2-3. Operation Panel
Submenu Name
[Factory Mode Settings
Menu name]
Fix-Thru Level
[Fix Through Cal Level]
Fix-Refl Level
[Fix Reflect Cal Level]
Fix-None Level
[Fix SensNone Cal Level]
Adj-Thru Level
[Adj Through Cal Level]
Adj-Refl Level
[Adj Reflect Cal Level]
Adj-None Level
[Adj SensNone Cal Level]
Peel Sens Level
Cont Paper Sens
Dbl Heat Menu
[Double Heat Menu]
PwrOn Head Chk
[Power On Head Check]
Head Chk Start
[Head Check Start Pos.]
Head Chk Stop
[Head Check Stop Pos.]
Rbn End Detect
[Ribbon End Detection]
Parallel ErrOut
USB Serial Num
[USB Serial Number]
Adjustable Value
(Default Value)
0.01 to 3.30V Performs sensitivity adjustment of the front fixed
(2.30 V) sensor for Media Sensor menu "See Through".
The amount of light received is set to "2.30V".
0.01 to 3.30V Performs sensitivity adjustment of the front fixed
(2.10 V) sensor for Media Sensor menu "Reflect". The
amount of light received is set to "2.10V".
0.01 to 3.30V Performs sensitivity adjustment of the front fixed
(2.05 V) sensor for Media Sensor menu "None". The
amount of light received is set to "2.05V".
0.01 to 3.30V Performs sensitivity adjustment of the adjustable
(2.30V) sensor for Media Sensor menu "See Through".
The amount of light received is set to "2.30V".
0.01 to 3.30V Performs sensitivity adjustment of the adjustable
(2.10 V) sensor for Media Sensor menu "Reflect". The
amount of light received is set to "2.10V".
0.01 to 3.30V Performs sensitivity adjustment of the adjustable
(2.05 V) sensor for Media Sensor menu "None". The
amount of light received is set to "2.05V".
0.01 to 3.30V Sets the threshold value for the peel sensor.
(1.50 V)
Through/Reflect When continuous media is used, selects the
(Reflect) sensor type to be used for detecting paper end.
On/Off Sets whether to display the menu of "Double
(Off) Heat".
On/Off Sets whether to perform head check at power
(On) ON or not.
Dots 001 to 848 Designates the start dot for head check.
(Dot 001)
Dots 001 to 848 Designates the end dot for head check.
(Dot 848)
Normal/Slow Sets the ribbon end detection time.
(Normal)
On/Off Select whether to activate the Fault signal of
(On) parallel interface at the time of error occurrence.
On/Off Select whether to send the serial number to the
(Off) host when operating the printer through the USB
interface.
2-48
Description
