Tally Dascom 7010 Series Maintenance Manual page 165

PARTS LIST for 7010/7010-300
Location Part Name
3-1 Idle Gear A Sub Assembly
3-2 Idle Gear B Sub Assembly
3-3 Gear Plate Spring
3-4 SA, Gear Plate
3-5 SA, Frame U
3-6 SA, Head Cable
3-7 Wire Tie
3-8 Spring, Head L
3-9 Head Balance Seal
3-10 Sheet, Cover Cable
3-11 Head Earth Plate
3-12 Head Plate
3-13 Offset Spring
3-14 Slider
3-15 Spring, Head R
3-16 Curved Washer
3-17 Adjust Screw
3-18 Open Lever Spring
3-19 Lever, Head Up
3-20 Polyslider Washer
TITLE: Unit, Frame U
Drawing No. 3
Q'ty/
Part No.
Unit
2 23205720
1 23205730
1 21903240
1
1
1
1
1
1 25201200
1
1 20803381
1 20803370
1 21902562
1 25200861
1
1 90500390
1 92100202
1 21902601
1
1 90500380
5-16
Sheet No. 1/2
Rev. No. 0
Remarks @
