INVT Goodrive 300 Operation Manual page 187

inverters
Goodrive300
Function
code
P06.00
P06.14
P06.15
HDO high-speed pulse
P06.16
Name
HDO output
AO1 output
AO2 output
output
Detailed instruction of parameters
0: Open collector pole high speed pulse
output
1: Open collector pole output.
0:Running frequency
1:Set frequency
2:Ramp reference frequency
3:Running rotation speed
4:Output current (relative to the rated
current of the inverter)
5:Output current(relative to the rated
current of the motor)
6:Output voltage
7:Output power
8:Set torque value
9:Output torque
10:Analog AI1 input value
11:Analog AI2 input value
12:Analog AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16:PROFIBUS communication set value
1
17:PROFIBUS communication set value
2
18: Ethernet communication set value 1
19: Ethernet communication set value 2
20~21: Reserved
22:Torque current(relative to the rated
current of the motor)
23:Pre-magnetizing current(relative to
the rated current of the motor)
186
Basic operation instruction
Default
value
0
0
0
0
