INVT Goodrive 300 Operation Manual page 136

inverters
Goodrive300
Functi
on Name
code
P13.08 Control
parameter
1
P13.09 Control
parameter
2
P13.10 Reserved
Maladjustm
ent
P13.11
detection
time
High
frequency
P13.12
compensati
on
coefficient
Braking
P13.13 current of
short-circuit
Braking
retention
P13.14
time before
starting
The braking
retention
P13.15
time when
stopping
P14 Group Serial communication
Local
P14.00 communica
tiaddress
Detailed instruction of parameters
0~65535
0~655.35
0~65535
Adjust the response of anti-maladjustment. Bigger
load inertia may increase the value, but the
response will be slower.
Setting range: 0.0~10.0s
When the motor speed is faster than the rated
speed, the parameter is valid, if vibration occurs to
the motor, please adjust the parameter.
Setting range: 0~100.0%
When P01.00=0 during the starting of the inverter,
set P13.14 to a non-zero value to enter the short
circuit braking.
When the running frequency is lower than P01.09
during the stopping of the inverter, set 13.15 to a
non-zero value to enter into stopping short circuited
braking and then carry out the DC braking at the
time set by P01.12 (refer to the instruction of
P01.09~P01.12) .
Setting range of P13.13: 0.0~150.0%(the inverter)
Setting range of P13.14: 0.0~50.0s
Setting range of P13.15: 0.0~50.0s
The setting range:1~247
When the master is writing the frame, the
communication address of the slave is set to 0; the
address is the communication address. All slaves
135
Function codes
Default Modif
value y
○
0
○
2.00
○
0
○
0.5s
○
0.0%
○
0.0%
○
0.0s
○
0.0s
○
1
