7.5

Spoolpiece Specifications

Body Design Code
U.S. Dept. of Transportation Regulation 49 C.F.R. Part 192, Transportation of Natural and Other Gas by Pipeline:
Minimum Federal Safety Standards
MSS SP-97 Integrally Reinforced Forged Branch Outlet Fittings – Socket Welding, Threaded and Butt Welding Ends
–(Burst Test Guidelines)
ASME B36.10M Welded and Seamless Wrought Steel Pipe
Flange Design Code
ASME B16.5 Pipe Flanges and Flanged Fittings
Design Temperature
–22°F to 140°F (–30°C to 60°C) for meter body only
Operating Pressure
740 psig or 50 Bar for ANSI 300
1480 psig or 100 Bar for ANSI 600
Exterior Coating System
Sandblast per SPCC Spec SP10
Inorganic zinc silicate primer (3 mils DFT)
Epoxy High-Build (4-6 mils DFT)
System Safety Analysis
REAP 10 Panametrics Power Systems Product Safety (PHA and Ha2Op)
Internal Coating
Water Soluble Rust Preventative
