INVT Goodrive 300 Operation Manual page 155

inverters
Goodrive300
Function
code
P03.12 Keypad setting torque
Torque reference filter
P03.13
P03.14 forward rotation in vector
P03.15 reverse rotation in vector
Keypad setting for upper
P03.16
frequency of forward
Keypad setting for upper
P03.17
frequency of reverse
Name
time
Upper frequency of
control
Upper frequency of
control
rotation
Detailed instruction of parameters
torque
8:PROFIBUS\CANopen communication
setting torque
9:Ethernet communication setting torque
10:Reserved
-300.0%~300.0%(rated current of the
motor)
0.000~10.000s
0:Keypad (P03.16 sets P03.14,P03.17
sets P03.15)
1: AI1
2: AI2
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting
upper-limit frequency
7:PROFIBUS communication setting
upper-limit frequency
8:Ethernet communication setting
upper-limit frequency
9: Reserved
Setting range:0.00Hz~P00.03(the
Maximum frequency)
154
Basic operation instruction
Default
value
50.0%
0.100s
50.00Hz
50.00Hz
0
0
