3-6. Adjustments
7. Be sure that adjustment is successfully completed and the following screen is
displayed. (The value "123" is an example.)
Finished
DAC 123
Exit
When adjustment failed:
"Cannot Setup" is displayed. In this case, follow the next steps.
1) Press any key of the printer.
The screen returns to that in Step 3.
2) Check for correct media setting position, media, active
sensor (Sensor Select menu is set to "Front Fixed Sen"),
etc. and repeat from Step 3.
8. Press any key of the printer.
Then, the obtained value is saved into the printer and the screen returns to Step 3.
9. To continue other adjustment, proceed to the desired item ((2-2), (2-3) or (2-4)).
To terminate adjustment, go to the next step.
10. Press the [PAUSE] ( ) key to return to "Factory Setup" menu.
11. Press the [PAUSE] ( ) key once again.
The changed value is stored in the printer and the printer is turned OFF and then ON
for normal operation.
Enter
3-44
Cannot
Setup
Exit Enter
