3-5. Disassembly, Reassembly and Lubrication
[How to refer to the exploded diagram in Chapter 5 "Parts List"]
This section explains how to disassemble, reassemble and lubricate.
However, for disassembly procedures, illustrations are not fully provided. For parts that are not
illustrated here, the parts location Nos. in the drawing in Chapter 5 "Parts List" are stated.
Example: Remove 3 screws (BH, M3x5K) [1-37] and detach Unit, PCB [1-12] backwardly.
In this example, [1-37] and [1-12] are the parts location Nos. Please refer to the parts location
Nos. "1-37" and "1-12" in Drawing No. 1 in Chapter 5 "Parts List".
When reassembling parts, follow "Note(s) on reassembling" described at the end of
disassembly procedure.
When the parts to be lubricated are replaced, necessity of lubrication is stated in the
reassembling procedure. The places to be lubricated are indicated in the drawings in Chapter
5, with the mark .
