Chapter 3. Operation
3.10 Entering Velocity Constants
Use PanaView to enter fixed values for flow velocity. To accomplish this, complete the following steps:
1.
Make sure the system is connected to your computer, the system and the computer are turned on, and
PanaView is up and running.
2.
In the File menu, open the
3.
To enter values for
Channel 1
Vel
4.
Click twice on
and the
5.
Enter the desired values and click on the
Note:
The values should be entered in ascending velocity order.
6.
Channel 2
To enter values for
7.
When all the appropriate values have been entered, exit the program.
78
New Meter Browser
.
, click on the + sign before each level to open it (see Figure 43 on page lxvi).
Velocity
display appears (see Figure 60 below).
OK
button.
, repeat the above procedure under the
Figure 19: PanaView Velocity Correction Display
Channel 2
directory.
