Appendix A. CE Mark Compliance

A.1

Introduction

For CE Mark compliance, the Sentinel Flow Measurement System must be wired in accordance with the instructions in
this appendix.
IMPORTANT:
CE Mark compliance is required for all units intended for use in EU countries.
A.2

Wiring

The Sentinel must be wired with the recommended cable, and all connections must be properly shielded and
grounded. Refer to Table 3 below for the specific requirements.
Connection
Input/Output
(e.g., Baystate #78-1197)
Power 14 AWG, 3 conductor, shielded
Note:
If the Sentinel is wired as described in this appendix, the system will comply with the EMC Directive.
Sentinel™ User's Manual
Table 1: Wiring Modifications
Cable Type
22 AWG shielded
Armored conduit
(e.g., Belden #19364)
Armored Conduit
Termination Modification
Terminate shield
to chassis ground.
None - grounded
using a conduit fitting.
Terminate shield
to chassis ground.
None - grounded
using a conduit fitting.
Appendix A. CE Mark Compliance
