INVT Goodrive 300 Operation Manual page 289

inverters
Goodrive300
Model
160kW~220kW
250kW~350kW
C.5.2 Flange installation
Model W1
22kW~45kW 270
55kW~132kW 325
160kW~220kW 500
W1 W2
500 180
680 230
Flange installation of 660V 22-132kW inverters
Flange installation of 660V 160-220kW inverters
W2 W3 W4
130 261 65.5
200 317 58.5
180 480 60
H1 H2
870 850
960 926
H1 H2 H3
555 540 516
680 661 626
870 850 796
288
Appendix C
Installation
D1
360
380
H4 D1 D2
17 325 167
23 363 182
37 358 178.5
hole
11
13
Installation
hole
7
9.5
11
