7.3

Environmental Specifications

7.3.1

Operating Temperature

Minimum
–40°F (–40°C)
Maximum
+140°F (+60°C)
7.3.2

Random Vibration

Frequency Range
10-150 Hz
Total RMS Level
2
2
5.25 ft/s
(1.6 m/s
)
ASD Level 10-20Hz
2
0.157 ft/s
(0.048 m/s
ASD Level 20-150Hz
-3dB/octave
Number of Axes
3
Duration
2 minutes or longer per axis
7.3.3

Sinusoidal Vibration

Frequency Range
10-150 Hz
Total RMS Level
2
2
6.56 ft/s
(2 m/s
)
Number of Axes
3
Duration
20 cycles per axis
Sentinel™ User's Manual
2
)
Chapter 7. Specifications
121
