INVT Goodrive 300 Operation Manual page 161

inverters
Goodrive300
Function
code
P04.01 Torque boost of motor 1
Torque boost close of
P04.02
P04.03
frequency 1 of motor 1
P04.04
voltgage 1 of motor 1
P04.05
frequency 2 of motor 1
P04.06
voltgage 2 of motor 1
P04.07
frequency 3 of motor 1
P04.08
voltgage 3 of motor 1
V/F slip compensation
P04.09
Vibration control factor at
P04.10
low frequency of motor 1
Vibration control factor at
P04.11
high frequency of motor 1
Vibration control threshold
P04.12
P04.13 Motor 2 V/F curve setting
Name
motor 1
V/F
V/F
V/F
V/F
V/F
V/F
gain of motor 1
of motor 1
Detailed instruction of parameters
5:Customized V/F(V/F separation)
0.0%:(automatic)0.1%~10.0%
0.0%~50.0%(the rated
motor 1)
0.00Hz~P04.05
0.0%~110.0%
P04.03~ P04.07
0.0%~110.0%
P04.05~P02.02 or P04.05~P02.16
0.0%~110.0%
0.0~200.0%
0~100
0~100
0.00Hz~P00.03 (the Max. frequency)
0:Straight line V/F curve；applying to the
constant torque load
1:Multi-dots V/F curve
th
2:1.3 power low torque V/F curve
th
3:1.7 power low torque V/F curve
th
4:2.0 power low torque V/F curve
5:Customized V/F(V/F separation)
160
Basic operation instruction
Default
value
0.0%
frequency of
20.0%
0.00Hz
00.0%
00.00Hz
00.0%
00.00Hz
00.0%
0.0%
30.00 Hz
10
10
0
