6.3.2

T11 Transducer Installation Components

See Table 1 below and Figure 75 below for the components required to install the new transducer.
Table 1: Components at each Transducer Location
No.*
Part Number
1
577-004-00
2
551-1135
3
410-538
4
410-539
5
412-1032-24
6
412-148
7
8
*Component numbers correspond to item numbers in Figure 75 below.
6.3.3

Installing a New Transducer in a Depressurized Pipe

IMPORTANT: The following procedures should be used only in situations where the process line is shut down.
Sentinel™ User's Manual
Description
Sensor Holder
Sensor Flange
O-Ring, Size 210, Viton
O-Ring, Size 213, Viton
Screw, Cap Hex 3/8-16 x 1-1/2
Washer, Lock Split 3/8"
O-Ring-Safe Lubricant
Anti-Seize Lubricant
5
6
4 places
8
4 places
7
4
7
3
2 places
Figure 2: T11 Installation Components for a Depressurized Pipe
Chapter 6. Transducer Replacement
Qty.
1
1
2
1
4
4
A/R
A/R
2
T11 Transducer
1
103
