Chapter 7. Specifications
7.5
Spoolpiece Specifications (cont.)
Nominal Pipe
Size
ANSI Flange Weight
6"
300 lb (112 kg)
600 lb (224 kg)
8"
300 lb (112) kg
600 lb (224 kg)
10"
300 lb (112 kg)
600 lb (224 kg)
12"
300 lb (112) kg
600 lb (224 kg)
14"
300 lb (112 kg)
600 lb (224 kg)
16"
300 lb (112) kg
600 lb (224 kg)
18"
300 lb (112 kg)
600 lb (224 kg)
20"
300 lb (112) kg
600 lb (224 kg)
24"
300 lb (112 kg)
600 lb (224 kg)
Component
Pipe Flanges and Fittings
Pipe Sections
Transducer Holder Components
T11 Transducer
*A350 LF2 and A333 Gr. 6 are used for low temperature service and are specified by the customer.
126
Meter Body Length
Flange Face-to-Face
45" (1143mm)
48" (1219mm)
52" (1321mm)
56" (1422mm)
58" (1473mm)
60" (1524mm)
63" (1600mm)
67" (1702mm)
74" (1880mm)
Carbon Steel (A105 or A350 LF2*)
Carbon Steel (A106 Gr. B or A333 Gr. 6*)
Stainless Steel 316/316L (A276)
Titanium CP Gr. 2 (B348/B381)
Bore
Schedule
40
80
40
80
40
80
40
80
40
80
40
80
40
80
40
80
40
80
Materials
Actual ID
6.065"
5.761"
7.981"
7.625"
10.020"
9.562"
11.938"
11.374"
13.124"
12.500"
15.000"
14.312"
16.876"
16.124"
18.812"
17.938"
22.624"
21.562"
