2-3. Operation Panel

(3) Menu list print mode

You can print the list of machine information and current menu settings.
1. While pressing and holding the [MENU] key, turn on the power.
The POWER LED turns on and the LCD indicates "Print Settings", and then automatically
print starts.
The printer prints the list of machine information and current menu settings, and then
enters menu setup mode for further menu operation.
To exit from menu list print mode: In Main menu, press the [PAUSE] ( ) key.
<Example of Datamax
Machine Information
Model Number
Boot Version
ROM Version
ROM Date(DD//MM//YY)
ROMCheck Sum
Head Check
Print Counter
Service Counter
Sensor Monitor
Option Interface
Current Menu Settings
[Page Setup Menu]
Print Speed
Print Darkness
Darkness Adjust
Print Method
Continuous Media Length
Vertical Position
Horizontal Shift
Vertical Image Shift
Sensor Select
Media Sensor
Small Media Adjustment
Small Media Length
Symbol Set
[System Setup Menu]
Sensor Level
Paper End Level
Error Reporting
Cover Open Sensor
Buzzer Select
Metric/Inch
Max Media Length
Setting Lock
Keyboard Lock
Control Code
Emulation Select
[After Print Menu]
AutoConfigure
Function Select
Cutter Action
Paper Position
Menu Key Action
[Interface Menu]
RS-232C Baud rate
RS-232C Parity
RS-232C Length
RS-232C Stop bit
RS-232C X-ON
IEEE 1284
USB Device Class
USB VCOM Protocol
®
emulation selected (7010)>
: 7010
: ****
: ********
: XX/XX/XX
: ****
: OK
: 0002.234 km
: 0002.234 km
: 1.50 V
: None
: 7 IPS
: 12
: 00
: Thermal Transfer
: 4.00 inch
: 0.00 inch
: 0.00 inch
: 0.00 inch
: Rear Adj Sensor
: See Through
: Off
: 1.00 inch
: PM
: 1.7 V
: 2.80 V
: On Printing
: Off
: On
: Inch
: 10.00 inch
: Off
Off
: STD
: DM4
: On
: Tear
: Backfeed
: 0.00 inch
: Enters Menu
: 9600
: None
: 8 bit
: 1 bit
: Yes
: On
: Printer
: Auto
2-40
Note:
We continually enhance our
printers with new options and
settings based on our
customer's requests. Extra or
changed menu items may
appear on the print out in some
cases.
