C.5 Dimensions for inverters of AC 3PH 520V(-15%)~690V(+10%)
C.5.1 Wall installation
Model
22kW~45kW
55kW~132kW
Wall installation of 660V 22-132kW inverters
Wall installation of 660V 160-220kW inverters
Wall installation of 660V 250-350kW inverters
Installation dimension (unit:mm)
W1
W2
270
130
325
200
H1
H2
555
540
680
661
287
Appendix C
Installation
D1
hole
325
7
365
9.5
