Table 1 on page 6 to identify your Aurora components. Figure 2: Aurora H2O System Assembly with Optional USA/CAN Heater Aurora H2O User’s Manual...
  • Page 17 Chapter 1. Features and Capabilities System Components (cont.) Note: Refer to Figure 3 below and Table 1 on page 6 to identify your Aurora components. Figure 3: Aurora H2O System Assembly with Optional EU/ATEX Heater Aurora H2O User’s Manual...
  • Page 18 Membrane Filter Drain & Fast Loop Vent Pressure Regulator w/ 0-10 psig outlet pressure gauge Magnetic Stylus Process or Purge Gas Selector Purge Gas Inlet Needle Valve Absorption Cell Temperature Sensor Pressure Sensor Rotameter Optional Heater, thermostat, junction box Aurora H2O User’s Manual...
  • Page 19 Probe Length Part Probe Overall (See Detail A) Number Length Length 750-633 4.00" 11.80" 14.80" 750-634 7.00" 16.80" 750-635 9.00" 750-633 4.00" 11.80" 14.80" 750-634 7.00" 16.80" 750-635 9.00" 0.92 Figure 4: Sample System (ref. dwg #733-737) Aurora H2O User’s Manual...
  • Page 20 J-Box Terminal Customer Power Line 1 Brown Line 2 Blue Ground Green/Yellow Thermostat Line 1 Brown Line 2 Blue Ground Green/Yellow Heater Line 1 Brown Line 2 Blue Ground Green/Yellow Figure 6: EU/ATEX Heater Wiring Diagram Aurora H2O User’s Manual...

  • Page 21: Specifications

    ±0.2 ppm or ±0.1%, whichever is greater; for CO applications: ±1.0 ppm or ±0.5%, whichever is greater Calibration Certification: NIST or equivalent NMI traceable certification Calibration Options: Nitrogen, standard natural gas and 3 customizable calibration curves Aurora H2O User’s Manual...

  • Page 22: Response Time

    Three 0/4-20 mA DC (source) with 500 ohm load; user programmable for any parameter and scalable; complies with NAMUR protocol for analog signals Analog Input: Loop powered 4-20 mA input for remote pressure transmitter; Aurora supplies 24 VDC Aurora H2O User’s Manual...

  • Page 23: Enclosure

    20°C/68°F ±5°C/9°F for US/Canada; 10°C/50°F ±5°C/9°F EU and elsewhere 1.4.9 Hazardous Area Certification USA/Canada: Explosion-proof for Class I, Division 1, Groups B, C, D EU and Elsewhere: ATEX and IECEx: Ex de IIB+H2 T6 -20°C to +65°C; Flameproof with increased safety compartment Aurora H2O User’s Manual...
  • Page 24 Chapter 1. Features and Capabilities Aurora H2O User’s Manual...

  • Page 25: Chapter 2. Installation

    Unpacking The Aurora H2O is shipped in a packing box with a plywood base (see Figure 7 below), and the Aurora H2O analyzer is secured to the plywood base with mounting bolts. Transport the shipping package with the plywood base on the bottom, and according to the warning labels on the exterior packaging.

  • Page 26: Choosing A Site For Installation

    Unpacking (cont.) Remove the mounting studs at the bottom of the enclosure. Using two people, lift the Aurora H2O from the bottom of the enclosure and from the top of the enclosure where the analyzer electronics is located. A typical Aurora H2O weighs approximately 100 pounds (45 kg).
  • Page 27 Chapter 2. Installation Choosing A Site for Installation (cont.) Figure 8: Aurora H O Analyzer Monitoring Moisture Content Within a Natural Gas Pipeline Aurora H2O User’s Manual...

  • Page 28: Low Voltage Directive

    IMPORTANT: Installation must be done in accordance with the National Electrical Code, the Canadian Electric Code, and/or any other applicable local codes. Mounting Use the four mounting tabs to mount the Aurora H2O System Assembly in the desired location (see Figure 32 on page 21). IMPORTANT: The Aurora H2O should only be mounted vertically.

  • Page 29: Optional Insertion Probe/Regulator

    • Installing the Housing • Installing the Insertion Probe/Regulator Assembly 2.7.2.1 Installing the Housing The housing, as shown in Figure 10 below, is supplied with a Locking Mechanism to ensure that housing can only be removed intentionally. Aurora H2O User’s Manual...
  • Page 30 (see Figure 11 below). Do not allow the thread sealant to enter the slot, as it may interfere with the mechanism. Thread Sealant Figure 11: Applying Thread Sealant Aurora H2O User’s Manual...
  • Page 31 Using a wrench on the wrench flats, turn the housing until it is secure and sealed (see Figure 13 below). This will require between three and five turns. DO NOT OVERTIGHTEN! The housing may be damaged if it is over-tightened, causing the housing to deform. Wrench Flats 180° apart Figure 13: Tightening the Housing Aurora H2O User’s Manual...
  • Page 32 (see Figure 16 below). The torque value should be 10 inch-lbs. If the Allen cap screw is only hand-tight, the screw may protrude excessively, which could result in foot valve actuation when the probe is installed into the housing. Aurora H2O User’s Manual...
  • Page 33 Rotate the pressure adjustment screw on the pressure regulator fully counterclockwise until it rotates freely. Close the isolation ball valve (see Figure 17 below). Pressure Adjustment Screw Pressure Gauge Isolation Ball Valve Figure 17: Rotating the Pressure Adjustment Screw Aurora H2O User’s Manual...
  • Page 34 (see Figure 19 below). Note: The threaded nut on the housing ensures that if all other safety procedures are disregarded, it is mechanically impossible to remove the probe. Insertion Insertion Washer Housing Figure 19: Threading the Insertion Nut Aurora H2O User’s Manual...
  • Page 35 The threaded nut on the housing ensures that if all other safety procedures are disregarded, it is mechanically impossible to remove the probe. Perform the next step regardless of the status of the foot valve o-ring. Figure 21: Loosening the Insertion Nut Aurora H2O User’s Manual...
  • Page 36 (see Figure 22 below). At this point the foot valve opens and the insertion process is complete. Figure 22: Tightening the Insertion Nut Aurora H2O User’s Manual...

  • Page 37: Setting The Pressure

    Perform these steps only after the entire system has been plumbed, including the Aurora H2O. Ensure the inlet sample gas isolation valve on the Aurora H2O sample system is closed. Open the isolation ball valve at the Optional Pipeline Insertion Membrane Liquid Separator/Pressure Regulator.

  • Page 38: Making Electrical Connections

    Refer to Figure 33 on page 22 for wiring connections. Aurora H2O has three ¾” NPT conduit inlet ports for power and I/O (see Figure 24 below). These will normally be shipped plugged from the factory. Follow the applicable wiring code and requirements for wiring the unit.
  • Page 39 Figure 26: Power Terminal Block Use wiring conduit runs, separate from the Aurora H2O main power, for all I/O (Input/Output) leads. Wire up to three 4-20mA outputs to the terminals labeled A, B, and C. The three analog outputs A, B and C (0-20mA or 4-20mA) are internally powered by the Aurora H2O.
  • Page 40 Making Electrical Connections (cont.) Multi-drop RS-485: For multiple Aurora H2O units connected in daisy-chain fashion to the RS485 interface, it is important that the farthest unit away from the transmitting device be the only unit incorporating any termination (see Figure 27 below).
  • Page 41 Prepare a shielded CAT5e Ethernet cable with flying leads compatible with the TIA/EIA-568 specification. For proper operation, Aurora H2O requires connection of the TX and RX pairs, as well as the shield wire. Connect the leads per Figure 29 and the table below, depending on the cable used:...

  • Page 42: Specific Conditions Of Use

    If the Aurora H2O has been supplied with an optional electrical heater, there are two possible configurations: USA/CAN or EU. Connect the AC power using a separate conduit from the power for the Aurora H2O analyzer. The heater is equipped with a thermostat preset to 25°C (77°F) nominal. Use 12-18 AWG (3.3 - 0.82 mm ) wires.
  • Page 43 Chapter 2. Installation The laser head assembly of the Aurora H2O Moisture Analyzer shall be inside a tool secured enclosure with IP20 or better to ensure the factory installed laser head assembly bolts are inaccessible from the outside. Consult the manufacturer for genuine replacement flange fasteners. 5/16 inch-24 x 1-1/4 inch 18-8 stainless steel socket head cap bolts or better with a minimum tensile strength of 70,000 psi are acceptable alternatives.
  • Page 44 Chapter 2. Installation Aurora H2O User’s Manual...
  • Page 45 15.66 13.08 .125 10.92 1.622 9.29 TYP 3.18 TYP 33.12 24.26 24.91 26.16 10.24 18.31 Aurora H2O User’s Manual...
  • Page 46 Aurora H2O User’s Manual...
  • Page 47 Aurora H2O User’s Manual...

  • Page 48: Chapter 3. Operation And General Programming

    Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Sample System See the instructions below and Figure 34 on page 3 to operate the Aurora H2O sample system. 3.2.1 Aurora H2O Startup Supply gas inlet pressure should be <400 psig (2758 kPa).

  • Page 49: Aurora H2O Shut Down

    Chapter 3. Operation and General Programming 3.2.2 Aurora H2O Shut Down Fully close the supply gas isolation valve (item 4) by turning it clockwise. Turn the supply gas pressure regulator (item 6) fully counter-clockwise. Fully close the bypass and sample gas metering valves (Items 2 and 3) by turning them clockwise.
  • Page 50 ISOLATION VALVE 8. MEMBRANE FILTER 2. BYPASS GAS METERING VALVE 6. SUPPLY GAS PRESSURE REGULATOR 1. GAS SELECTOR VALVE 3. SAMPLE GAS 7. SAMPLE GAS METERING VALVE FLOWMETER Figure 34: Aurora H2O Sample System (ref. dwg #902-004_revE) Aurora H2O User’s Manual...

  • Page 51: Keypad Features

    Enter Up, Left, Right, Down Arrows   The Aurora H2O has seven keys: a Menu key, four Arrow keys, a Cancel key, and an Enter key. • Use the Menu key to open the main menu on the display.

  • Page 52: Indicator Lights

    By touching the clear window at a key location, that key will be selected and will flash a red light to verify the contact. Figure 36: Magnetic Stylus 3.3.3 The Default Display Figure 37 below shows the default display of the Aurora H2O window. Primary Alt 1 Alt 2 Figure 37: Default Display...

  • Page 53: Unlocking The Keypad

    Aurora H2O. Similar to a mobile phone, the Aurora H2O will prompt the operator to unlock if any key is pressed. A passcode is required to use certain factory service features only.

  • Page 54: Accessing The Menus

    Figure 39: Main Menu 3.3.7 Entering Numeric Values Since the Aurora H2O has no numeric keypad, numeric values are entered using a “combination lock” style of entry:  Use the left and right arrow keys to select the digit to change.

  • Page 55: Starting Up

    3.3.8 Starting Up After proper installation, the Aurora H2O Transmitter can be set up to accommodate the user’s requirements. Typically, the user may need to configure the analog outputs, trim the analog outputs, and program the digital outputs. Refer to the Menu Map, Figure 49 on page 29, and complete the following steps. Upon startup, the Aurora H2O proceeds through several displays until a screen similar to the following appears: After startup, the screen will need to be unlocked.

  • Page 56: Selecting Alt 1 And Alt 2 Units

    2f waveform (scan), from the Display Menu use the arrow keys to highlight Data/Scan and press Enter. A screen similar to the following appears. Note: The scan can be used for diagnostic purposes when a PC with AuroraView is not readily available. Aurora H2O User’s Manual...

  • Page 57: Data/Scan

    Use the arrow keys to select the output (A, B or C) to be set up, and press Enter. 3.5.2Selecting Output Units To adjust the output units, from the Output Menu select Units and press Enter. A screen similar to the following appears. Output Menu [Out Select Lower Units NAMUR Aurora H2O User’s Manual...

  • Page 58: Selecting An Output Type

    Output Menu. 3.5.6NAMUR Response The Aurora H2O can report measurement failure information via the analog outputs. The signal presentation of failure information is consistent with by the recommendations established by the “User Association of Automation...
  • Page 59 Upper (Span) settings determine the measurement value assigned to 4.0 and 20.0 mA, respectively. For the measurement assigned to an output, the Aurora H2O continuously checks if an error has occurred. If an error has occurred, the output will be driven to a current which is within the Error Information bands displayed above. The Aurora H2O can signal 3.5 mA ('NAMUR Low') or 21.1 mA ('NAMUR High').

  • Page 60: Testing The Output

    3.5.7 Testing the Output The Test Menu causes the Aurora H2O to generate a 0- or 4-20mA output at the percent of scale selected. For example, in 4-20 operation, 0% = 4mA, 50% = 12mA, 100% = 20mA. This allows the proper function of recording or SCADA equipment to be Output Menu [Out verified.

  • Page 61: Setting Up The Alarms

    The operator enters “19.985” as the Span Trim value. Aurora H2O adjusts the output accordingly to true the output as read by the customer recorder, SCADA or DVM. Using the Test Menu, the operator verifies that a test value of 0% now reads 4.000 mA at the SCADA equipment, and a test value of 100% now reads 20.000 mA.

  • Page 62: Selecting Alarm Units

    Press Enter to save (or Cancel to keep the previous value), and return to the Alarm Menu. If Pressure was selected, this display appears. Use the arrow keys to select a unit. Press Enter to save (or Cancel to keep the previous value), and return to the Alarm Menu. Aurora H2O User’s Manual...

  • Page 63: Selecting An Alarm Type

    Reset Trip Figure 42: Example of Alarm Types 3.6.6 Changing the Upper Alarm Span To adjust the upper alarm span, from the Alarm Menu select Upper and press Enter. A screen similar to the following appears. Aurora H2O User’s Manual...
  • Page 64 Use the left and right arrow keys to select each digit to be changed and the up and down arrow keys to increase or decrease its value. Press Enter to save (or Cancel to keep the previous value), and return to Output Menu. Aurora H2O User’s Manual...
  • Page 65 Chapter 3. Operation and General Programming Aurora H2O User’s Manual...

  • Page 66: Chapter 4. Programming Advanced Features

    4.1.1Selecting a Comm Port There are two physical comm ports in the Aurora H2O. Comm Port 1 is aligned to SCADA in the instrument program and Comm Port 2 is aligned to SERVICE. This setup enables the...

  • Page 67: Setting The Parity

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the Comm Port Menu. Aurora H2O User’s Manual...

  • Page 68: Selecting The Protocol

    Serial Port Test mode, using a serial terminal or terminal emulation software. Configure the terminal to the same parameters specified for the Aurora H2O in “Setting the Baud Rate” on page 1, “Setting the Parity” on page 2 and “Selecting the Protocol” on page 2.

  • Page 69: Serial Port Test

    Figure 44: Response to “ABCDE” Entry Note: The Aurora H2O will remain in test mode until it is turned off or it is reset or power-cycled. Ethernet Settings The Aurora H2O supports Modbus/TCP over Ethernet. This enables remote access to measurement and diagnostic data whenever an Ethernet LAN connection is available.

  • Page 70: Connecting To An Ethernet Lan

    RealPort (serial emulation) mode. After a Factory Reset, it is necessary to log in via the HTML or Telnet command interface, and reconfigure the network and Modbus settings (see Appendix B. “Aurora H2O Ethernet Operation” for detailed instructions).

  • Page 71: Device Discovery

    Aurora H2O. See Appendix B. “Aurora H2O Ethernet Operation” for detailed instructions. Note: The Ethernet module is not enabled and the Aurora H2O will not be visible on the network until the Aurora completes laser startup. Aurora H2O User’s Manual...

  • Page 72: Adjust Offset Values

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the User Adjustments menu. Aurora H2O User’s Manual...

  • Page 73: Adjusting The Scan Averaging

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the User Adjustments Menu. Aurora H2O User’s Manual...

  • Page 74: Setting The Dew Point Calculation Method

    There can be a difference of several degrees C between the dew point and the frost point. • When set for Dew/Frost, the Aurora H2O will report the Dew Point if the reading is above freezing, and will report the Frost Point if the reading is below freezing.

  • Page 75: Saturation Calculation

    From the Select Calc Options Menu select Saturation and press Enter. The following screen appears. Use the arrow keys to highlight the desired saturation calculation method (ASTM or GOST) and press . The screen returns to the User Adjustments Menu. Enter Aurora H2O User’s Manual...

  • Page 76: Set Up The Background Gas

    Set Up the Background Gas 4.4.1 Selecting the Type of Gas The Aurora H2O TDLAS is normally calibrated to a standard gas mixture that is representative of “typical” natural gas. The primary components and concentrations of this gas mixture are: Component...

  • Page 77: Setting The Z Factor

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the Settings Menu. Aurora H2O User’s Manual...

  • Page 78: Entering A Label

    Case Select Highlighted) Text Edit “Keyboard” Figure 46: Alphanumeric Entry Control The alpha menu is divided into three sections. The active section will have something highlighted (reverse video). The Up/Down arrows are used to move between sections. Aurora H2O User’s Manual...
  • Page 79 Note that the Context Menu has changed again; it displays prompts of available key actions when in the keyboard. In Keyboard, the Left / Right / Up / Down arrows move the highlight from character to character in the keyboard. Aurora H2O User’s Manual...

  • Page 80: Adjusting The Gas Offset

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the Settings Menu. Aurora H2O User’s Manual...

  • Page 81: Clock Settings

    When finished, press Enter. The screen returns to the Clock Menu. 4.5.4Resetting the Date To reset the date, from the Clock Menu select Date and press Enter. The following screen appears. Aurora H2O User’s Manual...

  • Page 82: Resetting The Year

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the Clock Menu. Aurora H2O User’s Manual...

  • Page 83: Pressure Settings

    Use the left and right arrow keys to select each digit to be changed. Use the up and down arrow keys to change the value. When finished, press Enter. The screen returns to the Pressure Menu. Note: Data entry for this setting is in the units selected in Section 4.6 above. Aurora H2O User’s Manual...

  • Page 84: Editing Pressure Calibration

    Input a “constant” value if the line pressure is at a normal pressure, or use an external pressure transmitter to input a “live” pressure input into the Aurora H2O analyzer. To edit the pressure calibration, from the Line Pressure Source Menu, select Live and press Enter.

  • Page 85: 4.7Regional Settings

    When finished, press Enter. The screen returns to the previous menu. 4.7Regional Settings This section enables the setting of regional information, depending on the location of the Aurora H2O. To reset the regional settings, from the Settings Menu, select Locale... and press Enter. The following screen appears.

  • Page 86: Setting The Decimal Format

    Beginning with software revision H2O.001.F, the Aurora H2O supports a two-point User Calibration for use in methane/natural gas. This is provided so that a field calibration can be easily performed to cause the Aurora H2O measurement to correspond to a calibration gas or other moisture device. The User Calibration is independent from, and does not affect, the Factory Calibration.
  • Page 87 Background Gas. Choose Settings... from the Main Menu. A User Cal... selection is now provided. Note: If the Aurora H2O is set for Nitrogen as the background gas, the User Cal selection will be disabled/grayed out.
  • Page 88 Read Zero The Aurora H2O will read the signal while exposed to the Zero gas. Read Span The Aurora H2O will read the signal while exposed to the Span gas, then determine the CH4 Offset and Scalar calibration values. CH4 Offset Permits the user to view/edit the calculated offset term.

  • Page 89: Service Settings

    When the reading is stable, select Read Span. The Aurora H2O uses the current measurement, and immediately calculates the new calibration. If the calculated values are determined to be valid, the Aurora H2O will display “Calibration OK” and prompt you to Save the results, or Cancel. If the values are not valid, the Aurora will display “Calibration *FAILED*”, and prompt you to continue.

  • Page 90: 4.10 Aurora H2O Information

    To return to the About Menu, press Enter. 4.10.2Checking the System Status To view the status of the Aurora H2O system, from the About Menu select System Status and press Enter. A screen similar to the following appears. Uptime: is the elapsed time since the Aurora H2O was powered on or reset.

  • Page 91: 4.10.3 Checking The Software

    To return to the About Menu, press Enter. 4.10.4Checking the Gas Composition To view the gas content, from the About Menu select Gas Composition and press Enter. A screen similar to the following appears. To return to the About Menu, press Enter. Aurora H2O User’s Manual...

  • Page 92: 4.10.5 Checking The Alternate Gas Composition

    For special applications, where the composition of the gas to be measured differs significantly from the standard, BH can provide an alternate calibration. If this service has been ordered, the Aurora H2O will be shipped from the factory with both the standard and a custom calibration installed.

  • Page 93: Locking/Unlocking The Display

    4.11 Locking/Unlocking the Display To lock the Aurora H2O against any future changes, from the Main Menu select Lock and press Enter. The screen returns to the standard display. Note: This menu option is the same as exiting the programming menu and waiting for a keypad time-out to lock the keypad.
  • Page 94 Use the Escape ( ) key to Trim... Upper cancel an entry and return to the previous screen. Select Output, Select Alarm, Reset Trim Enter Max. Value Trim Zero Lower Select Alarm, Enter Min. Value Trim Span Aurora H2O User’s Manual...
  • Page 95 Use the Enter ( ) key to accept a selection and Select Protocol: move to the next menu. Use the Escape ( ) key to RS-232 cancel an entry and return to the previous screen. RS-485 Network ID Set Node ID: Aurora H2O User’s Manual...
  • Page 96 Aurora H2O User’s Manual...

  • Page 97: Chapter 5. Auroraview Interface Software

    • Aurora H2O software updates. • Save the Aurora H2O Configuration. The Aurora H2O has a robust design which allows the meter to recover from fault conditions without the need to upload the configuration of the meter using external software.

  • Page 98: Installing Auroraview

    Installing AuroraView Insert the Installation CD into the optical drive on your PC.   The installation program should launch automatically (see Figure 51 below). If it does not, select Start Browse. Figure 51: Initial Screen Aurora H2O User’s Manual...
  • Page 99 Chapter 5. AuroraView Interface Software Installing AuroraView (cont.) Browse to the file named “setup.exe” in the root directory of the CD (see Figure 52 below). Double-click the file to start the installation. Figure 52: AuroraView Installer Aurora H2O User’s Manual...
  • Page 100 Chapter 5. AuroraView Interface Software Installing AuroraView (cont.) Exit all other programs before running the installer (see Figure 53 below). Figure 53: Installation Recommendation Aurora H2O User’s Manual...
  • Page 101 The next screen (see Figure 55 below) provides the opportunity to change installation locations if desired. When ready, click Next. Figure 54: Destination Directory At the next screen, accept the Software License Agreement (see Figure 55 below) and click Next. Figure 55: Software License Agreement Aurora H2O User’s Manual...
  • Page 102 Chapter 5. AuroraView Interface Software Installing AuroraView (cont.) The next screen (see Figure 56 below) provides instructions for initiating the installation. When ready, click Next to begin. Figure 56: Starting the Installation Aurora H2O User’s Manual...
  • Page 103 Chapter 5. AuroraView Interface Software Installing AuroraView (cont.) During installation, the screen shown in Figure 57 below appears. Figure 57: Overall Progress Aurora H2O User’s Manual...
  • Page 104 Chapter 5. AuroraView Interface Software Installing AuroraView (cont.) The screen shown in Figure 58 below appears when the installation is complete. Figure 58: Installation Is Complete Aurora H2O User’s Manual...

  • Page 105: Starting Auroraview

    Chapter 5. AuroraView Interface Software Starting AuroraView   From the Start menu, click Programs AuroraView AuroraView (see Figure 59 below). Figure 59: AuroraView in Programs Menu Aurora H2O User’s Manual...
  • Page 106 AuroraView boots up and displays a screen similar to Figure 60 below. Command Line Scan Plots Tab Trend Plots Tab Trend Tabular Data Tab Alarms Status Reading Interval Datalog Interval Current Readings Pane Figure 60: AuroraView Main Screen Aurora H2O User’s Manual...

  • Page 107: Using The Main Menus

    • Read: Check this box if you want to show the value in the current Readings pane. • Plot: Check this box if you want to show the value in the Trend Plots graph AND the Trend Tabular Data tab. Aurora H2O User’s Manual...
  • Page 108 This window enables the user to configure the alarm status within the AuroraView application. This feature allows you to remotely configure Aurora H2O alarms, which are used only with Modbus RTU digital output. The AuroraView Alarms are shown in Figure 62, Figure 63 and Figure 64 below.
  • Page 109 Config (see Figure 65 and Figure 66 below). Figure 65: Outputs Configuration Set Zero or Lower Range; Set Output Parameter Set Span or Upper Range Set Output Type: 0-20mA or 4-20mA Figure 66: Other Output Options Aurora H2O User’s Manual...
  • Page 110 This section enables you to pick the desired type of scan. The default scan is the SPECTRA scan, which shows the 2f spectral scan. This is the processed signal waveform that the Aurora H2O uses to determine the moisture concentration. Viewing this scan may assist in troubleshooting. A typical 2f spectra scan is shown in Figure 68 below.
  • Page 111 115200 bps, 8 data bits, even parity, and 1 stop-bit, which is also the default in the Aurora. If you have more than one Aurora H2O on an RS485 network, you will have to establish a different NETWORK ID for each analyzer, using the keypad on the Aurora H2O.
  • Page 112 Chapter 5. AuroraView Interface Software Click Help (see Figure 71 below). This screen indicates the version of AuroraView currently installed. Figure 71: Software Information Aurora H2O User’s Manual...

  • Page 113: Datalogging With Auroraview

    When you are done datalogging, click the button to stop logging. You may now open your .txt datalog file in any application, such as Microsoft Excel, so that you can analyze that data. Note: When datalogging multiple parameters at intervals of five seconds or less, it is recommended to use baud rates of 57.6K or 115.2K. Aurora H2O User’s Manual...

  • Page 114: Working With Trend Plots, Trend Tabular Data And Scan Plots

    Figure 73: Using Trend Plots Note: If you use the secondary y-axis, you may see “–” tick marks preceding the value. These are tick marks from the graphical applet and not an indication of negative values. Aurora H2O User’s Manual...
  • Page 115 • Zoom Tool - gives you six options as shown in Figure 76 below. • Hand Tool - Enables you to graph the trend plot area and move it around without rescaling. Zoom X-axis Zoom Y-axis Zoom window Zoom in Zoom all Zoom out Figure 76: Zoom Tool Aurora H2O User’s Manual...
  • Page 116 Copying and Pasting a Trend Plot can be done from AuroraView (see Figure 77 and Figure 78 below) One way to do this quickly is to simply right click over the data area and choose Copy. In another application, like Microsoft Word, simply paste. Figure 77: Copying a Trend Plot Figure 78: Pasting a Trend Plot Aurora H2O User’s Manual...
  • Page 117 Pasting an enhanced metafile will give you the ability to paste an image with an inverted color scheme as shown in the second example posted into Word (see Figure 81 on page 22). Figure 79: Exporting a Simplified Image Aurora H2O User’s Manual...
  • Page 118 Chapter 5. AuroraView Interface Software Working with Trend Plots, Trend Tabular Data and Scan Plots (cont.) Figure 80: Selecting Enhanced Metafile Figure 81: Pasting an Enhanced Metafile Aurora H2O User’s Manual...
  • Page 119 Working with Trend Tabular Data, you will be able to see data in tabular format as shown in Figure 82 below. You can adjust column widths to see data more easily with full titles in the header row. Figure 82: Trend Data in Tabular Format Aurora H2O User’s Manual...
  • Page 120 Chapter 5. AuroraView Interface Software Aurora H2O User’s Manual...

  • Page 121: Chapter 6. Maintenance

    Cleaning the Mirror The Aurora H2O analyzer may provide the message Weak Signal Return - Check Mirror on the top line of the display, along with the red light “!” to the left of the main display. If this occurs, the mirror and/or the optical window of the measuring cell may be contaminated due to liquid or particulate coating/deposition.
  • Page 122 The mirror can be removed from the end of this cell for cleaning WITHOUT DISMOUNTING the cell. Be sure to follow the correct mirror cleaning procedure for your version of the optical absorption cell assembly. Figure 83: Style 1 (Left) and Style 2 (Right) Optical Absorption Cell/Mirror Assemblies Aurora H2O User’s Manual...
  • Page 123 Handle the mirror assembly with extreme care. Performance of the analyzer is critically dependent upon the mirror integrity. Do not touch the mirror surface with any tools, objects, hands or fingers. Alignment Pin Mirror Figure 85: Handling the Mirror Assembly Aurora H2O User’s Manual...

  • Page 124: Instructions For Optical Absorption Cell Style 1

    Place the mirror assembly on a flat surface and repeatedly puff the air blower to force dry clean air onto the mirror surface (see Figure 87 below). Figure 87: Blowing Air onto the Mirror Aurora H2O User’s Manual...
  • Page 125 Place the wet lens tissue on top of the mirror and drag it horizontally across the surface of the mirror (see Figure 89 below), ensuring minimal liquid residue/streaks are left behind on the mirror surface. Figure 89: Dragging the Wet Lens Tissue Across the Mirror Aurora H2O User’s Manual...
  • Page 126 Visually inspect the mirror, and record any observation of gross contamination. If the mirror does not appear to be clean after repeated cleanings, contact BH Technical Support for further assistance. 10. If the mirror does appear to be clean, re-install it onto the measurement cell. Aurora H2O User’s Manual...
  • Page 127 14. Re-establish power to the Aurora H2O analyzer. 15. Re-establish the flow through the sample system. 16. If the Aurora H2O still indicates a Check Mirror fault after normal start-up, contact BH Technical Support for further assistance. Aurora H2O User’s Manual...
  • Page 128 Figure 92: Removing Mirror End Cap Assembly from the Absorption Cell CAUTION! Handle the mirror assembly with extreme care. Performance of the analyzer is critically dependent upon the mirror integrity. Do not touch the mirror surface with any tools, objects, hands or fingers. Aurora H2O User’s Manual...

  • Page 129: Instructions For Optical Absorption Cell Style 2

    Typically, one drop of acetone will suffice. Tilt the lens tissue so that the acetone drop is absorbed by the lens paper along the length of the piece (see Figure 88 on page 5 and Figure 94 below). Figure 94: Applying Acetone to Lens Tissue Aurora H2O User’s Manual...
  • Page 130 12. If the mirror does appear to be clean, replace it into the mirror end cap, taking care not to disturb the two O-rings in the assembly (see Figure 96 below), Prepare to re-install the mirror end cap assembly into the optical absorption cell. Figure 96: Replacing Cleaned Mirror into End Cap Assembly Aurora H2O User’s Manual...
  • Page 131 14. Re-establish power to the Aurora H2O analyzer. 15. Re-establish the flow through the sample system. 16. If the Aurora H2O still indicates a Check Mirror fault after normal start-up, contact BH Technical Support for further assistance. Aurora H2O User’s Manual...

  • Page 132: Replacing The Filter Element

    Chapter 6. Maintenance Replacing the Filter Element The Aurora H2O uses a membrane filter (see Figure 98 to the left) as the secondary filter. This filter is intended to prevent liquid or particulate contamination from entering the absorption cell. The Aurora should not be operated without a filter train upstream of the unit.
  • Page 133 Figure 100: Orient the Filter Cap and Remove the Large O-Ring Remove the white membrane filter element and the membrane backing plate (see Figure 101 below). Figure 101: Remove the White Filter Element and the Backing Plate Aurora H2O User’s Manual...
  • Page 134 Using a tissue, clean the filter components (see Figure 103 below). Large O-Ring Backing Plate Membrane Filter Small O-Ring Figure 103: O-Rings, Membrane Filter and Backing Plate Removed Re-assemble the filter, and reinstall the cap hand–tight. Aurora H2O User’s Manual...

  • Page 135: Chapter 7. Troubleshooting

    • A fault is a non-recoverable condition that can affect the quality of measurement by the Aurora H2O. Fault messages are accompanied by a slow flashing (!) indicator.
  • Page 136 Aurora H2O has detected a failure in the laser temperature control. FAULT: TEC FAIL Fault Contact the factory for assistance. The pressure in the Aurora H2O sample cell is greater than 212 kPa WARNING - Warning Sample Pressure TOO HIGH (30.75 psia).

  • Page 137: No Flow Measurement Indicated On Aurora H2O Measurement Cell Outlet

    Verifying Aurora H2O Performance in the Field There are two methods for verifying the performance of the Aurora H2O in the field. The first method is to use a portable hygrometer such as BH's PM880 portable hygrometer. The second method is to use a moisture generator or standard gas cylinder.

  • Page 138: Using A Moisture Standard

    Whether using a moisture generator or a standard moisture gas cylinder, the source gas should be connected to the Aurora H2O using the PURGE INLET on the analyzer. Ensure that the sample gas pressure is regulated to a just barely positive pressure and establish gas flow from the PURGE INLET to the Aurora H2O measurement cell.
  • Page 139 (shown in unlocked position) Figure 106: Background Selection Lockout Switch Location Attempting to access the Background Gas Selection menu with the switch in the Locked Out (down) position will result in the following message being displayed: Aurora H2O User’s Manual...
  • Page 140 Chapter 7. Troubleshooting Aurora H2O User’s Manual...

  • Page 141: Appendix A. Modbus Rtu/Tcp Communications

    • Revision number Aurora H2O supports data types of Integer and Double/Float. Integer data types are always four (4) bytes long and should be read with a request for two registers (two bytes per each register, two registers total) at the address.

  • Page 142: Modbus Registers

    All registers denoted with a bullet (•) in the Read-Only column are read-only registers and should be read with the function “Read Input Registers.” All other registers can be read and written with “Read Holding Registers” or “Write Multiple Registers.” Note: The Modbus Register Address map supported by Aurora H2O is shown in Table 7 below. Functio Parameter Description...
  • Page 143 0-20mA Trim Reading Zero 3.0 ~ 5.2 Double/Floa Trim Reading Span 10.0 ~ 22.2 Double/Floa Upper of Value –10000 ~ 10000 Double/Floa Lower of Value –10000 ~ 10000 Double/Floa Test % value of output, Double/Floa 0~100 Aurora H2O User’s Manual...
  • Page 144 0 = OFF, 1 = ON Integer Units Reg. address of Meas. Integer Type Set Point = 0, In Band Integer = 1, Out Band = 2 Upper Depends on unit type Double/Floa Lower Depends on unit type Double/Floa Aurora H2O User’s Manual...
  • Page 145 Pressure Zero Calibration, mA 0~22 mA Double/Floa Pressure Span Calibration, mA 0~22 mA Double/Floa Pressure Zero Calibration, kPa 0~3500 kPa Double/Floa Pressure Span Calibration, kPa 0~3500 kPa Double/Floa Pressure Source Constant Value = 0, Integer Live Sensor = 1 Aurora H2O User’s Manual...
  • Page 146 Serial Number Bytes Laser ------ ------ 8 Character • Serial Number Bytes Calibration Month 1~12 Integer • Date Date Depends on month Integer • Year 2000~2100 Integer • System Up MSDate Uptime, in days Double/Floa • Time Aurora H2O User’s Manual...
  • Page 147 Double/Floa • ------ Double/Floa • kg/cm Bars ------ Double/Floa • mmHg ------ Double/Floa • ------ Double/Floa • Concentratio Lbs MMSCF ------ Double/Floa • ------ Double/Floa • mg/sm g/sm3 ------ Double/Floa • Vapor ------ Double/Floa • Pressure Aurora H2O User’s Manual...
  • Page 148 Appendix A. MODBUS RTU/TCP Communications Aurora H2O User’s Manual...
  • Page 149 Attempting to write to Trim registers 2x40/2x50 without first writing to Trim State register 2x00 will fail with Modbus exception 4. At the end of calibration, write 0 to 2x00 to make Aurora H2O exit trim mode. Aurora H2O User’s Manual...

  • Page 150: Modbus System Status Codes

    Aurora H2O could not detect any signal from the laser. Contact the factory for assistance. 0x00004000 Aurora H2O could not detect a signal returned from the sample cell, or the signal is below 0x00010000 allowed limits. Check the mirror for contamination.

  • Page 151: Appendix B. Aurora H2O Ethernet Operation

    Device Discovery If no DHCP server is present on the LAN, Device Discovery will still allow you to identify the Aurora H2O, and begin the configuration process. Confirm the Media Access Control (MAC) address displayed with the MAC address label on the Aurora H2O Ethernet connector.
  • Page 152 Appendix B. Aurora H2O Ethernet Operation Use the Open web interface option on the Device Tasks menu. The default web browser will launch and will display the Aurora H2O login page shown in Figure 107 below: Figure 107: Web Server - Login Page...

  • Page 153: User Accounts

    Misuse of the root account could prevent connection to the Aurora H2O, or enable unauthorized access to the Aurora H2O, or possibly expose the network to unauthorized users and exploits. The default login credentials for the root account are: •...
  • Page 154 Appendix B. Aurora H2O Ethernet Operation B.3.1 The Root Account (cont.) The root password can be changed via the Users menu under Configuration, as shown in Figure 109 below: Figure 109: Web Server - User Configuration Page Click on the root link to enter and confirm a new password for the root account:...
  • Page 155 Appendix B. Aurora H2O Ethernet Operation B.3.1 The Root Account (cont.) Enter the new password. Then, re-enter the password for confirmation and click Apply (see Figure 110 below). The password will be changed immediately. Figure 110: Web Server - Changing a Password...

  • Page 156: B.3.2 The Operator Account

    Appendix B. Aurora H2O Ethernet Operation B.3.2 The Operator Account The operator account is provided to perform limited configuration management of the Aurora H2O Ethernet option. The operator account has a reduced set of options, permissions, and capabilities. It is designed for use by field personnel performing commissioning or service of the Aurora H2O.

  • Page 157: Communicating By Modbus Via Ethernet

    • MODBUS/TCP over Ethernet • MODBUS/RTU over Ethernet The Aurora H2O and the Ethernet option must be correctly configured for the desired communications mode. B.4.1 MODBUS/TCP Note: As shipped, the Aurora H2O is configured to use the Modbus/TCP Ethernet protocol.

  • Page 158: Modbus/Rtu

    To change the default MB/TCP Ethernet protocol and use the MB/RTU protocol instead, follow the instructions in this section. Select MODBUS/RTU (MB/RTU) from the Aurora H2O menu (Main Menu, Settings…, Ethernet…, Protocol). To use Modbus/RTU over Ethernet, the Ethernet module must also be configured as follows: Log in to the web user interface.

  • Page 159: Using Telnet For Configuration

    Appendix B. Aurora H2O Ethernet Operation Using TELNET for Configuration If a web browser is not available or not practical in a given situation, the Telnet server can be used to perform configuration changes. Telnet is a text-based system that provides a Command Line Interface (CLI) to the Ethernet module.

  • Page 160: Using The Ms Windows Telnet Client

    Appendix B. Aurora H2O Ethernet Operation Using the MS Windows Telnet Client At a Windows command prompt, enter telnet to run the Telnet client (see Figure 114 below). Figure 114: Telnet Client To connect to the module, use the OPEN command with the IP address of the module (see Figure 115 below).
  • Page 161 Appendix B. Aurora H2O Ethernet Operation Using the MS Windows Telnet Client (cont.) At the module login: prompt, log in using the root account. Your password will not be echoed back. Upon success- ful login, the #> module prompt is displayed (see Figure 116 below).
  • Page 162 Appendix B. Aurora H2O Ethernet Operation Using the MS Windows Telnet Client (cont.) A list of other available commands and their usage can be displayed by entering help or ? at the #> prompt (see Figure 118 below). To disconnect the telnet session, enter quit or exit. At the Microsoft Telnet> prompt, enter quit again to return to the Windows command prompt.
  • Page 163 Filter Element, Replacing 7, 12 Gas Molecular Weight, Adjusting 11 Heater EU/ATEX 5, 8 USA/CAN 4, 8 Indicator Lights 5 Insertion Probe/Regulator Description 5 Installation 5 Setting the Pressure 13 Installation Choosing a Site 2 Mounting 4 Installation, System 1 Aurora H2O User’s Manual...
  • Page 164 Regional Settings 20 Registration vii Replacing the Filter Element 7, 12 Safety Auxiliary Equipment viii General Issues vii Personal Equipment viii Sample System Operation 1 Services vii Settings, Regional 20 Site Location 2 Spare Parts 1 Aurora H2O User’s Manual...
  • Page 165 No Flow Measurement 3 Status Messages and Indicators 1 Using a Moisture Standard 4 Using a Portable Hygrometer 3 Verifying Performance 3 Typographical Conventions vii Unpacking 1 Wiring 14, 22 Wiring Diagram EU/ATEX Heater 8 USA/CAN Heater 8 Aurora H2O User’s Manual...
  • Page 166 Aurora H2O User’s Manual...
  • Page 167 If BH Digital Solutions determines that the damage is not covered under the terms of the warranty, or if the warranty has expired, an estimate for the cost of the repairs at standard rates will be provided. Upon receipt of the owner’s approval to proceed, the instrument will be repaired and returned. Aurora H2O User’s Manual...
  • Page 168 Warranty [no content intended for this page] Aurora H2O User’s Manual...
  • Page 170 Customer Support Centers U.S.A. The Boston Center 1100 Technology Park Drive Billerica, MA 01821 U.S.A. Tel: 800 833 9438 (toll-free) 978 437 1000 E-mail: mstechsupport@bakerhughes.com Ireland Sensing House Shannon Free Zone East Shannon, County Clare Ireland Tel: +353 (0)61 470200 E-mail: mstechsupport@bakerhughes.com Copyright 2017 Baker Hughes company.

Table of Contents
