(2-2) Init Fix-Refl sensitivity adjustment

Init Fix-Refl sensor is the reflective sensor (fixed type), i.e. SA, Sensor Bottom (Fixed
type).
Preparation:
Open the head block and the sensor arm, and then set label with black mark or tag with
black mark.
When label with black mark is used:
1. Prepare recommended media or media to be used.
2. Peel off labels from the liner.
3. Set the media and be sure that the media is put on the SA, Sensor Bottom (Fixed
type) (avoid the black mark area).
4. Close the sensor arm and the head block.
When tag with black mark is used:
1. Prepare recommended media or media to be used.
2. Set the media (if continuous tag is used, set it) and be sure that the media is put on
the SA, Sensor Bottom (Fixed type) (avoid the black mark area).
3. Close the sensor arm and the head block.
Procedure:
1. Enter Factory/Service mode by turning on the power while pressing and holding the
[MENU], [FEED] and [STOP] keys.
"Factory Setup" main menu appears.
2. In "Factory Setup" main menu, press the [STOP] ( ) key to enter Factory Setup mode.
The first submenu "Sens Vol Adj." appears.
3. Press the [MENU] ( ) key until "Init Fix-Refl" submenu appears.
Factory Setup
Init Fix-Refl
Exit
4. Press the [STOP] ( ) key to enter Init Fix-Refl sensitivity adjustment mode.
Init Fix-Refl
No
Exit
5. Press the [MENU] ( ) key to select "Exec".
Init Fix-Refl
Exec
Exit
Enter
Enter
Enter
