INVT Goodrive 300 Operation Manual page 71

inverters
Goodrive300
Functi
on Name
code
Keypad
P03.12 setting
torque
Torque
P03.13 reference
filter time
Upper
frequency
of forward
P03.14
rotation in
vector
control
Upper
frequency
of reverse
P03.15
rotation in
vector
control
Keypad
setting for
upper
P03.16
frequency
of forward
rotation
Detailed instruction of parameters
Note: Setting modes 2~10, 100% corresponds to
three times of the rated current of the motor.
Setting range: -300.0%~300.0%(rated current of
the motor)
0.000~10.000s
0:Keypad (P03.16 sets P03.14,P03.17 sets
P03.15)
1: AI1
2: AI2
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting upper-limit
frequency
7:PROFIBUS communication setting upper-limit
frequency
8:Ethernet communication setting upper-limit
frequency
9: Reserved
Note:setting method 1~9, 100% corresponds to the
maximum frequency
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14; P03.17
sets the value of P03.15.
Setting range:0.00 Hz~P00.03 (the Max. output
frequency)
70
Function codes
Default Modif
value y
○
50.0%
○
0.010s
○
0
○
0
50.00
○
Hz
