3-5. Disassembly, Reassembly and Lubrication

3-5-18. Disassembling the Rewinder Part (7010R Only)

Disassembly procedures for the Rewinder part of 7010R are explained here.
[Parts to be lubricated]
When the following parts are replaced or reassembled, apply grease (Floil G-311S).
The places to be lubricated are indicated with the mark
(the latter half) of Chapter 5 "Parts List".
Drawing No. 2 "Unit, Rewinder":
• Shaft, Measure Sensor [2-1]: Both ends of the shaft (2 places)
• Shaft, Damper [2-6]: Both ends of the shaft (2 places)
• SA, Rewinder Motor [2-8]: Contacting surface with the Motor Plate Guide [2-10] (1 place)
• Guide, Motor Plate [2-10]: Back surface (1 place)
• Shaft, Handle Plate [2-24]: Both ends of the shaft (2 places)
• Plate, Handle [2-28]: Both holes for the Handle Plate Shaft [2-24] (2 places)
• SA, Handle Link [2-29]: Both studs (2 places)
• Frame, Door L [2-33]: Door Shaft [2-40] (1 place)
• Frame, Door R [2-43]: Door Shaft [2-40] (1 place)
• Holder, Door Shaft R [2-44]: Hole for Door Shaft [2-40] (1 place)
Drawing No. 3 "SA1, Peeler":
• Roller, Idle Rewinder [3-1]: Both ends of the shaft (2 places)
• Bush, Idle [3-2]: Right side (2 places)
• Roller, Friction [3-6]: Both ends of the shaft (2 places)
• Plate, Sensor Holder [3-8]: Rear surface at both ends where circled with a dotted line (2
places)
Drawing No. 4 "SA2, Peeler":
• Roll, Peel [4-1]: Both ends of the shaft (2 places)
in the drawings for the Rewinder Part
