PARTS LIST for 7010R
Location Part Name
2-1 Shaft, Measure Sensor
2-2 Spring, Measure Sensor L
2-3 Spring, Measure Sensor R
2-4 Plate, Measure Sensor
2-5 Plate, Measure Flap
2-6 Shaft, Damper
2-7 Roller, Measure Sensor
2-8 SA, Rewinder Motor
2-9 Pivot, Rewinder Motor Plate
2-10 Guide, Motor Plate
2-11 Spring, Rewinder Motor
2-12 Sheet, Damper Plate Cover
2-13 Sheet, Peel Sensor Cover
2-14 Guide, Rewinder Flange
2-15 SA, Interlock SW
2-16 Plate, Nut
2-17 Stopper, Rewinder Door
2-18 Frame, Rewinder Inner
2-19 SA, Rewinder Flange
2-20 SA1, Peeler
TITLE: Unit, Rewinder
Drawing No. 2
Q'ty/
Part No.
Unit
1
1
1
1
1
2
4
1
1
1
1
1
1
2
1
1
2
1
1
1
5-65
Sheet No. 1/4
Rev. No. 0
Remarks @
