INVT Goodrive 300 Operation Manual page 296

inverters
Goodrive300
D.4.2.2 The inverters of AC 3PH 520V(-15%)~690V(+10%)
cable size (mm
Model
UVW
GD300-022G-6
GD300-030G-6
GD300-037G-6
GD300-045G-6
GD300-055G-6
GD300-075G-6
GD300-090G-6
GD300-110G-6
GD300-132G-6
GD300-160G-6
GD300-185G-6
GD300-200G-6
GD300-220G-6
GD300-250G-6
GD300-280G-6
GD300-315G-6 95*2P
GD300-350G-6 95*2P
GD300-400G-6 150*2P
GD300-500G-6 95*4P
GD300-560G-6 95*4P
GD300-630G-6 150*4P
Note:
1. It is appropriate to use the recommended cable size under 40℃ and rated current. The
wiring distance should be no more than 100m..
2. Terminals P1, (+), PB and (-) connects the DC reactor options and parts.
D.4.3 Routing the cables
Route the motor cable away from other cable routes. Motor cables of several drives can be
run in parallel installed next to each other. It is recommended that the motor cable, input
Recommended
2
)
RST
PE
10 10
10 10
16 16
16 16
25 16
35 16
35 16
50 25
70 35
95 50
95 50
120 70 95~300 70~300 35~300 70~240
185 95 95~300 70~300 35~300 95~240
185 95 95~300 70~300 35~300 95~240
240 120 95~300 95~300 70~300 120~240
95 95~150 70~150 70~150 35~95
95 95~150 70~150 70~150 35~95
150 95~150 70~150 70~150 50~150
95*2P 95~150 70~150 70~150 70~150
95*4P 95~150 70~150 70~150 70~150
150*2P 95~150 70~150 70~150 70~150
Connecting cable size (mm
RST PB
P1,(+)
UVW (+),(-)
10~16 6~16 6~10
10~16 6~16 6~10
16~25 16~25 6~10
10~16 16~35 10~16
16~25 16~35 16~25
25~50 25~50 25~50
25~50 25~50 25~50
35~95 50~95 25~95
70~95 35~95 50~75
35~95 35~150 25~70 50~150
35~95 35~150 25~70 50~150
295
Appendix D
Tightening
2
)
Terminal
torque
screw
PE
6~16 M8
6~16 M8
10~16 M8
10~16 M8
16~25 M10 18~23
16~25 M10 18~23
16~25 M10 18~23
25 M10 18~23
25~35 M10 18~23
It is recommended to
use wrench or
sleeve because
screw is used as
terminal.
(Nm)
9~11
9~11
9~11
9~11
