INVT Goodrive 300 Operation Manual page 89

inverters
Goodrive300
Functi
on Name
code
frequency
of HDI
Correspond
ing setting
of upper
P05.53
limit
frequency
of HDI
HDI
frequency
P05.54
input filter
time
P06 Group Output terminals
P06.00 HDO output
P06.01 Y output
P06.02 HDO output
Relay RO1
P06.03
output
Relay RO2
P06.04
output
Detailed instruction of parameters
-100.0%~100.0%
0.000s~10.000s
The function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output:
The Max.pulse frequency is 50.0kHz. See
P06.27~P06.31 for detailed information of the
related functions.
1: Open collector pole output. See P06.02 for
detailed information of the related functions.
0:Invalid
1:In operation
2:Forward rotation operation
3:Reverse rotation operation
4: Jogging operation
5:The inverter fault
6:Frequency degree test FDT1
7:Frequency degree test FDT2
8:Frequency arrival
9:Zero speed running
88
Function codes
Default Modif
value y
Hz
○
100.0%
○
0.100s
◎
0
○
0
○
0
○
1
○
5
