(3-2) Setting submenu in Factory mode

In Factory mode, there are 2 types of submenus.
• Value setting type
• Option selection type
Procedure:
1. Enter Factory/Service mode by turning on the power while pressing and holding the
[MENU], [FEED] and [STOP] keys.
"Factory Setup" main menu appears.
2. In "Factory Setup" main menu, press the [STOP] ( ) key to enter Factory Setup mode.
The first submenu "Sens Vol Adj." appears.
3. Press the [MENU] ( ) or [FEED] ( ) key until "Adj-Thru Pos" submenu (example)
appears.
4. Press the [STOP] ( ) key to select that submenu.
The current value is shown on the LCD.
Position
+000 dots
Exit
5. Press the [MENU] ( ) or [FEED] ( ) key to increase or decrease the value (or select
a desired option).
In this example, the position of transparent sensor (adjustable type) will be electrically
moved back (-) and forth (+).
6. Press the [STOP] ( ) key to save the set value in the printer.
7. Press the [PAUSE] ( ) key to return to "Factory Setup" menu. (To set other submenu,
repeat from Step 2.)
8. Press the [PAUSE] ( ) key once again.
The changed value is stored in the printer and the printer is turned OFF and then ON
for normal operation.
Enter
