Tally Dascom 7010 Series Maintenance Manual page 63

Submenu Name
[Factory Mode Settings
Menu name]
Fix-Thru Pos
[Fix Through Sensor Pos.]
Fix-Refl Pos
[Fix Reflect Sensor Pos.]
Adj-Thru Pos
[Adj Through Sensor Pos.]
Adj-Refl Pos
[Adj Reflect Sensor Pos.]
Mach Tear Pos
[Machine Tear Position]
Mach Cut Pos
[Machine Cut Position]
Mach Peel Pos
[Machine Peel Position]
Mach Hor Pos
Machine Horizontal Pos.]
Auto Cal Mode
[AutoCal Mode]
Fix-Thru LED
[Fix Through Sensor]
Fix-Refl LED
[Fix Reflect Sensor]
Adj-Thru LED
[Adj Through Sensor]
Adj-Refl LED
[Adj Reflect Sensor]
Adjustable Value
(Default Value)
-256 to +256 dot Electrically shifts the position of transparent
(+000 dot) sensor (fixed type) back and forth.
(-32 to +32 mm, -1.26 to +1.26")
-256 to +256 dot Electrically shifts the position of reflective sensor
(+000 dot) (fixed type) back and forth.
(-32 to +32 mm, -1.26 to +1.26")
-256 to +256 dot Electrically shifts the position of transparent
(+000 dot) sensor (adjustable type) back and forth.
(-32 to +32 mm, -1.26 to +1.26")
-256 to +256 dot Electrically shifts the position of reflective sensor
(+000 dot) (adjustable type) back and forth.
(-32 to +32 mm, -1.26 to +1.26")
-256 to +256 dot Electrically shifts the tear off position back and
(+000 dot) forth. (-32 to +32 mm, -1.26 to +1.26")
-256 to +256dot Electrically shifts the cutting position back and
(+000 dot) forth. (-32 to +32 mm, -1.26 to +1.26") (Optional)
-256 to +256dot Electrically shifts the peel position back and
(+000 dot) forth. (-32 to +32 mm, -1.26 to +1.26") (Optional)
-16 to +32dot Electrically shifts the head position to the right or
(+008 dot) left side.
(-2 to +4 mm, -0.08 to +0.16")
On/Off Automatically controls the light amount of each
(On) media sensor.
0.0 to 3.3V This menu is effective when "Auto Cal Mode" is
(0.0 V) set to OFF. The light amount emitted from the
transparent sensor (fixed type) can be changed
manually.
Larger value emits larger amount of light.
0.0 to 3.3V This menu is effective when "Auto Cal Mode" is
(0.0 V) set to OFF. The light amount emitted from the
LED of the reflective sensor (fixed type) can be
changed manually.
Larger value emits larger amount of light.
0.0 to 3.3V This menu is effective when "Auto Cal Mode" is
(0.0 V) set to OFF. The light amount emitted from the
transparent sensor (adjustable type) can be
changed manually.
Larger value emits larger amount of light.
0.0 to 3.3V This menu is effective when "Auto Cal Mode" is
(0.0 V) set to OFF. The light amount emitted from the
LED of the reflective sensor (adjustable type)
can be changed manually.
Larger value emits larger amount of light.
2-47
2-3. Operation Panel
Description
