inverters
Goodrive300
Function
code
P09.03
P09.04 Proportional gain (Kp)
P09.05
P09.06
P09.07
P09.08 PID control deviation limit 0.0~100.0%
P09.09 Output upper limit of PID
P09.10 Output lower limit of PID
P09.11
P09.12
P09.13
P17.00
P17.23
P17.24

7.16 Traverse running

Traverse is applied in some industries such as textile, chemical fiber and cases where traverse and
Name
PID output feature
Intergal time(Ti)
Differential time(Td)
Sampling cycle(T)
Detection value of
feedback offline
Detection time of
feedback offline
PID adjustment
Set frequency
PID reference
PID feedback
Detailed instruction of parameters
6:Ethernet communication feedback
7:Reserve
0:PID output is positive
1:PID output is negative
0.00~100.00
0.00~10.00s
0.00~10.00s
0.00~100.00s
P09.10~100.0%
(Max. frequency or the Max. voltage)
-100.0%~P09.09
(Max. frequency or the Max. voltage)
0.0~100.0%
0.0~3600.0s
0x00~0x11
LED ones:
0:Keep the integral adjustment ON while
the frequency achieves upper or lower
limit.
1:Stop the integral adjustment while the
frequency achieves the upper or lower
limit
LED tens:
0:The same with the setting direction
1:Opposite to the setting direction
0.00Hz~P00.03 (the Max. frequency)
-100.0~100.0%
-100.0~100.0%
209
Basic operation instruction
Default
value
1.00
0.10s
0.00s
0.10s
0.0%
100.0%
0.0%
0.0%
1.0s
0x00
0.00Hz
0.0%
0.0%
