Tally Dascom 7010 Series Maintenance Manual page 209

PARTS LIST for 7010R
Location Part Name
1-1 Roll Holder
1-2 Flange, Paper Wide
1-3 Unit, Top Cover
1-4 Cover, Hinge
1-5 Holder, Paper Shaft Left
1-6 SA, Cover Inner Power
1-7 SA, Ribbon Holder
1-8 Stopper, Hinge
1-9 SA, Hinge
1-10 Unit, Mechanism
1-11 Cover, Inner Paper
1-12 Unit, PCB
1-13 Sheet 1, Power Protect
1-14 Plate, Power
1-15 Unit, Power Supply
1-16 Cover, Cable
1-17 SA, Power Cable
1-18 Cable, Ope-pane FFC
1-19 WS-2NS (Cable, Clamp)
1-20 SA, Fan
TITLE: General Assembly
Drawing No. 1
Q'ty/
Part No.
Unit
1 24600730
1
1 Ref: Drawing No. 10 / 7010, 7010-300
2
1
1
2
2
2
1 Ref: Drawing No. 2 / 7010, 7010-300
1
1 Ref.: Drawing No. 14 / 7010, 7010-300
1
1
401400 1
1
1
1
3
1
5-60
Sheet No. 1/3
Rev. No. 0
Dedicated for
Remarks
7010R
