4-2. Troubleshooting

4-2-7. Rewinder Problems (7010R Only)

(1) Rewinding problem (7010R Only)

Symptoms
Does not rewind.
Label is peeled but
rewinding operation
does not pause.
Checks
1. Is the rewinder cover opened?
In this case, the LCD indicates "Error
Rewinder Open".
2. Is the rewinder full?
In this case, the LCD indicates "Error
Rewinder Full".
3. Is the rewinder motor over heated?
In this case, the LCD indicates "Alarm
Rewinder Hot".
4. Are cables J15 and J16 (SA, Main PCB)
connected to J501 and J502 (SA,
Rewinder PCB) firmly?
5. Is the connector of the SA, Rewinder
Motor connected to J504 of the SA,
Rewinder PCB firmly?
6. Is the connector of the SA, Interlock
SW connected to SA, Rewinder Motor
firmly?
In this case, the LCD indicates "Error
Rewinder Open".
7. Failure in the SA, Rewinder Motor.
8. Failure in the SA, Rewinder PCB.
9. Failure in the control circuit.
1. Is the peel sensor cable connected to
JP503 of the SA, Rewinder PCB firmly?
2. Failure in the SA, Rewinder PCB.
3. Failure in the control circuit.
1. Close the rewinder cover.
2. Remove the wound media from the
rewinder flange.
3. Wait until the rewind motor gets
cool. Rewinding resumes
automatically.
4. Connect them firmly.
5. Connect it firmly.
6. Connect it firmly.
7. Replace the SA, Rewinder Motor.
8. Replace the SA, Rewinder PCB.
9. Replace the SA, Main PCB.
1. Connect it firmly.
2. Replace the SA, Rewinder PCB.
3. Replace the SA, Main PCB.
