INVT Goodrive 300 Operation Manual page 191

inverters
Goodrive300
Set
value
12 increasing/decreasing setting
Switch between A setting and
13
Switch between A setting and
14
combination setting
Switch between B setting and
15
combination setting
16 Multi-step speed terminal 1
17 Multi-step speed terminal 2
18 Multi-step speed terminal 3
19 Multi-step speed terminal 4
20 Multi-step speed pause
21 ACC/DEC time selection 1
Function
Frequency
clear
B setting
Frequency increasing/decreasing
terminal can cancel the assistant channel frequency
set by the internal UP/DOWN of the inverter to make
the given frequency restore to the frequency given by
the main given frequency channel.
This function can realize the shifting between the
frequency setting channels.
th
The 13 function can realize the shifting between A
frequency given channel and B frequency given
channel.
th
The 14 function can realize the shifting between A
frequency given channel and the combination setting
channel set by P00.09
th
The 15 function can realize the shifting between B
frequency given channel and the combination setting
channel set by P00.09
The 16 stage speeds can be set by the combination of
digital state of four terminals.
Note: multi-step speed 1 is the low bit, multi-step
speed 4 is the high bit.
Multi-step Multi-step
speed 4 speed 3
BIT3 BIT2
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
Select 4 ACC/DEC time by the combination of the 2
190
Basic operation instruction
Instructions
setting
Multi-step
speed 2
BIT1
clear
Multi-step
speed 1
BIT0
