Tally Dascom 7010 Series Maintenance Manual page 161

PARTS LIST for 7010/7010-300
Location Part Name
2-1 Bushing
2-2 Shaft, Ribbon Guide FF
2-3 Bushing
2-4 SA, Front Tension Arm
2-5 Unit, Frame Rear
2-6 Unit, Frame U
2-7 Spring, Head Up
2-8 Unit, Head (203 dpi)
Unit, Head (300 dpi)
2-9 SA, Frame Ribbon R
2-10 SA, Base Guide Open
2-11 Ground Brush
2-12 Unit, Sensor Adjust
2-13 Sheet 2, Power Protect
2-14 Damper
2-15 Damper Pin
2-16 SA, Head Up SW
2-17 Clamp, Main Cable
2-18 Unit, Frame
2-19 Unit, Frame Ribbon L
TITLE: Unit, Mechanism
Drawing No. 2
Q'ty/
Part No.
Unit
1 24400670
1
1 24400680
1 Ref: Drawing No. 4
1 Ref: Drawing No. 5
1 Ref: Drawing No. 3
1
043948 1 For 7010/7010R
043949 1 For 7010-300
1 Ref: Drawing No. 6
1 Ref: Drawing No. 7
1 33000340
1 Ref: Drawing No. 8
1
1 25200890
1 22601801
1
1
1 Ref: Drawing No. 9
1 (Rev. No. 1)
5-12
Sheet No. 1/2
Rev. No. 1
Remarks @
