Title page
Nortel Communication Server 1000
Nortel Communication Server 1000 Release 4.5
Communication Server 1000S
Installation and Configuration
Document Number: 553-3031-210
Document Release: Standard 4.00
Date: May 2007
Year Publish FCC TM
Copyright © 2007 Nortel Networks
All Rights Reserved
Produced in Canada
The information in this document is subject to change without notice. The statements, configurations, technical
data, and recommendations in this document are believed to be accurate and reliable, but are presented
without express or implied warranty. Users must take full responsibility for their applications of any products
specified in this document. The information in this document is proprietary to Nortel Networks.
Nortel, the Nortel Logo, the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
