INVT Goodrive 300 Operation Manual page 109

inverters
Goodrive300
Functi
on Name
code
FDT1
electrical
P08.32 level
detection
value
FDT1
retention
P08.33
detection
value
FDT2
electrical
level
P08.34
detection
value
FDT2
retention
P08.35
detection
value
P08.36 Frequency When the output frequency is among the positive
Detailed instruction of parameters
2: PROFIBUS communication shifting
3: Ethernet communication shifting
4: Reserved
LED tens: shifting enabling in operation
0: Disabled
1: Enabled
0x00~0x14
When the output frequency exceeds the
corresponding frequency of FDT electrical level,
the multi-function digital output terminals will output
the signal of "frequency level detect FDT" until the
output frequency decreases to a value lower than
(FDT electrical level—FDT retention detection
value) the corresponding frequency, the signal is
invalid. Below is the ware form diagram:
Setting range of P08.32: 0.00Hz~P00.03(the Max.
frequency)
Setting range of P08.33: 0.0~100.0%(FDT1
electrical level)
Setting range of P08.34: 0.00~P00.03(the Max.
frequency)
Setting range of P08.35: 0.0~100.0%(FDT2
electrical level)
108
Function codes
Default Modif
value y
50.00H
○
z
○
5.0%
50.00H
○
z
○
5.0%
○
0.00Hz
