When the user selects the user-defined V/F curve function in Goodrive300 series inverters, they
can set the given channel of voltage and frequency and the corresponding ACC/DEC time, or the
two can combinate to form a real-time curve.
Note: the application of V/F curve separation can be used in many cases with various kinds of
power supply of the inverter. But the users should set and adjust the parameters with caution.
Incorrect parameters may cause damage to the inverter.
Function
code
P00.00 Speed control mode
P00.03 Max. output frequency
Upper limit of the running
P00.04
Lower limit of the running
P00.05
P00.11
P00.12
P02.00
P02.02
asynchronous motor 1
P02.04
asynchronous motor 1
P04.00 Motor 1V/F curve setting
Name
frequency
frequency
ACC time 1
DEC time 1
Motor type 1
Rated frequency of
Rated voltage of
Detailed instruction of parameters
0: Sensorless vector control mode 0
(apply to AM and SM)
1: Sensorless vector control mode 1
(applying to AM)
2:V/F control
P00.04~400.00Hz
P00.05~P00.03
0.00Hz~P00.04
0.0~3600.0s
0.0~3600.0s
0:Asynchronous motor
1:Synchronous motor
0.01Hz~P00.03(Max frequency)
0~1200V
0:Straight line V/F curve；applying to the
constant torque load
1:Multi-dots V/F curve
th
2:1.3 power low torque V/F curve
th
3:1.7 power low torque V/F curve
th
4:2.0 power low torque V/F curve
159
Basic operation instruction
Default
value
50.00Hz
50.00Hz
0.00Hz
Depend
on model
Depend
on model
50.00
Depend
on model
1
0
0
