Goodrive300
Functi
on Name
code
Keypad
P09.01
PID preset
PID
P09.02 feedback
source
Detailed instruction of parameters
5:Multi-step speed set
6:MODBUS communication set
7:PROFIBUS communication set
8:Ethernet communication set
9:Reserved
The setting target of procedure PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the relative
value (0~100.0%).
Note:
Multi-step speed given, it is realized by
setting PA group parameters.
PROFIBUS, Ethernet and CANopen
communication setting need corresponding
extension cards.
When P09.00=0, set the parameter whose basic
value is the response value of the system.
The setting range:-100.0%~100.0%
Select the PID channel by the parameter.
0: AI1
1: AI2
2: AI3
3: HDI
4:MODBUS communication feedback
5:PROFIBUS communication feedback
6:Ethernet communication feedback
7:Reserved
Note: The reference and feedback channel can not
coincide, otherwise, PID can not control effectively.
114
Function codes
Default Modif
value y
○
0.0%
○
0
