OUT1 Red
Frequency
RTN1 Black
NO Red
Alarm
COM Black
+
–
Modbus
#22 +Sield
1345 Board
Twisted
Twisted
Pair
Pair
Channel
2
Up Down
Transducer Transducer
Transducer wiring, accomplished at the
factory, is shown for information purposes
only and should not be changed by the user.
Sentinel™ User's Manual
#22 Twisted
Note 1
J5
3 2 1
J4
CH2
CH1
J3
ENCLOSURE #1
PC Board #703-1459
Twisted Twisted
Pair Pair
Channel
RS485
1
Down Up
Transducer Transducer
Important:
#22 Twisted
J2
J1 J1
+
RX
–
RS232
TX
#22 +Shield
RS485 RS232
Connections Connections
Notes:
1. J5 as shown is on the 1345 Communication Board
that connects to the 1236 Board.
2. Wire colors are represented as follows:
B = Black O = Orange (from Mineral Insulated enclosure link)
R = Red Y = Yellow (from Mineral Insulated enclosure link)
W = White WM = White (from Mineral Insulated enclosure link)
ENCLOSURE #2
PC Board #703-1460
+
1
–
2
3
TB5
#18
+
DC –
DC POWER
Connections
Chapter 1: Installation
