INVT Goodrive 300 Operation Manual page 68

inverters
Goodrive300
Functi
on Name
code
Correction
coefficient
P02.28
of motor 1
power
Parameter
P02.29
display of
motor 1
P03 Group Vector control
Speed loop
P03.00 proportiona
l gain1
Speed loop
P03.01 integral
time1
Low
P03.02 switching
frequency
Speed loop
P03.03 proportiona
l gain 2
P03.04 Speed loop
Detailed instruction of parameters
Setting range: 20.0%~120.0%
Correct the power displaying of motor 1.
Only impact the displaying value other than the
control performance of the inverter.
Setting range: 0.00~3.00
0: Display according to the motor type
1: Display all
The parameters P03.00~P03.05 only apply to
vector control mode. Below the switching
frequency 1(P03.02), the speed loop PI parameters
are: P03.00 and P03.01. Above the switching
frequency 2(P03.05), the speed loop PI parameters
are: P03.03 and P03.04. PI parameters are gained
according to the linear change of two groups of
parameters. It is shown as below:
67
Function codes
Default Modif
value y
●
1.00
●
0
○
20.0
○
0.200s
○
5.00Hz
○
20.0
○
0.200s
