3-5. Disassembly, Reassembly and Lubrication
5. Remove the SA, Open Guide U [8-11].
1) Pull out Sensor Adjust Knob [8-20], disengage 1 E-ring (E-Ring, 3) [8-26], and remove
the Adjust Sensor Bushing 3 [8-18] and Guide Sensor Up Spring [8-17] from the
Sensor Adjust Shaft [8-16].
2) Disengage 1 E-ring (E-Ring, 2) [8-28], pull out Teeth Spring 1.2x8 Pin [8-3], remove the
Screw Gear [8-4] and Sensor Adjust Shaft [8-16], and detach the SA, Open Guide U
[8-11] from the SA, Open Guide L [8-22].
Note on reassembling:
• Apply grease (Floil G-311S) to the following points (refer to the places marked with
Drawing No. 8 "Unit, Sensor Adjust" for the Printer Part in Chapter 5 "Parts List"):
• Adjust Sensor Bushing 3 [8-18]: Rear surface (where contacting with E-ring)
• SA, Open Guide U [8-11]: 2 holes for the Sensor Adjust Shaft [8-16]
• SA, Open Guide L [8-22]: 2 holes for the Sensor Adjust Shaft [8-16]
6. Remove the SA, Open Guide L [8-22].
1) Remove 2 screws (PH (SW+PW), M3x5) [8-29] and detach the Sensor L Holder [8-25].
2) Peel off the Sensor Adjust Sheet [8-15] and Sensor Adjust Sheet L [8-32], and remove
the RFID Cover [8-21] from the SA, Open Guide L [8-22].
Note on reassembling:
• Apply grease (Floil G-311S) to the following points (refer to the places marked with
Drawing No. 8 "Unit, Sensor Adjust" for the Printer Part in Chapter 5 "Parts List"):
• SA, Open Guide L [8-22]: 2 holes for the Sensor Adjust Shaft [8-16]
3-24
