Functi
on Name
code
PZD12
P15.12
receiving
PZD2
P15.13
sending
PZD3
P15.14
sending
PZD4
P15.15
sending
PZD5
P15.16
sending
PZD6
P15.17
sending
PZD7
P15.18
sending
PZD8
P15.19
sending
PZD9
P15.20
sending
PZD10
P15.21
sending
PZD11
P15.22
sending
PZD12
P15.23
sending
Detailed instruction of parameters
10:Virtual output terminals command
Range:0x00~0x0F
11:Voltage setting value(special for V/F
separation )(0~1000,1000 corresponds to 100.0%
the rated voltage of the motor)
12: AO output set value 1(-1000~1000,1000
corresponds to 100.0%)
13: AO output set value 2(-1000~1000,1000
corresponds to 100.0%)
14~20: Reserved
0: Invalid
1: Running frequency(*100,Hz)
2: Setting frequency(*100,Hz)
3: Bus voltage(*10,V)
4: Output voltage(*1,V)
5: Output current (*10,A)
6: Output torque actual value(*10,%)
7: Output power actual value(*10,%)
8:Running rotating speed(*1,RPM)
9:Running linear speed (*1,m/s)
10:Ramp given frequency
11:Fault code
12:AI1 value (*100,V)
13:AI2 value (*100,V)
14:AI3 value (*100,V)
15:PULSE frequency value (*100,kHz)
16:Terminals input state
17:Terminals output state
18:PID given(*100,%)
19:PID feedback(*100,%)
20:Motor rated torque
139
Function codes
Default Modif
value y
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
