Functi
on Name
code
P15 Group PROFIBUS function
Module
P15.00
type
Module
P15.01
address
PZD2
P15.02
receiving
PZD3
P15.03
receiving
PZD4
P15.04
receiving
PZD5
P15.05
receiving
PZD6
P15.06
receiving
PZD7
P15.07
receiving
PZD8
P15.08
receiving
PZD9
P15.09
receiving
PZD10
P15.10
receiving
PZD11
P15.11
receiving
Detailed instruction of parameters
1: Communication encrypting invalid
0: PROFIBUS；
1: CANopen
Select communication protocol
0~127
This function code is used to designate the address
of the inverter.
Note: 0 is the broadcast address, when set it as
broadcast address, only receive the radio
command of the upper monitor other than
answering the upper monitor.
0:Invalid
1:Setting frequency (0~Fmax(unit:0.01Hz))
2: PID reference, range(0~1000,1000 corresponds
to 100.0%)
3:PID feedback, range(0~1000,1000 corresponds
to 100.0%)
4:Torque setting (-3000~3000,1000 corresponds to
100.0% the rated current of the motor)
5:Upper frequency of forward rotation
(0~Fmax unit:0.01Hz))
6: Upper frequency of reverse rotation
(0~Fmax(unit:0.01Hz))
7:Electromotion torque upper limit (0~3000,1000
corresponds to 100.0%of the rated current of the
motor)
8:Braking torque upper limit (0~2000,1000
corresponds to 100.0% of the rated current of the
motor)
9:Virtual input terminals command
Range:0x000~0x1FF
138
Function codes
Default Modif
value y
◎
0
◎
2
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
